cte tft lcd sd shield for arduino brands

2023-01-03 12:32:11

Hi all, have searched for help in the forum and found none on this combination. I"m using the UTFT libraries and the 320x240 example in the library. Using the 1.5.8 IDE. The code compiles fine, uploads fine, displays a white screen. I have set the pins for the Due with this shield as directed as shown here:

That is a select line for the SD card? Surely that doesn"t prevent the screen from displaying video. Where is it set? Have not found it in any of the files.

You have correctly updated HW_ARM_defines.h, the UTFT initialiser is correct "UTFT myGLCD(ITDB32S,25,26,27,28);" assuming your display is the part "TFT_320QVT" and you are sure your Sainsmart shield is CTE compatible.

Yes, all brand new. I have run sketches with the serial monitor so the Due seems to be working. The CTE shield and TFT display are of course unknowns. I do have 2 of the displays and they both react the same, lights up with white screen and no video. The back of the displays have TFT_320QVT by the SD slot and the SainSmart website by the pins.

Let us assume also your shield is ok (based on the fact it is new??), did you edit the UTFT/memorysaver.h file? Check the line #define DISABLE_SSD1289 IS commented! eg :-

You appear to have done everything to resolve this issue yourself, so I am thinking you have 3 choices, bite the bullet and order a CTE shield, send the shield and display back to Sainsmart or get out your multimeter and check out the shield manually.

Yes the SSD1289 line is commented. I guess using jumper wires to go direct to the Due would be one way to eliminate the shield and prove it is or is not bad. If it were bad, one would think only the 4 lines defined at the top of the sketch would be the issue of white screen.

Thank you Graham! I found the both pairs of 3,3v and 5v jumpers were jumped. That mistake resulted in a system voltage of 4.1v. Removing the 5v jumpers corrected the voltage to 3.3 but the result is the same. I have returned both the display and the CTE shield for refund. Based on my InSain experience I will be looking for another vendor.

BTW, I did hook up my 4x20 LCD display just to be sure the Due wasn"t damaged and works beyond "Hello World." The example LCD code in UTFT works fine once I commented out the code that has not been ported for Due.

Thats an interesting point you make! I understood there were problems with UTFT library when IDE 1.5.7 was released, and Henning issued an update to his libraries to deal with those problems, but I was not aware of any differences between 1.5.7 and 1.5.8. Can you confirm which version of UTFT you are using?

Maybe you should upgrade your version of UTFT? Based on the fact the compatibility issues I mentioned were already resolved in a later version than yours.....

So I checked and the uno was working, the LCD was working but the combo UNO, shield and LCD was not working. I noticed that the LCD is getting very hot.

yes it is possible, but you need to do several things first. Look at your schematic and identify the PWM pin for the back display. Make sure this pin is compatible with your display, and not being used. If it is available and compatiblewith your display, you will need to do the following.

cte tft lcd sd shield for arduino brands

So someone provided me an "Arduino Mega 2560", a "CTE TFT LCD/SD for Arduino Due [I just read that from the shield"s PCB xd] {CTE v1.04}", and a TFT LCD Display with an SD Card slot... which is only labeled as "TFT_320QVT_9341"... that"s the only text in the PCB apart from the pins" labels.

The LCD screen can"t be directly plugged into the Arduino as it has more pins than the mega"s digital pins, so I"m assuming that the shield is included to act as an adapter between the screen and the arduino.

Since yesterday, I was trying to get it to work with UTFT (the latest version available) but I never had any luck of getting anything displayed apart from a blank, white screen of nothingness.

cte tft lcd sd shield for arduino brands

This is SainSmart MEGA2560 + 7 inch TFT LCD module with the TFT LCD shield kit For arduino enthusiasts.It includes one pcs of SainSmart MEGA2560 , 7 inch TFT LCD display and a TFT LCD shield for Arduino MEGA2560.This kit helps you to avoid complicated wiring processes and save you much time to accomplish your goal. You can feel free to enjoy the touch function and SD card function by using our codes.We will provided you the whole document including the example project of the kit. We will supply you the technical support after your purchase.

This is the new MEGA2560 R3. In addition to all the features of the previous board, the MEGA now uses an ATMega16U2 instead of the ATMega8U2 chip. This allows for faster transfer rates and more memory. No drivers needed for Linux or Mac (inf file for Windows is needed and included in the Arduino IDE), and the ability to have the Uno show up as a keyboard, mouse, joystick, etc.

The MEGA2560 R3 also adds SDA and SCL pins next to the AREF. In addition, there are two new pins placed near the RESET pin. One is the IOREF that allow the shields to adapt to the voltage provided from the board. The other is a not connected and is reserved for future purposes. The MEGA2560 R3 works with all existing shields but can adapt to new shields which use these additional pins.

It is 100% compatible with the normal MCU like ARM AVR PIC and 8051,especially on Arduino family such as Arduino Due and Arduino MEGA2560(R3). The module uses the LCD controller Chip SSD1963 with 7 inch LCD including the touchscreen.

LCD-specificed intialization code is provided, so that you can save time to optimize power control register and gamma curves for best display performance. We have test the provided code, it gives the best display performanace

This is Sainsmart TFT LCD Extend shield for arduino due .Using this shield can help you out of the bothers to use other cables. You just need to plug the module to arduino due through this shield.

