Newhaven 8x1 character Liquid Crystal Display shows characters with dark pixels on a gray background when powered on. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-0108HZ-FSW-GBW display has an optimal view of 6:00. This display operates at 3.3V supply voltage, has a built-in ST7066U controller and is RoHS compliant.

Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.

Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HDMI, USB, SPI, VGA and more into your display to achieve your design goals.

Newhaven 8x1 character Liquid Crystal Display shows characters with dark pixels on a bright yellow/green background when powered on. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-0108BZ-FSY-YBW-33V3 display has an optimal view of 6:00. This display operates at 3.3V supply voltage, has a built-in ST7066U controller and is RoHS compliant.

Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.

Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HDMI, USB, SPI, VGA and more into your display to achieve your design goals.

AOur production quality follow ISO9000 standard system, stable design team,22 years experience of QC team and strictly quality control system guarantee the production quality. accept third part inspection,we have mechanical checking,display checking,high&low temperature storage&operating test during high humidity condition,EMC test(optional) for every design

An import function allows additionally to use Windows fonts. With the FontEditor it is easy to generate for example Cyrillic, Greek and Arabic fonts. The preview function shows immediately the size and style in simulation window. When the testboard EA 9780-2USB is connected to the USB port, you can see the character (or any predefined text) live on the display which is plugged-in!

I combined and modified some of the tutorials to allow driving an LCD display in 4 bit mode, to save digital pins. The result is a program that can display temperature on an LCD and turn a digital pin on and off, to control a heater or other device. I"d post it in the playground but I haven"t figured out how to create a new page.

Character LCD displays refer to 1x8, 2x16, 4x20 and other character LCD modules that are widely available at very affordable prices. When programming in assembly language, it takes 16 steps to display data on LCD. Let me show you some of the steps:

You can trust me when I say that displaying text on a character LCD is one of the easiest tasks when programming with Bascom. You just have to make sure that the configuration (and wiring connections of course!) of the LCD is correct and then it will display data, text or even custom made characters flawlessly. The configuration commands in Bascom are as follows:

The first statement tells the compiler what type of LCD we are using. In our case we have used the 2x16 LCD. When using the 4x20 LCD, for example, we would write 20*4. You can find all possible LCDs in the Options/Compiler/LCD menu as shown in Figure 1. Note that if using the 2x8 LCD, we should write 16*1a – this is the only case in which the Bascom description does not match the physical layout of the LCD panel.

As seen in Figure 1 you can also select your LCD in this menu. It is, however, advisable to write the program definitions at the top of your program (just as you would set the microcontroller and other definitions). It’s easy to set one type of LCD in the menu and later, when using another LCD, simply forget to change the LCD type. This has happened to me many times.As a result, the program will not work as it should. So, it is good practice to define the LCD type at the top of the program, when programming in Bascom.

The next statement defines the bus mode we use to connect the LCD: 8 or 4 bits. I always use the 4-bit data bus. There are several reasons for that: the 4-bit data bus uses fewer of the microcontrollers’ pins and it’s nearly as fast as the 8-bit data bus. So far I have not needed the extra speed provided by the 8-bit data format.

It is as simple as that. You will notice that displaying text (or constants, and signs such as +/- etc.) can be done within brackets like “This is test, 123 +/-@”. This combination of text, numbers and signs will appear on the LCD exactly as written between the brackets, including spaces. If displaying a variable, then we just write its name instead of variable1, variable2, as shown in the example statement above. If displaying more than one variable, make sure that you include blank spaces between them, in order to distinguish them on the display.
