Liquid crystal displays (LCD) have become an essential component to the industry of display technology. Involved in a variety of contexts beyond the indoors like LCD TVs and home/office automation devices, the LCD has expanded its usage to many environments, such as cars and digital signage, and, thus, many temperature variations as well.

As with any substance that requires a specific molecular characteristic or behavior, LCDs have an operating temperature range in which the device, if within, can continue to function properly and well. In addition to that, there is also an ideal storage temperature range to preserve the device until used.

This operating temperature range affects the electronic portion within the device, seen as falling outside the range can cause LCD technology to overheat in hot temperatures or slow down in the cold. As for the liquid crystal layer, it can deteriorate if put in high heat, rendering it and the display itself defective.

In order for the LCD panel to avoid defects, a standard commercial LCD’s operation range and storage range should be kept in mind. Without adaptive features, a typical LCD TV has an operating range from its cold limit of 0°C (32°F) to its heat limit of 50°C (122°F) (other LCD devices’ ranges may vary a bit from these numbers).

The storage range is a bit wider, from -20°C (-4°F) to 60°C (140°F). Though these ranges are quite reasonable for many indoor and even outdoor areas, there are also quite a few regions where temperatures can drop below 0°C or rise above 32°C, and in these conditions, LCDs must be adapted to ensure functionality.

Heat, can greatly affect the electronics and liquid crystals under an LCD screen. In consideration of heat, both external heat and internally generated heat must be taken into consideration.

Seen as the liquid crystals are manipulated in a device by altering their orientations and alignments, heat can disrupt this by randomizing what is meant to be controlled. If this happens, the LCD electronics cannot command a certain formation of the liquid crystal layer under a pixel, and the LED backlighting will not pass through as expected, which can often lead to dark spots, if not an entirely dark image. This inevitably disrupts the display’s readability.

Depending on the upper limit of the operation temperature range, LCD device can be permanently damaged by extreme heat. With long exposure to extreme heat, besides the destruction of the liquid crystals, battery life can shorten, hardware can crack or even melt, response time may slow to prevent even more heat generation from the device.

The LED backlight and the internal circuitry, typically TFT-based in the common TFT LCDs, are components that can generate heat that damages the device and its display. To address this concern with overheating, many devices use cooling fans paired with vents.

Some devices that are used in extremely high ambient temperatures may even require air conditioning. With air vents to carry the heat out, the device can expel it into the surroundings.

But this leads to another problem: how can moisture be prevented from entering through the vent? If moisture enters the device and high heat is present, condensation can occur, fogging the display from inside, and in some cases, short-circuiting may cause the device to turn off. In order to circumvent this issue, the shapes of the air vents are specific in a way that allows only for air movement, not forms of moisture.

In the opposite direction is extreme cold. What typically occurs in the cold is “ghosting” (the burning of an image in the screen through discoloration) and the gradual slowing and lagging of response times. Like heat-affected LCD modules, the extreme temperature can affect the liquid crystals. This layer is a medium between the liquid and solid state, so it is still susceptible to freezing.

An LCD device can be left in freezing temperatures because it will likely not be permanently damaged like in the heat, but it is important to understand the device’s limits and how to take precautions when storing the device. The standard and most common lower-bound storage range limit is -20°C, below freezing, but if possible, it would be best to keep it above that limit, or else there is still a risk of permanent damage.

If the device is not adapted for the cold, it would be good to keep it bundled up, trapping the heat within layers. However, this is only a temporary solution. Adapted, rugged devices have advantages such as screen enclosure insulation for heat level preservation and, in more extreme cases, heaters to generate extra heat to raise the internal temperature to a level above the minimum.

When selecting the appropriate module, it is necessary to understand the device’s expected primary application. The application will decide factors such as display type, environmental conditions, whether or not power consumption is a factor, and the balance between performance and cost. These factors can have an effect on the operation and storage temperature ranges for the device.

Display types have a lot of variation. Choices like alphanumeric or graphic LCD, human-machine interactive LCD modules and touchscreen panels capabilities, the width of the viewing angle, level of contrast ratios, types of backlighting, and liquid crystal alignment methods are often considered. For example, the twisted nematic LCD provides for the fastest response time at the lowest cost, but cannot offer the highest contrast ratio or widest viewing angle.