The shield defines that all the the data transmit ports are PC1-PC8 and PC12-PC19,the controll pins are PD0-PD3.The perfect design could realize that the data transmits in high speed.The SPI interface is designed in the ISP header of arduino due so that the SPI transfer with DMA could be achieved in high speed with no drag.

This shiled is just for Arduno MEGA2560. If you need the LCD Extend shield for Arduino Due,you need a similar shield which is also provided from our store.

This shiled is just for 7 inch TFT LCD.If you need the LCD Extend shield for 3.2/3.5/...,you need a similar shield which is also provided from our store.

cte tft lcd sd shield for arduino brands

This is SainSmart 7 inch TFT LCD module with the TFT LCD shield kit For arduino enthusiasts. It includes one pcs of 7 inch TFT LCD display and a TFT LCD shield for Arduino MEGA2560(R3). We will provided you the whole document including the example project of Arduino MEGA2560(R3) with the kit. We will supply you the technical support after your purchase.

It is 100% compatible with the normal MCU like ARM AVR PIC and 8051, especially on Arduino family such as Arduino Due and Arduino MEGA2560(R3).The module uses the LCD controller Chip SSD1963 with 5 inch LCD including the touchscreen.

This is SainSmart TFT LCD Extend shield for Arduino MEGA2560(R3). Using this shield can help you out of the bothers to use other cables. You just need to plug the module to Arduino MEGA2560(R3) through this shield.

The shield defines that all the the data transmit ports are PC1-PC8 and PC12-PC19,the controll pins are PD0-PD3.The perfect design could realize that the data transmits in high speed. The SPI interface is designed in the ISP header of arduino due so that the SPI transfer with DMA could be achieved in high speed with no drag.

This shiled is just for Arduno MEGA2560(R3). If you need the LCD Extend shield for Arduino Due, you need a similar shield which is also provided from our webstore.

This shiled is just for 7 inch TFT LCD.If you need the LCD Extend shield for 3.2"" or 5"", you need a similar shield which is also provided from our store.

cte tft lcd sd shield for arduino brands

10 Days Replacement This item is eligible for free replacement, within 10 days of delivery, in an unlikely event of damaged, defective or different/wrong item delivered to you. For device-related issues in Apple iPhones, please contact Apple Customer Service. For Android smartphones, our Returns Centre will prompt you to download the Blancco app to diagnose issues with a defective smartphone. We"ll provide a resolution on the basis of the Blancco app diagnostic results. In certain cases, we may also schedule a technician visit to your location. On the basis of the technician"s evaluation report, we will provide resolution.

10 Days Returnable This item is eligible for free replacement/refund, within 10 days of delivery, in an unlikely event of damaged, defective or different/wrong item delivered to you. Note: Please keep the item in its original condition, with MRP tags attached, user manual, warranty cards, and original accessories in manufacturer packaging.

7 Days Replacement This item is eligible for free replacement, within 7 days of delivery, in an unlikely event of damaged or different item delivered to you. In case of defective, product quality related issues for brands listed below, customer will be required to approach the brands’ customer service center and seek resolution. If the product is confirmed as defective by the brand then customer needs to get letter/email confirming the same and submit to Amazon customer service to seek replacement. Replacement for defective products, products with quality issues cannot be provided if the brand has not confirmed the same through a letter/email. Brands -HP, Lenovo, AMD, Intel, Seagate, Crucial

Please keep the item in its original condition, with brand outer box, MRP tags attached, user manual, warranty cards, CDs and original accessories in manufacturer packaging for a successful return pick-up. Before returning a Tablet, the device should be formatted and screen lock should be disabled.

For few products, we may schedule a technician visit to your location. On the basis of the technician"s evaluation report, we will provide resolution.

7 Days Replacement This item is eligible for free replacement, within 7 days of delivery, in an unlikely event of damaged, defective or different item delivered to you.

For few products, we may schedule a technician visit to your location. On the basis of the technician"s evaluation report, we will provide resolution.

7 Days Replacement This item is eligible for free replacement, within 7 days of delivery, in an unlikely event of damaged, defective or different item delivered to you.

For few products, we may schedule a technician visit to your location. On the basis of the technician"s evaluation report, we will provide resolution.

7 Days Replacement This item is eligible for free replacement, within 7 days of delivery, in an unlikely event of damaged, defective or different item delivered to you.

For few products, we may schedule a technician visit to your location. On the basis of the technician"s evaluation report, we will provide resolution.

All PC components, listed as Components under "Computers & Accessories" that are labeled as not returnable on the product detail page are not eligible for returns.

10 Days Replacement This item is eligible for free replacement, within 10 days of delivery, in an unlikely event of damaged, defective or different/wrong item delivered to you.

Note: Please keep the item in its original condition, with MRP tags attached, user manual, warranty cards, and original accessories in manufacturer packaging for a successful return pick-up.

10 days Replacement only This item is eligible for free replacement, within 10 days of delivery, in an unlikely event of damaged, defective or different/wrong item delivered to you. .

