Abstract:A build-in power supply circuits IP core for TFT-LCD driver IC is designed using 0.25μm CMOS LV/MV/HV hybrid voltage process.It is composed by four sub-blocks such as LDO regulators,capacitor-switched charge-pump circuits,VCOM and Vgoff driving buffer circuits.Both power supply voltages for TFT-LCD driver IC and driving voltages for TFT-LCD panel can be provided by this IP core.The temperature coefficients of voltages generated by LDO regulators are less than 13.7ppm/℃.A new topology of charge pump which generates the highest voltage VGH and the lowest voltage VGL is proposed,and the settling time of VGH and VGL is reduced to less than 100ms.The voltages generated by VCOM and Vgoff driving buffer circuits can be adjusted by programmable register.All generated voltages are with their stable values in 200ms when power is on.The static power dissipation of this IP core is less than 2mW.

ROHM was established in Kyoto in 1958 as initially a manufacturer of small electronic components. In 1967 production was expanded to include transistors and diodes, and in 1969 ICs and other semiconductor products were added to the lineup. Two years later (in 1971), going against conventional Japanese business culture, the company entered the US market by establishing a sales office and IC design center in Silicon Valley. Through the hard work and passionate dedication of its young work force, business flourished, causing the industry to take notice. ROHM"s expansion overseas soon became a template for other companies and eventually was accepted as common business practice.

By continuing to use AliExpress you accept our use of cookies (view more on our Privacy Policy). You can adjust your Cookie Preferences at the bottom of this page.

The XC9516 series can offer three different power supplies to TFT-LCD panels. These power supplies consist of a step-up DC/DC converter for a source driver, positive and negative charge pumps for a gate driver.

This IC has power-on sequences to keep inrush current as small when output voltage rises. The step-up DC/DC output can be used as power-on sequences with adding a P-channel FET as external component. Also, the FET can shut down a path to the power input line when CE pin is low.

An IC for which any output voltage can be set by the reference voltage of the FB pins and the external dividing resistor. The output voltage is determined by the RFB1 and RFB2 values, using the following formula: VOUT = Vref × (RFB1 + RFB2)/RFB2

This circuit forcibly turns off the driver transistor when VIN drops below the UVLO voltage. If the input voltage recovers to the value which is equal to the specified value or more, UVLO will be released to resume the switching operation. It is resumed by the soft-start function. The paused state by UVLO is not the shutdown. The pulse output is stopped, but the internal circuit is operating.

BD83854GWL is a step-up switching regulator and charge pump inverter for small TFT-LCD Displays. It has a wide input voltage range of 2.5V to 4.5V that is suitable for portable applications. In addition, its small package design is ideal for miniaturizing the power supply.
