5 inches tft lcd color monitor 480x272 made in china

※Price Increase NotificationThe TFT glass cell makers such as Tianma,Hanstar,BOE,Innolux has reduced or stopped the production of small and medium-sized tft glass cell from August-2020 due to the low profit and focus on the size of LCD TV,Tablet PC and Smart Phone .It results the glass cell price in the market is extremely high,and the same situation happens in IC industry.We deeply regret that rapidly rising costs for glass cell and controller IC necessitate our raising the price of tft display.We have made every attempt to avoid the increase, we could accept no profit from the beginning,but the price is going up frequently ,we"re now losing a lot of money. We have no choice if we want to survive. There is no certain answer for when the price would go back to the normal.We guess it will take at least 6 months until these glass cell and semiconductor manufacturing companies recover the production schedule. (Mar-03-2021)

All the accessories listed below tier pricing need to pay.We won"t deliver until you select. Power adaptor should be 5V/2000mA in output and center pin for positive voltage and the outer shield for negative voltage .The temperature for controller RTD2660 would increase during working.That"s normal phenomenon,not quality problem.

ER-TFTV050A1-1 is 480x272 dots 5" color tft lcd module display with small HDMI signal driver board,optional capacitive touch panel with USB controller board and cable and 4-wire resistive touch panel with USB driver board and cable, optional remote control,superior display quality,super wide view angle.It can be used in any embedded systems,car,industrial device,security and hand-held equipment which requires display in high quality and colorful video. It"s also ideal for Raspberry PI by HDMI.

We have now sophisticated machines. Our solutions are exported to the USA, the UK and so on, enjoying a great reputation amid consumers for Tft 5 Inch, Lcd Monitor Tft, In-Cell/On-Cell Touch Game Lcd Screen, Different Types Of Lcd,Liquid Crystal Display Panel. Through our hard work, we have always been on the forefront of clean technology product innovation. We are a green partner you can rely on. Contact us today for more information! The product will supply to all over the world, such as Europe, America, Australia,Seattle, Barcelona,Guatemala, Ghana.We have more than 10 years experience of production and export business. We always develop and design kinds of novel products to meet the market demand and help the guests continuously by updating our products. We are specialized manufacturer and exporter in China. Wherever you are, please join us, and together we will shape a bright future in your business field!

This LCD is a 480x272 pixel resolution IPS TFT display. The IPS technology delivers sunlight readable image quality with higher brightness, better color reproduction, image consistency and optical characteristics at any angle. This 24-bit true color Liquid Crystal Display includes better FPC design with EMI shielding on the cable. It also has a built-in SC7283 IC driver and offers the same mechanical footprint and pinout as the TN display. This TFT is RoHS compliant and does not include a touch panel.

Maclight 4.3 inch tft lcd have the standard resolution with 480x272 pixels and 800x480 pixels, regular RGB interface with ST7282, OTA5108, HX8257A IC driver, and custom made MCU interface with SSD1963, RA8875 series interface for difference application.

Our 4.3 inch tft lcd have standard working temperature and wide working temperature 4.3" lcd that can up to -30~+80 °c, The 4.3" lcds have standard viewing angle TN TFT LCD type ( 6 o"clock and 12 o"clock) and IPS tft lcd with full viewing angle.

Our 4.3" tft touch screen could combine with resistive touch screen (RTP) and capacitive touch screen( CTP / PCAP), to the 4.3" PCAP, air-gap bonding and optical bonding to the CTP is welcome to us. to the 4.3 inch capacitive touch, we could custom make the CTP cover glass up to 3mm thickness cover glass and anti-finger print, anti-glare surface treatment.

Maclight 4.3 inch tft lcd display is also including 4.3" sunlight readable tft lcd display with 1000 nits high brightness tft lcd, that is suitable for outdoor application.

1. Sizes: please confirm the display area sizes for the project, the typical 4.3" tft lcd display active area is around 95.04*53.86 mm (4.3" diagonal).