Please keep the item in its original condition, original packaging, with user manual, warranty cards, and original accessories in manufacturer packaging for a successful return pick-up.

10 Days Returnable This item is eligible for free replacement, within 10 days of delivery, in an unlikely event of damaged, defective or different item delivered to you. You can also return the product within 10 days of delivery for full refund.

Please keep the item in its original condition, with brand outer box, MRP tags attached, user manual, warranty cards, and original accessories in manufacturer packaging for a successful return pick-up.

Please keep the item in its original condition, with outer box or case, user manual, warranty cards, and other accompaniments in manufacturer packaging for a successful return pick-up.

All the toys item other than Vehicle and Outdoor Category are eligible for free replacement/refund, within 7 days of delivery, in an unlikely event of damaged, defective or different/wrong item delivered to you.

Vehicle and Outdoor category toys are eligible for free replacement, within 7 days of delivery, in an unlikely event of damaged, defective or different/wrong item delivered to you

Note: Please keep the item in its original condition, with outer box or case, user manual, warranty cards, and other accompaniments in manufacturer packaging for a successful return pick-up. We may contact you to ascertain the damage or defect in the product prior to issuing refund/replacement.

7 Days Replacement Only This item is eligible for free replacement, within 7 days of delivery, in an unlikely event of damaged, defective or different/wrong item delivered to you.

Please keep the item in its original condition, with outer box or case, user manual, warranty cards, and other accompaniments in manufacturer packaging for a successful return pick-up.We may contact you to ascertain the damage or defect in the product prior to issuing refund/replacement.

Return pickup facility is not available for these items. You can self return these products using any courier/ postal service of your choice. Learn more about shipping cost refunds.

The return timelines for seller-fulfilled items sold on Amazon.in are equivalent to the return timelines mentioned above for items fulfilled by Amazon.

If you do not receive a response from the seller for your return request within two business days, you can submit an A-to-Z Guarantee claim. Learn more about returning seller fulfilled items.

Note: For seller fulfilled items from Books, Movies & TV Shows categories, the sellers need to be informed of the damage/ defect within 14 days of delivery.

For seller-fulfilled items from Fine Art category, the sellers need to be informed of the damage / defect within 10 days of delivery. These items are not eligible for self-return. The seller will arrange the return pick up for these items.

For seller-fulfilled items from Sports collectibles and Entertainment collectibles categories, the sellers need to be informed of the damage / defect within 10 days of delivery.

The General Return Policy is applicable for all Amazon Global Store Products (“Product”). If the Product is eligible for a refund on return, you can choose to return the Product either through courier Pickup or Self-Return**

- Once the package is received at Amazon Export Sales LLC fulfillment center in the US, it takes 2 (two) business days for the refund to be processed and 2- 4 business days for the refund amount to reflect in your account.

- If your return is due to an Amazon error you"ll receive a full refund, else the shipping charges (onward & return) along with import fees will be deducted from your refund amount.

cte tft lcd sd shield for arduino brands

Description:Now, you can drive TFT LCD in a much faster speed using 84Mhz Ardiuno DUE. The shield is designed to fit two types of LCD:1. 40pin version LCD which is commonly used in previous version of TFT Mega shield for Arduino MEGA 25602. 32pin version LCD which is commonly used in STM32 development board. (unsoldered)The shield route all the LCD data pins to port PC1-PC8 and PC12-19, control pins to PD0-PD3, this design can acheive high speed data transfer (three cycles per write strobe to the LCD) to maximize LCD display speed. The SPI interface (for SD or flash control) is route to the ISP header of arduino DUE, so that high speed SPI transfer with DMA can be achieved.The shield is compatible with Arduino DUE and the following LCD:2.2" TFT LCD Module (220x176)2.8" TFT LCD Module (320x240)3.2" TFT LCD Module with Font IC (320x240)3.2" High Resolution TFT LCD Module with Font IC (480x320)3.5" TFT LCD Module with Font IC (480x320) (Full viewing angle IPS panel)4.0" TFT LCD Module with Font IC (480x320)4.3" TFT LCD Module with Font IC (480x272)5.0" TFT LCD Module with Font IC (800x480)7.0" TFT LCD Module with Font IC (800x480)Features:- Drive TFT LCD on arduino DUE by just plugging into arduino DUE main board, no flying wires- Compatible with 40-pin version LCD, which is commonly used in TFT Mega shield- Also comptabile with 32-pin version LCD, which is commonly used in STM32 development board- On board SD card slot with adjustable CS selection- On board SPI flash footprint with adjustable CS selection, for upgrade include Font IC to draw text to the LCD and also support SPIFlash library- LCD power 3.3V and 5V selectable through solder jumpers- LCD Backlight (LEDA+) 3.3V., 5V or PWM selectable through solder jumpers- Pins are routed to reduce CPU cycles, i.e. display speed is fasterPackage included:1 x CTE TFT LCD / SD Card Shield For Arduino DUE

cte tft lcd sd shield for arduino brands

TFT touchscreens are the amazing graphical interface which can be used with microcontrollers such as Atmel, PIC, STM, as it has a wide color range, and good graphical ability and a good mapping of pixels.