Environment-based factors must consider things besides the obvious temperature like UV exposure and humidity/moisture, as they all are necessary in finding the perfect fit extreme temperature LCD module.

Besides the LCD modules, recent new products have opened doors in wide temperature range displays, such as OLED displays. OLED displays offer better displays in regard to contrast, brightness, response times, viewing angles, and even power consumption in comparison to traditional LCD displays.

These benefits, in addition to its ability to achieve a wide temperature range, provide more options for consumers in search of high quality displays for extreme climates.

Every new motorhome and most new 5th wheel and travel trailers have at least one LCD TV. Many have 2 or more.  The bigger LCD TVs on board RVs and motorhomes have 40-inch screens (or larger).

Today’s technology has come to the point where, for the most part, you will find LCD (or Liquid Crystal Display televisions) being installed almost exclusively in new recreational vehicles.

LCDs are a great choice inside RVs for a number of reasons.  For one, the picture quality is very good.  Plus, they’re not big and bulky like the TVs of yesterday. In fact, some are so thin you can actually mount them on the wall like a picture. LCD flat-screen TVs are even being mounted on motorized bases that retract up flush to the ceiling when not in use.

There is a liquid-based material within the screen of LCD TVs.  Will it be damaged overnight in freezing weather?  Worse yet, if left in storage through the winter in the northern states where temperatures can get bitterly cold, will an LCD flat-screen TV survive?

This means that if your LCD TV is kept in an environment below this range, you must allow it at least 24 hours to acclimate to the proper operating range before you plug it in or turn it on.

When something cold is brought into a warm environment, condensation (or moisture) will be present throughout the device.  Plugging it in or turning it on could result in short circuits, shock, or other catastrophic failure of the unit. If the LCD screen is chilled, even though not frozen, it could fail as well.

Manufacturer limitations on cold storage of their LCD TVs varies all over the map.  Some are rated to handle temps as low as -15F to -20F below zero, while others are barely rated to be stored anywhere near the zero mark.

I was unable to find a single supplier of LCD televisions that would stand behind their product when stored in temperatures lower then the -20F below zero mark.

I live in Minnesota. International Falls, MN is well known as “the ice box of the nation.”  During the very long winter months, temperatures drop to a -40F below quite often. I’ve personally experienced -60F below temperatures, though admittedly only once in my lifetime.

You can remove your LCD televisions from the RV (and I would consider removing VCRs, DVDs, and satellite receivers too), and store them indoors in warmer temperatures.

Typically, standard LCD modules provide a temperature range of -20°C to +70°C. To meet the need of customers, EVERVISION has developed a series of wide temperature TFT LCD modules with operating temperatures ranging from -30°C to +80°C, and the maximum for some models can reach 85°C.

EVERVISION developed LCD Heater to integrate with our TFT Display Module so that can show optimal view even in low temperature. For materials, heaters can be used with transparent resins, such as glass and poly-carbonate. Our LCD Transparent Heater is made of glass substrate, so we name it “Glass Heater”. It can not only improve the LCD image sticking issue efficiently, but also have heat and humidity resistance advantage.

As the result, it shows 4.3 inch TFT LCD Module display functionally under normal operating conditions. However, there is an overlapping at low temperature, because of LC"s physical characteristics. From this experiment, we know that overlapping can be solved by turning on Glass Heater.

The use of liquid crystal displays (LCDs) in user interface assemblies is widespread across nearly all industries, locations, and operating environments. Over the last 20 years, the cost of LCD displays has significantly dropped, allowing for this technology to be incorporated into many of the everyday devices we rely on.

The odds are high you are reading this blog post on a laptop or tablet, and it’s likely the actual screen uses LCD technology to render the image onto a low-profile pane of glass. Reach into your pocket. Yes, that smartphone likely uses LCD technology for the screen. As you enter your car, does your dashboard come alive with a complex user interface? What about the menu at your favorite local drive-thru restaurant? These are some everyday examples of the widespread use of LCD technology.

But did you know that the U.S. military is using LCD displays to improve the ability of our warfighters to interact with their equipment? In hospitals around the world, lifesaving medical devices are monitored and controlled by an LCD touchscreen interface. Maritime GPS and navigation systems provide real-time location, heading, and speed information to captains while on the high seas. It’s clear that people’s lives depend on these devices operating in a range of environments.

