cpt tft display quotation

But now with the power of Crystal Displays promotion and technical know-how and back up you will be seeing a lot more of these CPT Industrial TFT Displays and excellent related products as they add great value to our clients applications and reputation.

Chunghwa Picture Tubes Ltd. (CPT), is a professional display manufacturer with 40 years + of expertise experience in TFT production. Through constant innovation design and research development, CPT brings out breath taking, high quality products to satisfy many industrial product designs. With years of display development product development and massive production as our corner store, combining with technological advantage such as wide viewing angle, fast response time, and high colour saturation. CPT continues to improve both the product and service quality, and plans for the next generation display technology. CPT will also thrive in medium-small TFT-LCD and touch panel, and aims to be the most advance company in terms of technology in the display panel market.

Product Parameters Resolution 800*3(RGB)*480 Interface TTL 50Pin Outline Dimensions 165.0(H)*100.0(V)*2.6(D)mm Viewing Angle Narrow Backlight 18 WLED Luminance 320cd/m2 Backlight Voltage 9.6V Backlight Current 140mA Glass Brand CPT

We are CLAA057VA01CWSupplier in China ,If you have any inquiry of CPT CLAA057VA01CW or other CPT lcd display , Welcome to contact us to get low price for it .

We are one of the professional and experienced suppliers of cpt 5.7 640*480 led tft-lcd display claa057va01cw, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.

* Says its wholly owned Fujian unit will sign agreement with the co’s actual controller Chunghwa Picture Tubes LTD, to get TFT-LCD panel patent use rights

ASI-T-40072B3MP6/A is a 4.0 inch TFT with a resolution of 720 x 720, 4-lane MIPI interface and with a brightness of 300 Nits; with a G+G Capacitive Touch Panel

ASI-T-700MA4F6/D is a 7.0 inch TFT with a resolution of 800 x 480, with parallel 24-bit RBG interface, a brightness of 430 nits and a capacitive touch panel.

WF43V*** is a WQVGA (480x272) diagonal size 4.3"" color TFT. It is built in with ST7282-G4-1L driver IC and supports 24-bit RGB interface. It’s available without touch panel or with Resistive / Capacitive Touch Screen. WF43V*** is the New Family that hasreplaced WF43H*** Family whichadopted the EOL CPT (Chunghwa Picture Tubes Ltd) TFT Panel

CPT TECHNOLOGY (GROUP) CO.,LTD is a China-based company principally engaged in the processing and distribution of liquid crystal display (LCD) modules. The Company’s main products include large-size Thin Film Transistor Liquid Crystal Displays (TFT-LCDs), medium- and small-size TFT-LCDs, cover lens, flat display components and products, LCD monitors, backlight modules and spare parts, among others. The Company"s products are applied in LCD televisions, laptops, monitors, computer monitors, smart phones, tablet computers and vehicle displays, among others. The Company mainly distributes its products in domestic market and to overseas markets.

I recently pulled a 7" display from a portable DVD viewer (I don"t know the correct term for those. It"s a netbook-shaped thing, that can play DVDs and files off of SD cards), that I"ve found in the dumpster.

Now, I wasn"t interested in the DVD player, but the display seemed interesting. I"ve powered up the device, and the display works fine, it displays a sort-of greeting screen with a "JAYtec" logo, and seems to wait for a DVD to be inserted.

So the display works fine, but I"d like to use it with other stuff. Before I can go on, I need to know what sort of interface it uses. There"s a sticker on the back saying "CPT 7.0-LED9+R3" with a barcode on it. I was suspecting this is something like a part number or product designator, and googled for it. The closest thing I could find is this: https://e2e.ti.com/cfs-file/__key/telligent-evolution-components-attachments/00-130-00-00-00-26-02-52/Chunghwa-Display-CLAA070LC0ECT.pdf the specification seems about correct, the backlight takes 9V, and 800×480px seems about right when it comes to resolution.

The datasheet suggests the display has a 30-pin LVDS connector, but this is where it doesn"t match with my screen. My screen has just a 26-pin flatflex connector.

So now, I"m a little at a loss. I don"t know what sort of interface this display uses. I can power up the backlight, but I don"t know even what sort of interface it has, so I can"t even really begin to read on about how to interface with it. Since this is a free display, I"d love to make a DSI -> LVDS adapter for it, possibly get a VGA/DVI -> LVDS interface adapter.