This library is the continuation of my ITDB02_Graph, ITDB02_Graph16 and RGB_GLCD libraries for Arduino and chipKit. As the number of supported display modules and controllers started to increase I felt it was time to make a single, universal library as it will be much easier to maintain in the future.

This library supports a number of 8bit, 16bit, and serial graphics displays, and will work with both Arduino, chipKit boards and select TI LaunchPads.

NOTE:Due to the size of the library I do not recommend using it on ATmega328 (Arduino Uno) and ATmega32U4 (Arduino Leonardo) as they only have 32KB of flash memory. It will work, but you will be severely limited in available flash memory for your application.

This is our target, this file has the names of the modules and shields that are supported by this library, you can see in it a list of module names and module names for the UTFT which you should use to define your module.

#include // Declare which fonts we will be usingextern uint8_t BigFont[];extern uint8_t SevenSegNumFont[];// Remember to change the model parameter to suit your display module!UTFT myGLCD(ITDB28, A5, A4, A3, A2);void setup(){myGLCD.InitLCD();myGLCD.clrScr();myGLCD.setFont(BigFont);}void loop(){myGLCD.setColor(0, 255, 0); //greenmyGLCD.print("HELLO WORLD", 45, 100);while (true) {};}

#include // Declare which fonts we will be usingextern uint8_t SmallFont[];extern uint8_t BigFont[];extern uint8_t SevenSegNumFont[];// Set the pins to the correct ones for your development shield// ------------------------------------------------------------// Arduino Uno / 2009:// -------------------// Standard Arduino Uno/2009 shield : ,A5,A4,A3,A2// DisplayModule Arduino Uno TFT shield : ,A5,A4,A3,A2//// Arduino Mega:// -------------------// Standard Arduino Mega/Due shield : ,38,39,40,41// CTE TFT LCD/SD Shield for Arduino Mega : ,38,39,40,41//// Remember to change the model parameter to suit your display module!UTFT myGLCD(ITDB32S,38,39,40,41);void setup(){myGLCD.InitLCD();myGLCD.clrScr();}void loop(){myGLCD.setColor(0, 255, 0);myGLCD.setBackColor(0, 0, 0);myGLCD.setFont(BigFont);myGLCD.print(" !\"#$%&"()*+,-./", CENTER, 0);myGLCD.print("0123456789:;<=>?", CENTER, 16);myGLCD.print("@ABCDEFGHIJKLMNO", CENTER, 32);myGLCD.print("PQRSTUVWXYZ[\\]^_", CENTER, 48);myGLCD.print("`abcdefghijklmno", CENTER, 64);myGLCD.print("pqrstuvwxyz{|}~ ", CENTER, 80);myGLCD.setFont(SmallFont);myGLCD.print(" !\"#$%&"()*+,-./0123456789:;<=>?", CENTER, 120);myGLCD.print("@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\\]^_", CENTER, 132);myGLCD.print("`abcdefghijklmnopqrstuvwxyz{|}~ ", CENTER, 144);myGLCD.setFont(SevenSegNumFont);myGLCD.print("0123456789", CENTER, 190);while(1) {};}