As the use of LCDs continues to expand, and larger screen sizes become even less expensive, one inherent flaw of LCDs remains: LCD pixels behave poorly at low temperatures. For some applications, LCD displays will not operate whatsoever at low temperatures. This is important because for mil-aero applications, outdoor consumer products, automobiles, or anywhere the temperature is below freezing, the LCD crystal’s performance will begin to deteriorate. If the LCD display exhibits poor color viewing, sluggish resolution, or even worse, permanently damaged pixels, this will limit the ability to use LCD technologies in frigid environments. To address this, there are several design measures that can be explored to minimize the impact of low temperatures on LCDs.

Most LCD displays utilize pixels known as TFT (Thin-Film-Transistor) Color Liquid Crystals, which are the backbone to the billions of LCD screens in use today. Since the individual pixels utilize a fluid-like crystal material as the ambient temperature is reduced, this fluid will become more viscous compromising performance. For many LCD displays, temperatures below 0°C represent the point where performance degrades.

Have you tried to use your smartphone while skiing or ice fishing? What about those of you living in the northern latitudes - have you accidently left your phone in your car overnight where the temperatures drop well below freezing? You may have noticed a sluggish screen response, poor contrast with certain colors, or even worse permanent damage to your screen. While this is normal, it’s certainly a nuisance. As a design engineer, the goal is to select an LCD technology that offers the best performance at the desired temperature range. If your LCD display is required to operate at temperatures below freezing, review the manufacturer’s data sheets for both the operating and storage temperature ranges. Listed below are two different off-the-shelf LCD displays, each with different temperature ratings. It should be noted that there are limited options for off-the-shelf displays with resilience to extreme low temperatures.

For many military applications, in order to comply with the various mil standards a product must be rated for -30°C operational temperature and -51°C storage temperature. The question remains: how can you operate an LCD display at -30°C if the product is only rated for -20°C operating temperature? The answer is to use a heat source to raise the display temperature to an acceptable range. If there is an adjacent motor or another device that generates heat, this alone may be enough to warm the display. If not, a dedicated low-profile heater is an excellent option to consider.

Made of an etched layer of steel and enveloped in an electrically insulating material, a flat flexible polyimide heater is an excellent option where space and power are limited. These devices behave as resistive heaters and can operate off a wide range of voltages all the way up to 120V. These heaters can also function with both AC and DC power sources. Their heat output is typically characterized by watts per unit area and must be sized to the product specifications. These heaters can also be affixed with a pressure sensitive adhesive on the rear, allowing them to be “glued” to any surface. The flying leads off the heater can be further customized to support any type of custom interconnect. A full-service manufacturing partner like Epec can help develop a custom solution for any LCD application that requires a custom low-profile heater.

With no thermal mass to dissipate the heat, polyimide heaters can reach temperatures in excess of 100°C in less than a few minutes of operation. Incorporating a heater by itself is not enough to manage the low temperature effects on an LCD display. What if the heater is improperly sized and damages the LCD display? What happens if the heater remains on too long and damages other components in your system? Just like the thermostat in your home, it’s important to incorporate a real-temp temperature sensing feedback loop to control the on/off function of the heater.

The first step is to select temperature sensors that can be affixed to the display while being small enough to fit within a restricted envelope. Thermistors, thermocouples, or RTDs are all options to consider since they represent relatively low-cost and high-reliability ways to measure the display’s surface temperature. These types of sensors also provide an electrical output that can be calibrated for the desired temperature range.

The next step is to determine the number of temperature sensors and their approximate location on the display. It’s recommended that a minimum of two temperature sensors be used to control the heater. By using multiple sensors, this provides the circuit redundancy and allows for a weighted average of the temperature measurement to mitigate non-uniform heating. Depending on the temperature sensors location, and the thermal mass of the materials involved, the control loop can be optimized to properly control the on/off function of the heater.

Another important consideration when selecting a temperature sensor is how to mount the individual sensors onto the display. Most LCD displays are designed with a sheet metal backer that serves as an ideal surface to mount the temperature sensors. There are several types of thermally conductive epoxies that provide a robust and cost-effective way to affix the delicate items onto the display. Since there are several types of epoxies to choose from, it’s important to use a compound with the appropriate working life and cure time.

For example, if you are kitting 20 LCD displays and the working life of the thermal epoxy is 8 minutes, you may find yourself struggling to complete the project before the epoxy begins to harden.

