iphone 7 lcd screen repair cost made in china

These affected units were manufactured between September 2016 and February 2018 and sold in China mainland, Hong Kong, Japan, Macao, and the U.S. See below for iPhone 7 model numbers that are covered in this program.

If your device exhibits the symptom described above, Apple will repair your device, free of charge. Your iPhone will be examined prior to any service to verify that it is eligible for this program. This program only applies to iPhone 7.

Apple will be contacting customers via email who may have paid for a repair related to this issue to arrange for reimbursement. If you believe you paid for a repair related to this issue, and have not received an email from Apple by the end of March 2018, please contact Apple.

After replacing the screen, I noticed that the iPhone performance (ios 11.4.1 - latest one) is not the same as it was before. It’s not that bad but the difference between before and not is obvious. The phone doesn’t crash or doesn’t need long to open apps, or the performance is not 1sec behind as some people complain. It’s just working little bit slower (juddery).

Not too long ago, we’ve just got some samples of the new China Made iPhone 6 LCD Display. No doubt that this will be another option for all who are suffering from the high price of the iPhone screens. Let’s take a deep look of these screens.

At the moment, there are two companies producing the iPhone 6 LCD screens, one is LT, the other one is JDF (no iPhone 6 screens made by TM are available now). Below are some detailed comparisons after our tests.

When taking a closer look at both of the LT and JDF iPhone 6 screens under direct light, you’ll see the digitizer textures. While for the original screen, the textures had been hidden by a special painted layer.

The glass lens of LT made iPhone 6 screen is far too thin compared with the original one, which can’t secure the display well. At the same time, thinner glass lens will make the home button stick up above the screen. While for the JDF made the screen, a plastic layer has been added to make it thicker.

It’s hard to be realized through eyes, but it’s easily to be touched. When you grab the iPhone 6 with LT made screen, it’s hard to ignore that annoying uncomfortable feeling. At this point, the JDF made screen is much better.

High and low temperature tests have been applied to both the LT and JDF iPhone 6 screens. Both of them have survived and worked well after been putted in a 55 centi degrees room for 2 hours and -5 centi degrees room for 2 hours.

Through our tests, the first version of both the LT and JDF displays are not good choices for the repair industry. The obvious color differences, thickness differences still need to be improved. If you have any questions regarding the LT/JDF iPhone 6 screens, please leave your comment below, we’ll try our best to answer it.

In addition to this, though SC which was vigorously supported by Foxconn had been performing mass production for LTPS, TFT, LCD displays at the beginning of 2012, did not make a great progress for the reason that SC failed to neither win over the Apple iPhone orders and nor get authorization in CG Si and IGZO technology of Sharp.

But do you know which iPhone 6 LCD made by these three display penal manufacturers is more cost-effective? Let’s go on with this article and sort things out. Not too long ago, REWA has analyzed the JDF(BOE) and LT(IVO) China made iPhone 6 LCDs in some ways. After several months’ development, how is the situation now? We have tested 3 mainstream China-made iPhone 6 LCDs by JDF(BOE ), TM(Tianma) and SC from aspects of “Appearance” and “Function” in order to make a comparison with OEM ones and give us clarity of thought.

After installed in the mobile devices, it’s much easy for us to find that all these three China made LCDs have a small gap between the LCD and device body, especially SC.

It can be observed visually that LCD Display and Touchscreen digitizer flex cable made by JDF, TM and SC are different in texture. 5) Structure Generally speaking, there are two kinds of mainstream cell phone display constructions of formation, “G+G” and “In-cell”.

Compared with the In-cell structure of OEM LCD, JDF, TM and SC which use G+G touch screen display technology thus cause their overall thickness greater than the OEM ones.

Testing Touch screen digitizer by moving the app icon in all directions including swiping from the edge of the screen, JDF, TM and SC display have no problems with touch function.

Testing LCD display in the pure color of gray, white and black, a part of JDF, TM and SC LCDs have somewhat degree problems of backlight leakage, but it does not affect the normal use and can be ignored in a certain sense. Note: The severity of this problem in the actual situation is a lot more slight than the captured pictures above.

After playing video for 72 hours, JDF, TM, SC have no obvious differences with the OEM ones. CONCLUSION From a series of tests we can find there are only a few differences between OEM display and China made LCDs. In terms of quality, JDF & TM are better than SC. For Price, JDF is more favorable than TM. Therefore, on the market condition that OEM LCDs being out of stock, JDF LCD is the most cost-effective choice for you. Want to order our products? Please contact us: PRE-SALES Skype: rewatech Email: service@rewa.tech AFTER-SALES Skype: support-rewatech Email: support@rewatechnology.com And you can also check our repair guides：

SIQI TECHNOLOGY CO., LIMITED is a professional wholesaler & exporter for top selling cell phone brand repair parts and accessories in Shenzhen, China since 2012.