#include // Declare which fonts we will be usingextern uint8_t SmallFont[];// Set the pins to the correct ones for your development shield// ------------------------------------------------------------// Arduino Uno / 2009:// -------------------// Standard Arduino Uno/2009 shield : ,A5,A4,A3,A2// DisplayModule Arduino Uno TFT shield : ,A5,A4,A3,A2//// Arduino Mega:// -------------------// Standard Arduino Mega/Due shield : ,38,39,40,41// CTE TFT LCD/SD Shield for Arduino Mega : ,38,39,40,41//// Remember to change the model parameter to suit your display module!UTFT myGLCD(ITDB32S,38,39,40,41);void setup(){randomSeed(analogRead(0));// Setup the LCDmyGLCD.InitLCD();myGLCD.setFont(SmallFont);}void loop(){int buf[318];int x, x2;int y, y2;int r;// Clear the screen and draw the framemyGLCD.clrScr();myGLCD.setColor(255, 0, 0);myGLCD.fillRect(0, 0, 319, 13);myGLCD.setColor(64, 64, 64);myGLCD.fillRect(0, 226, 319, 239);myGLCD.setColor(255, 255, 255);myGLCD.setBackColor(255, 0, 0);myGLCD.print("* Universal Color TFT Display Library *", CENTER, 1);myGLCD.setBackColor(64, 64, 64);myGLCD.setColor(255,255,0);myGLCD.print("", CENTER, 227);myGLCD.setColor(0, 0, 255);myGLCD.drawRect(0, 14, 319, 225);// Draw crosshairsmyGLCD.setColor(0, 0, 255);myGLCD.setBackColor(0, 0, 0);myGLCD.drawLine(159, 15, 159, 224);myGLCD.drawLine(1, 119, 318, 119);for (int i=9; i<310; i+=10)myGLCD.drawLine(i, 117, i, 121);for (int i=19; i<220; i+=10)myGLCD.drawLine(157, i, 161, i);// Draw sin-, cos- and tan-linesmyGLCD.setColor(0,255,255);myGLCD.print("Sin", 5, 15);for (int i=1; i<318; i++){myGLCD.drawPixel(i,119+(sin(((i*1.13)*3.14)/180)*95));}myGLCD.setColor(255,0,0);myGLCD.print("Cos", 5, 27);for (int i=1; i<318; i++){myGLCD.drawPixel(i,119+(cos(((i*1.13)*3.14)/180)*95));}myGLCD.setColor(255,255,0);myGLCD.print("Tan", 5, 39);for (int i=1; i<318; i++){myGLCD.drawPixel(i,119+(tan(((i*1.13)*3.14)/180)));}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);myGLCD.setColor(0, 0, 255);myGLCD.setBackColor(0, 0, 0);myGLCD.drawLine(159, 15, 159, 224);myGLCD.drawLine(1, 119, 318, 119);// Draw a moving sinewavex=1;for (int i=1; i<(318*20); i++){x++;if (x==319)x=1;if (i>319){if ((x==159)||(buf[x-1]==119))myGLCD.setColor(0,0,255);elsemyGLCD.setColor(0,0,0);myGLCD.drawPixel(x,buf[x-1]);}myGLCD.setColor(0,255,255);y=119+(sin(((i*1.1)*3.14)/180)*(90-(i / 100)));myGLCD.drawPixel(x,y);buf[x-1]=y;}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);// Draw some filled rectanglesfor (int i=1; i<6; i++){switch (i){case 1:myGLCD.setColor(255,0,255);break;case 2:myGLCD.setColor(255,0,0);break;case 3:myGLCD.setColor(0,255,0);break;case 4:myGLCD.setColor(0,0,255);break;case 5:myGLCD.setColor(255,255,0);break;}myGLCD.fillRect(70+(i*20), 30+(i*20), 130+(i*20), 90+(i*20));}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);// Draw some filled, rounded rectanglesfor (int i=1; i<6; i++){switch (i){case 1:myGLCD.setColor(255,0,255);break;case 2:myGLCD.setColor(255,0,0);break;case 3:myGLCD.setColor(0,255,0);break;case 4:myGLCD.setColor(0,0,255);break;case 5:myGLCD.setColor(255,255,0);break;}myGLCD.fillRoundRect(190-(i*20), 30+(i*20), 250-(i*20), 90+(i*20));}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);// Draw some filled circlesfor (int i=1; i<6; i++){switch (i){case 1:myGLCD.setColor(255,0,255);break;case 2:myGLCD.setColor(255,0,0);break;case 3:myGLCD.setColor(0,255,0);break;case 4:myGLCD.setColor(0,0,255);break;case 5:myGLCD.setColor(255,255,0);break;}myGLCD.fillCircle(100+(i*20),60+(i*20), 30);}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);// Draw some lines in a patternmyGLCD.setColor (255,0,0);for (int i=15; i<224; i+=5){myGLCD.drawLine(1, i, (i*1.44)-10, 224);}myGLCD.setColor (255,0,0);for (int i=224; i>15; i-=5){myGLCD.drawLine(318, i, (i*1.44)-11, 15);}myGLCD.setColor (0,255,255);for (int i=224; i>15; i-=5){myGLCD.drawLine(1, i, 331-(i*1.44), 15);}myGLCD.setColor (0,255,255);for (int i=15; i<224; i+=5){myGLCD.drawLine(318, i, 330-(i*1.44), 224);}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);// Draw some random circlesfor (int i=0; i<100; i++){myGLCD.setColor(random(255), random(255), random(255));x=32+random(256);y=45+random(146);r=random(30);myGLCD.drawCircle(x, y, r);}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);// Draw some random rectanglesfor (int i=0; i<100; i++){myGLCD.setColor(random(255), random(255), random(255));x=2+random(316);y=16+random(207);x2=2+random(316);y2=16+random(207);myGLCD.drawRect(x, y, x2, y2);}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);// Draw some random rounded rectanglesfor (int i=0; i<100; i++){myGLCD.setColor(random(255), random(255), random(255));x=2+random(316);y=16+random(207);x2=2+random(316);y2=16+random(207);myGLCD.drawRoundRect(x, y, x2, y2);}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);for (int i=0; i<100; i++){myGLCD.setColor(random(255), random(255), random(255));x=2+random(316);y=16+random(209);x2=2+random(316);y2=16+random(209);myGLCD.drawLine(x, y, x2, y2);}delay(2000);myGLCD.setColor(0,0,0);myGLCD.fillRect(1,15,318,224);for (int i=0; i<10000; i++){myGLCD.setColor(random(255), random(255), random(255));myGLCD.drawPixel(2+random(316), 16+random(209));}delay(2000);myGLCD.fillScr(0, 0, 255);myGLCD.setColor(255, 0, 0);myGLCD.fillRoundRect(80, 70, 239, 169);myGLCD.setColor(255, 255, 255);myGLCD.setBackColor(255, 0, 0);myGLCD.print("That"s it!", CENTER, 93);myGLCD.print("Restarting in a", CENTER, 119);myGLCD.print("few seconds...", CENTER, 132);myGLCD.setColor(0, 255, 0);myGLCD.setBackColor(0, 0, 255);myGLCD.print("Runtime: (msecs)", CENTER, 210);myGLCD.printNumI(millis(), CENTER, 225);delay (10000);}