Before building any type of prototype LCD heater assembly, it’s important to carefully study the heat transfer of the system. Heat will be generated by the flexible polyimide heater and then will transfer to the LCD display and other parts of the system. Although heat will radiate, convect, and be conducted away from the heater, the primary type of heat transfer will be through conduction. This is important because if your heater is touching a large heat sink (ex. aluminum chassis), this will impact the ability of the heater to warm your LCD display as heat will be drawn toward the heat sink.

Insulating materials, air gaps, or other means can be incorporated in the design to manage the way heat travels throughout your system on the way toward an eventual “steady state” condition. During development, prototypes can be built with numerous temperature sensors to map the heat transfer, allowing for the optimal placement of temperature sensors, an adequately sized heater, and a properly controlled feedback loop.

Before freezing the design (no pun intended) on any project that requires an LCD display to operate at low temperatures, it’s critical to perform low temperature first. This type of testing usually involves a thermal chamber, a way to operate the system, and a means to measure the temperature vs time. Most thermal chambers provide an access port or other means to snake wires into the chamber without compromising performance. This way, power can be supplied to the heater and display, while data can be captured from the temperature sensors.

The first objective of the low-temperature testing is to determine the actual effects of cold exposure on the LCD display itself. Does the LCD display function at cold? Are certain colors more impacted by the cold than others? How sluggish is the screen? Does the LCD display performance improve once the system is returned to ambient conditions? These are all significant and appropriate questions and nearly impossible to answer without actual testing.

As LCD displays continue to be a critical part of our society, their use will become even more widespread. Costs will continue to decrease with larger and larger screens being launched into production every year. This means there will be more applications that require their operation in extreme environments, including the low-temperature regions of the world. By incorporating design measures to mitigate the effects of cold on LCD displays, they can be used virtually anywhere. But this doesn’t come easy. Engineers must understand the design limitations and ways to address the overarching design challenges.

A full-service manufacturing partner like Epec offers a high-value solution to be able to design, develop, and manufacture systems that push the limits of off-the-shelf hardware like LCD displays. This fact helps lower the effective program cost and decreases the time to market for any high-risk development project.

Malfunction alarms including high and low temperature, power failure, sensor error, clean-filter, and extremely high ambient, abnormal voltage, thermostat failure, low battery, condenser clean, door ajar.

Independent equipment CO2 back up system, LN2 back up system a backup refrigeration system for Ultra-Low Temperature Freezer failures and power outages.

Adjust the solenoid Valve"s On-off according to its own temperature control probe.A liquid nitrogen tank or liquid carbon dioxide tank that is connected by a solenoid valve as a Reserve.

Just like when your glasses will fog up when you come in from cold weather, moisture will build on surfaces inside the plant when temperatures go from very cold to very warm. Electronics that suffer this build-up of moisture can have failures related to corrosion. One way to prevent a moisture related failure is waiting a few hours before powering on electronics that have been kept in cold weather after a warm up has occurred. This will allow any condensation to dry before electricity is conducted.

While normally a cool environment is preferable to a warm one when it comes to keeping your electronics up and running, if it gets too cold, certain components can suffer sudden failure. For instance, LCD screens contain fluid and at extreme temperatures can freeze. If you live in the extreme north where temperatures can get into the negatives, it is important to understand the failure limits of your devices which should be available in the manual when you purchase the device. In addition, any electronics that rely on movement such as motors, disk drives, servo valves etc., can suffer failure from the cold. As the temperature drops, metal contracts making moving parts run under higher load stress which can cause the part to fail.

You’ve left your TV in your unheated garage this winter, and temperatures reached below zero. When you finally return, you’re about to turn on the TV, but something stops you.

If you live in a place with cold, icy winters, it’s best to store your TV inside your heated home, rather than leaving it in your humid, below-freezing garage or basement.

If you’re thinking of mounting your TV in your garage, it’s best to monitor the temperature and humidity levels to make sure it’s a safe environment for your TV.

This Haozee Smart WiFi Temperature and Humidity Monitor connects to an app on your phone, so you can monitor how cold and humid your garage gets at night without having to get out of bed and check it yourself.

Instead, bring your TV inside your home and let it come back down to room temperature. This will give the metal components time to expand back to their original size. It will also allow any condensation to evaporate.