We mainly provide iPhone, iPad, Samsung, etc famous brand parts, covering the LCD displays, touch screen digitizers, glass lenses, back cover, flex cable, vibrator, speaker, back and front cameras, accessories, etc.

I built a like-new (but really refurbished) iPhone 6S 16GB entirely from parts I bought in the public cell phone parts markets of Huaqiangbei. And it works!I’ve been fascinated by the cell phone parts markets in Shenzhen, China for a while. I’d walked through them a bunch of times, but I still didn’t understand basic things, like how they were organized or who was buying all these parts and what they were doing with them.

You might wonder why I chose to make an iPhone 6s and not an iPhone 7. I had two reasons. The first was that I already own an iPhone 6s that I bought in an Apple store, and I thought I might end up needing to have an identical phone to the one I was trying to build that I knew was assembled by Apple to compare against. In the end, this was never really an issue, and I never ended up having to open it up. It is nice to be able to show people the phone I built side-by-side with a phone bought in an Apple store though.

However, the other reason, which turned out to be far more important, is that iPhone 7 parts are pretty hard to come by in the markets. It’s not totally clear why this is, but I have some ideas. A lot of the parts come from recycled/broken phones, and so it would make sense that there just isn’t that much supply yet. I also think there’s probably really high demand for iPhone 7 parts, so what parts are available may get traded before they make it out into display cases. In some cases, even iPhone 6s parts were a bit hard to come by (mostly the logic board). I keep asking people about this, and people keep saying things like “there should be more after Spring Festival” (which has come and gone) or “there should be more in a month or two – it’s just a temporary shortage right now”. I’ll keep my eyes out – it’ll be interesting to see how this evolves over time.

Logic board – This is like the motherboard in a computer. It’s the circuit board that has the processor, flash memory, wifi/cell chips, etc on it. Everything plugs into this. The one I bought is refurbished/repaired, almost undoubtedly from a real, legitimately purchased phone made by Apple that was recycled at some point.

It came with the touch id sensor, because the processor and touch id sensor are cryptographically paired. This means that touch id no longer works if you swap out the touch id sensor. This is for security reasons, to make it harder for someone to malicious bypass touch id to unlock your phone without your permission. But it’s a really crappy restriction when it comes to repairing/refurbishing phones.

Screen – I really wanted to assemble my own. But there were two issues – you need a bunch of bulky equipment and I had an incredibly hard time trying to buy a bare lcd/digitizer. You can get them apparently, but they don’t seem to be readily available over the counter in the markets. So instead, I bought a broken screen from a phone repair booth, and had them completely disassemble and then reassemble it with new parts, other than the lcd/digitizer.

A: I was hanging out with a bunch of open source hardware geeks in Shenzhen, loosely affiliated with Ian and Jin at Dangerous Prototypes. Someone mentioned that they’ve seen all these phone parts in the cell phone repair markets, and wondered if you could use them to build your own phone. I’d walked through the markets a bunch before, but I didn’t really understand much about them, or what all was happening there. But I was really curious about how it all fit together, and this seemed like a great excuse to dive deeper.

A: I bought them all from the cell phone repair markets in Huaqiangbei in Shenzhen, China. These are public wholesale markets that target cell phone repair businesses all over the world.

A: In the end, no, unless you count that special pentalobe screwdriver Apple insists on using for the two outside screws. Some of the kids in the market that do repair also have one really long fingernail they use for prying up connectors, but I haven’t gotten quite that hardcore yet.

Really just a couple screwdrivers and a pair of tweezers are pretty much all you need for the main assembly. The big exception is the screen – there’s lots of bulky and expensive specialty tools necessary to do the lamination, which is why I ended up going to a screen repair booth, rather than buy all the equipment myself.

A: I’ve spent over $1000 at this point, but a lot of it was duplicate parts I didn’t end up using and tools I didn’t end up needing. I’d estimate the cost of the actual parts that went into the phone at around $300, maybe a bit more (I wasn’t keeping perfect track).

A: I didn’t – it came preinstalled on the logic board. I believe that the logic board came out of a legitimate phone made by Apple. The seller did some repair work, but it still had iOS installed on the flash chip.

A: It’s very, very close. So close that the average person can’t tell the difference when comparing it side by side with the same model phone I bought in an Apple store. However, I also showed it to a Chinese friend who is studying to be a professional iPhone repair technician, and we spotted a couple minor but correctable cosmetic flaws. As far as functionality goes, it is completely comparable to the iPhone I bought in the Apple store, as far as anyone I’ve shown it to can tell.