#include #include // Declare which fonts we will be usingextern uint8_t SmallFont[];// Set the pins to the correct ones for your development shield// ------------------------------------------------------------// Arduino Uno / 2009:// -------------------// Standard Arduino Uno/2009 shield : ,A5,A4,A3,A2// DisplayModule Arduino Uno TFT shield : ,A5,A4,A3,A2//// Arduino Mega:// -------------------// Standard Arduino Mega/Due shield : ,38,39,40,41// CTE TFT LCD/SD Shield for Arduino Mega : ,38,39,40,41//// Remember to change the model parameter to suit your display module!UTFT myGLCD(ITDB32S,A5,A4,A3,A2);extern unsigned int info[0x400];extern unsigned int icon[0x400];extern unsigned int tux[0x400];void setup(){myGLCD.InitLCD();myGLCD.setFont(SmallFont);}void loop(){myGLCD.fillScr(255, 255, 255);myGLCD.setColor(255, 255, 255);myGLCD.print(" *** A 10 by 7 grid of a 32x32 icon *** ", CENTER, 228);for (int x=0; x<10; x++)for (int y=0; y<7; y++)myGLCD.drawBitmap (x*32, y*32, 32, 32, info);delay(5000);myGLCD.fillScr(255, 255, 255);myGLCD.setColor(255, 255, 255);myGLCD.print(" Two different icons in scale 1 to 4 ", CENTER, 228);int x=0;for (int s=0; s<4; s++){x+=(s*32);myGLCD.drawBitmap (x, 0, 32, 32, tux, s+1);}x=0;for (int s=4; s>0; s--){myGLCD.drawBitmap (x, 224-(s*32), 32, 32, icon, s);x+=(s*32);}delay(5000);}

#include #include // Initialize display// ------------------// Set the pins to the correct ones for your development board// -----------------------------------------------------------// Standard Arduino Uno/2009 Shield : ,19,18,17,16// Standard Arduino Mega/Due shield : ,38,39,40,41// CTE TFT LCD/SD Shield for Arduino Due : ,25,26,27,28// Teensy 3.x TFT Test Board : ,23,22, 3, 4// ElecHouse TFT LCD/SD Shield for Arduino Due : ,22,23,31,33//// Remember to change the model parameter to suit your display module!UTFT myGLCD(ITDB32S,38,39,40,41);// Initialize touchscreen// ----------------------// Set the pins to the correct ones for your development board// -----------------------------------------------------------// Standard Arduino Uno/2009 Shield : 15,10,14, 9, 8// Standard Arduino Mega/Due shield : 6, 5, 4, 3, 2// CTE TFT LCD/SD Shield for Arduino Due : 6, 5, 4, 3, 2// Teensy 3.x TFT Test Board : 26,31,27,28,29// ElecHouse TFT LCD/SD Shield for Arduino Due : 25,26,27,29,30//URTouch myTouch( 6, 5, 4, 3, 2);// Declare which fonts we will be usingextern uint8_t BigFont[];int x, y;char stCurrent[20]="";int stCurrentLen=0;char stLast[20]="";/*************************** Custom functions ***************************/void drawButtons(){// Draw the upper row of buttonsfor (x=0; x<5; x++){myGLCD.setColor(0, 0, 255);myGLCD.fillRoundRect (10+(x*60), 10, 60+(x*60), 60);myGLCD.setColor(255, 255, 255);myGLCD.drawRoundRect (10+(x*60), 10, 60+(x*60), 60);myGLCD.printNumI(x+1, 27+(x*60), 27);}// Draw the center row of buttonsfor (x=0; x<5; x++){myGLCD.setColor(0, 