Extremely cold temperatures could severely damage your TV, leading to hundreds of dollars worth of repairs. In the worst-case scenario, you may even have to purchase a replacement.

Putting infested items in a freezer can kill bed bugs if some particular conditions are met. Freezing causes ice to form inside the bed bug, causing injury or death. Freezing bed bugs is easy to do. All it requires is:

If you are worried about ensuring that temperatures are low enough, use a remote thermometer and monitor the temperature inside the items you are freezing.

Unfortunately, no. It is unlikely that it will be cold enough for long enough to kill bed bugs. Sunlight, humidity, temperature variations during the day increase the risk that bed bugs will survive. DO NOT attempt to freeze your apartment or house by opening the windows and turning off the heat. There is a major risk that structural damage will occur and you will not kill the bed bugs.

For additional information on using freezing conditions to kill bed bugs please see this paper: Cold Tolerance of Bed Bugs and Practical Recommendations for Control

Unique 3 year freeze indicator with clear indication of pass/reject on LCD display.  In the event that temperature sensitive products guarded by the free indicator are subjected to a ‘reject’ event, details leading up to, during and after the event can be extracted using the optional TICT/TIC20 interface. Evidence of compliance is established when saving summary data using the TICT/TIC20 interface (optional)

The LogTag® TICT iS0°Tag® is a tamper-proof electronic indicator which shows if the temperature has been at or below freezing point (0°C or 32°F) for 60 minutes or more.

While the temperature remains above freezing point, the display shows a tick symbol. If the temperature drops below freezing point for 60 minutes or more, the display shows a cross symbol, which cannot be reset or deleted.

The TICT iS0°Tag® can be used to monitor the temperature of any freeze-sensitive product such as vaccine, food, or specialty chemicals for up to 3 years.

It"s that time of year when it is so bitterly freezing that even a 30-degree day can feel like a balmy respite. Temperatures plummet into the single digits, wind chills are painful and dangerous. It"s cold outside.

Few places in the U.S. know cold better than Alaska, and James Grant, who owns Right Choice Automotive Repair in Fairbanks, has seen a bit of what frigid temperatures can do to vehicles. We talked with Grant as well as the Car Care Council to find out how the cold can affect cars and trucks and hear about any possible solutions.

Solution:Granted, driving the EV isn"t the problem, but cold weather does impact an EV"s efficiency and performance. Low temperatures slow the battery chemistry, resulting in less energy for acceleration. It takes more energy to keep the battery at an efficient operating temperature, and a little more energy still to keep the cabin (and you) warm. All of this results in less efficient performance, which means you might not have as much range as you think. That"s an important consideration if you don"t want to end up walking in the cold. In 2018, we ran a Chevy Bolt EV in cold weather to compare against a 2017 test we did in nearly ideal conditions. The result was a 19 percent drop in efficiency. Got more questions about EVs? We have answers.

Solution:The Car Care Council recommends switching to low-viscosity oil in the winter. "Synthetic oils will help out a great deal," Grant noted. Don"t forget to read your owner"s manual, as the manufacturer may specify an oil weight for cold-weather operation. Synthetics can provide better startup performance and flow at temperatures down to -40 Fahrenheit.

Unless you live somewhere where the temperature gets down to 100 degrees below zero, the gasoline in your car will not freeze. However, water moisture in the gas lines can become icy. "In regard to fuel, one of the things we do see, if there"s any water content inside the fuel tank, that water can freeze and clog fuel pickup," Grant said.

If your car has liquid crystal display (LCD) screens, such as for infotainment, you may notice that they become a bit sluggish when the car has been sitting in extreme cold. That"s because, just like the engine"s oil and the battery"s electrolyte, molecules in liquid crystals slow down when the temperatures drop.

Sub-freezing temperatures can cause the rubber on windshield wiper blades to become brittle, which means it could tear or crack. Also, some washer fluid may not work as well in colder months.

It may be a bit late to hand out this advice this year, but for future reference, the Car Care Council recommends taking your car or truck in for an inspection before winter hits so you can stave off the above problems ahead of time. "Vehicles need extra attention when temperatures drop below zero," executive director Rich White points out. "Whether consumers perform an inspection and required maintenance themselves or go to a repair shop, it"s a small yet important investment to avoid the aggravation and unexpected and potentially dangerous cost of a breakdown in freezing weather."