2. Resolution: Would the display used in landscape or portrait type, 4.3" tft lcds have 480RGB*272 and 800RGB*480 in landscape type, and 480RGB*800 in portrait type. if we choose the IPS lcd with full viewing angle, we could use the 480RGB*272 and 800RGB*480 landscape lcd, and rotate 90 degree, then turn to portrait 4.3" tft lcd as well.

4. Viewing angle: would the 4.3" lcd be viewed from top viewing or bottom viewing, or would require full viewing angle? Maclight have full viewing angle IPS 4.3 lcd, and 12 o"clock (top), 6 o"clock (bottom) viewing angle for optional.

5. Working environments: if the lcd screen is used indoor, you could choose the standard brightness than lower than 400cd/m2, if used in outdoor, we suggest to choose the tft lcd brightness higher than 500cd/m2, that can be sunlight readable.

7. IC drivers: 4.3" TFT lcd have tradition IC driver ILI6480B, HX8257A, and new ST7282 IC drivers, that can fit the 4.3 lcds from tft lcd manufacturers Innolux, Tianma, BOE, Hannstar etc, because 4.3" lcd is digital RGB interface, the IC driver is not matter when choosing a new 4.3" lcd, or a replacement for other 4.3" lcd.

8. Interface: The typical 4.3" tft lcd module interface is RGB interface, we could make it with MCU interface, and HDMI interface, that is compliance for mainly driver boards in the market.

Please contact us for more 4.3" tft lcd products, we still have many 4.3" lcd not on this list below, and we support custom make 4.3" tft lcd as well.

If you are seeking 4.3" tft lcd, Maclight could provide the one stop 4.3" lcd solution for you, best technical support, 12 months warranty time and after sale services, high quality, competitive price, and stable supply, Welcome to contact us for more 4.3" tft lcd display module information.

OLED(organic light-emitting diode is a light-emitting diode in which the emissive electroluminescent layer is a film of organic compound that emits light in response to an electric current. This organic layer is situated between two electrodes; typically, at least one of these electrodes is transparent. OLEDs are used to create digital displays in devices such as computer monitors, television screens, and portable systems such as smartphones and handheld game consoles.

TST050WQBS-44 belongs to Team Source Display 5 inch series products, which is a 5 inch color TFT liquid crystal display module with 480x272 resolution. This 5 inch transmissive lcd screen is made of TN glass, and was drive by ST7257 driver IC. This 5 inch TFT liquid crystal display support connected by RGB interface and show bright colors and brightness. The outline size of this 5 inch lcd display is 120.70x75.80x3.15mm and the active area size is 110.88x62.832 mm.

Team Source Display was established in 2004, it has been focusing on the R&D, production and sales of LCD and LCM products for more than ten years. Launch a full range of LCD product solutions, and undertake the development and design of various LCD and LCM, mold opening and customization, single-chip development and processing.

TSD factory have passed ISO9001, ISO14001, IATF16949 and ISO13485 certification etc., and TSD cooperate with ABB, 3M, Schneider, Avnet and other international famous enterprises.

Our TFT liquid crystal displays are mainly used in communication equipment, consumer electronics, industrial applications, office automation, smart applications, automobiles, IT products, medical applications and other fields. Wherever there is a demand for LCD, our products can be used.

A wide variety of 5 inch 480x272 tft lcd options are available to you, such as original manufacturer, odm.You can also choose from tft, ips and lcm 5 inch 480x272 tft lcd,

We supply 4.3 inch 480x272 LCD Touch screen which is a transmissive type a-Si TFT-LCD (amorphous silicon thin film transistor liquid crystal display) module, which is composed of a TFT-LCD panel, a driver circuit, a backlight unit and capacitive touch panel(6pins FPC). The panel size is 4.3 inch and the resolution is 480x272. the panel can display up to 16M colors. The LCM can be easily accessed by RGB interface.

A: We usually accept the payment methods include T/T, Western Union. 50-100% deposit in advance and balance before shipping upon the payment amount. Buyer can choose which payment ways that you accept.

Hot Tags: 4.3 inch 480x272 LCD Touch screen, China, Manufacturers, Suppliers, Factory, Made in China, Customized, In stock, Bulk, Quotation, High quality