0, 255);myGLCD.fillRoundRect (10+(x*60), 70, 60+(x*60), 120);myGLCD.setColor(255, 255, 255);myGLCD.drawRoundRect (10+(x*60), 70, 60+(x*60), 120);if (x<4)myGLCD.printNumI(x+6, 27+(x*60), 87);}myGLCD.print("0", 267, 87);// Draw the lower row of buttonsmyGLCD.setColor(0, 0, 255);myGLCD.fillRoundRect (10, 130, 150, 180);myGLCD.setColor(255, 255, 255);myGLCD.drawRoundRect (10, 130, 150, 180);myGLCD.print("Clear", 40, 147);myGLCD.setColor(0, 0, 255);myGLCD.fillRoundRect (160, 130, 300, 180);myGLCD.setColor(255, 255, 255);myGLCD.drawRoundRect (160, 130, 300, 180);myGLCD.print("Enter", 190, 147);myGLCD.setBackColor (0, 0, 0);}void updateStr(int val){if (stCurrentLen<20){stCurrent[stCurrentLen]=val;stCurrent[stCurrentLen+1]="\0";stCurrentLen++;myGLCD.setColor(0, 255, 0);myGLCD.print(stCurrent, LEFT, 224);}else{myGLCD.setColor(255, 0, 0);myGLCD.print("BUFFER FULL!", CENTER, 192);delay(500);myGLCD.print(" ", CENTER, 192);delay(500);myGLCD.print("BUFFER FULL!", CENTER, 192);delay(500);myGLCD.print(" ", CENTER, 192);myGLCD.setColor(0, 255, 0);}}// Draw a red frame while a button is touchedvoid waitForIt(int x1, int y1, int x2, int y2){myGLCD.setColor(255, 0, 0);myGLCD.drawRoundRect (x1, y1, x2, y2);while (myTouch.dataAvailable())myTouch.read();myGLCD.setColor(255, 255, 255);myGLCD.drawRoundRect (x1, y1, x2, y2);}/*************************** Required functions ***************************/void setup(){// Initial setupmyGLCD.InitLCD();myGLCD.clrScr();myTouch.InitTouch();myTouch.setPrecision(PREC_MEDIUM);myGLCD.setFont(BigFont);myGLCD.setBackColor(0, 0, 255);drawButtons();}void loop(){while (true){if (myTouch.dataAvailable()){myTouch.read();x=myTouch.getX();y=myTouch.getY();if ((y>=10) && (y<=60)) // Upper row{if ((x>=10) && (x<=60)) // Button: 1{waitForIt(10, 10, 60, 60);updateStr("1");}if ((x>=70) && (x<=120)) // Button: 2{waitForIt(70, 10, 120, 60);updateStr("2");}if ((x>=130) && (x<=180)) // Button: 3{waitForIt(130, 10, 180, 60);updateStr("3");}if ((x>=190) && (x<=240)) // Button: 4{waitForIt(190, 10, 240, 60);updateStr("4");}if ((x>=250) && (x<=300)) // Button: 5{waitForIt(250, 10, 300, 60);updateStr("5");}}if ((y>=70) && (y<=120)) // Center row{if ((x>=10) && (x<=60)) // Button: 6{waitForIt(10, 70, 60, 120);updateStr("6");}if ((x>=70) && (x<=120)) // Button: 7{waitForIt(70, 70, 120, 120);updateStr("7");}if ((x>=130) && (x<=180)) // Button: 8{waitForIt(130, 70, 180, 120);updateStr("8");}if ((x>=190) && (x<=240)) // Button: 9{waitForIt(190, 70, 240, 120);updateStr("9");}if ((x>=250) && (x<=300)) // Button: 0{waitForIt(250, 70, 300, 120);updateStr("0");}}if ((y>=130) && (y<=180)) // Upper row{if ((x>=10) && (x<=150)) // Button: Clear{waitForIt(10, 130, 150, 180);stCurrent[0]="\0";stCurrentLen=0;myGLCD.setColor(0, 0, 0);myGLCD.fillRect(0, 224, 319, 239);}if ((x>=160) && (x<=300)) // Button: Enter{waitForIt(160, 130, 300, 180);if (stCurrentLen>0){for (x=0; x

