The component TFT supports a 2.8 inch TFT display with a resolution of 240*320 pixels.The display is not soldered on the board, but there is a 14 pin connector for a TFT display. The ILI9341 has been tested.

There are four sample projects for the Arduino IDE which could be downloaded: TFT-Box3D (download here), TFT-Graphic-Test (download here), TFT-HelloWorld (download here) and TFT-HowToUseFonts (download here). And there are two examples for the Arduino IDE for using the touch functionality which could be downloaded: TFT-TouchBtn (download here) and TFT-TouchDraw (download here).

There are two dip switches for the component: SW311 and SW314. If you want to use the TFT display all switches on SW311 have to be on on. If you additonally want to use the touchpad of the display all switch of SW314 have to be on. The following two tables shows the functions and the potential conflicts with other components

There are four sample projects for the Arduino IDE which could be downloaded: TFT-Box3D (download here), TFT-Graphic-Test (download here), TFT-HelloWorld (download here) and TFT-HowToUseFonts (download here).

And there are two examples for the Arduino IDE for using the touch functionality which could be downloaded: TFT-TouchBtn (download here) and TFT-TouchDraw (download here).

T-Display-S3 is a ESP32-S3 development board. It is equipped with a color 1.9" LCD screen and two programmable buttons. Communication using I8080 interface. Retains the same layout design as T-Display. You can directly use ESP32S3 for USB communication or programming.

In Arduino Preferences, on the Settings tab, enter the https://raw.githubusercontent.com/espressif/arduino-esp32/gh-pages/package_esp32_index.json URL in the Additional boards manager URLs input box.

Some settings, withing the TFT_eSPI library, need to be modified. A modified library is provided in this repository in the lib folder. Copy it to your Arduino library folder.