#include #include #include //==== Creating ObjectsUTFT myGLCD(SSD1289,38,39,40,41); //Parameters should be adjusted to your Display/Schield modelUTouch myTouch( 6, 5, 4, 3, 2);//==== Defining Fontsextern uint8_t SmallFont[];extern uint8_t BigFont[];extern uint8_t SevenSegNumFont[];extern unsigned int bird01[0x41A]; // Bird Bitmapint x, y; // Variables for the coordinates where the display has been pressed// Floppy Birdint xP = 319;int yP = 100;int yB = 50;int movingRate = 3;int fallRateInt = 0;float fallRate = 0;int score = 0;int lastSpeedUpScore = 0;int highestScore;boolean screenPressed = false;boolean gameStarted = false;void setup() {// Initiate displaymyGLCD.InitLCD();myGLCD.clrScr();myTouch.InitTouch();myTouch.setPrecision(PREC_MEDIUM);highestScore = EEPROM.read(0); // Read the highest score from the EEPROMinitiateGame(); // Initiate the game}void loop() {xP=xP-movingRate; // xP - x coordinate of the pilars; range: 319 - (-51)drawPilars(xP, yP); // Draws the pillars// yB - y coordinate of the bird which depends on value of the fallingRate variableyB+=fallRateInt;fallRate=fallRate+0.4; // Each inetration the fall rate increase so that we can the effect of acceleration/ gravityfallRateInt= int(fallRate);// Checks for collisionif(yB>=180 || yB<=0){ // top and bottomgameOver();}if((xP<=85) && (xP>=5) && (yB<=yP-2)){ // upper pillargameOver();}if((xP<=85) && (xP>=5) && (yB>=yP+60)){ // lower pillargameOver();}// Draws the birddrawBird(yB);// After the pillar has passed through the screenif (xP<=-51){xP=319; // Resets xP to 319yP = rand() % 100+20; // Random number for the pillars heightscore++; // Increase score by one}//==== Controlling the birdif (myTouch.dataAvailable()&& !screenPressed) {fallRate=-6; // Setting the fallRate negative will make the bird jumpscreenPressed = true;}// Doesn"t allow holding the screen / you must tap itelse if ( !myTouch.dataAvailable() && screenPressed){screenPressed = false;}// After each five points, increases the moving rate of the pillarsif ((score - lastSpeedUpScore) == 5) {lastSpeedUpScore = score;movingRate++;}}// ===== initiateGame - Custom Functionvoid initiateGame() {myGLCD.clrScr();// Blue backgroundmyGLCD.setColor(114, 198, 206);myGLCD.fillRect(0,0,319,239);// GroundmyGLCD.setColor(221,216,148);myGLCD.fillRect(0, 215, 319, 239);myGLCD.setColor(47,175,68);myGLCD.fillRect(0, 205, 319, 214);// TextmyGLCD.setColor(0, 0, 0);myGLCD.setBackColor(221, 216, 148);myGLCD.setFont(BigFont);myGLCD.print("Score:",5,220);myGLCD.setFont(SmallFont);myGLCD.print("HowToMechatronics.com", 140, 220);myGLCD.setColor(0, 0, 0);myGLCD.setBackColor(114, 198, 206);myGLCD.print("Highest Score: ",5,5);myGLCD.printNumI(highestScore, 120, 6);myGLCD.print(">RESET<",255,5);myGLCD.drawLine(0,23,319,23);myGLCD.print("TAP TO START",CENTER,100);drawBird(yB); // Draws the bird// Wait until we tap the sreenwhile (!gameStarted) {if (myTouch.dataAvailable()) {myTouch.read();x=myTouch.getX();y=myTouch.getY();// Reset higest scoreif ((x>=250) && (x<=319) &&(y>=0) && (y<=28)) {highestScore = 0;myGLCD.setColor(114, 198, 206);myGLCD.fillRect(120, 0, 150, 22);myGLCD.setColor(0, 0, 0);myGLCD.printNumI(highestScore, 120, 5);}if ((x>=0) && (x<=319) &&(y>=30) && (y<=239)) {gameStarted = true;myGLCD.setColor(114, 198, 206);myGLCD.fillRect(0, 0, 319, 32);}}}// Clears the text "TAP TO START" before the game startmyGLCD.setColor(114, 198, 206);myGLCD.fillRect(85, 100, 235, 116);}// ===== drawPlillars - Custom Functionvoid drawPilars(int x, int y) {if (x>=270){myGLCD.setColor(0, 200, 20);myGLCD.fillRect(318, 0, x, y-1);myGLCD.setColor(0, 0, 0);myGLCD.drawRect(319, 0, x-1, y);myGLCD.setColor(0, 200, 20);myGLCD.fillRect(318, y+81, x, 203);myGLCD.setColor(0, 0, 0);myGLCD.drawRect(319, y+80, x-1, 204);}else if( x<=268) {// Draws blue rectangle right of the pillarmyGLCD.setColor(114, 198, 206);myGLCD.fillRect(x+51, 0, x+60, y);// Draws the pillarmyGLCD.setColor(0, 200, 20);myGLCD.fillRect(x+49, 1, x+1, y-1);// Draws the black frame of the pillarmyGLCD.setColor(0, 0, 0);myGLCD.drawRect(x+50, 0, x, y);// Draws the blue rectangle left of the pillarmyGLCD.setColor(114, 198, 206);myGLCD.fillRect(x-1, 0, x-3, y);// The bottom pillarmyGLCD.setColor(114, 198, 206);myGLCD.fillRect(x+51, y+80, x+60, 204);myGLCD.setColor(0, 200, 20);myGLCD.fillRect(x+49, y+81, x+1, 203);myGLCD.setColor(0, 0, 0);myGLCD.drawRect(x+50, y+80, x, 204);myGLCD.setColor(114, 198, 206);myGLCD.fillRect(x-1, y+80, x-3, 204);}// Draws the scoremyGLCD.setColor(0, 0, 0);myGLCD.setBackColor(221, 216, 148);myGLCD.setFont(BigFont);myGLCD.printNumI(score, 100, 220);}//====== drawBird() - Custom Functionvoid drawBird(int y) {// Draws the bird - bitmapmyGLCD.drawBitmap (50, y, 35, 30, bird01);// Draws blue rectangles above and below the bird in order to clear its previus statemyGLCD.setColor(114, 198, 206);myGLCD.fillRoundRect(50,y,85,y-6);myGLCD.fillRoundRect(50,y+30,85,y+36);}//======== gameOver() - Custom Functionvoid gameOver() {delay(3000); // 1 second// Clears the screen and prints the textmyGLCD.clrScr();myGLCD.setColor(255, 255, 255);myGLCD.setBackColor(0, 0, 0);myGLCD.setFont(BigFont);myGLCD.print("GAME OVER", CENTER, 40);myGLCD.print("Score:", 100, 80);myGLCD.printNumI(score,200, 80);myGLCD.print("Restarting...", CENTER, 120);myGLCD.setFont(SevenSegNumFont);myGLCD.printNumI(2,CENTER, 150);delay(1000);myGLCD.printNumI(1,CENTER, 150);delay(1000);// Writes the highest score in the EEPROMif (score > highestScore) {highestScore = score;EEPROM.write(0,highestScore);}// Resets the variables to start position valuesxP=319;yB=50;fallRate=0;score = 0;lastSpeedUpScore = 0;movingRate = 3;gameStarted = false;// Restart gameinitiateGame();}

cte tft lcd sd shield for arduino brands
