A 10.1” TFT display module, featuring WUXGA (1920x1200px) resolution, has been introduced by KOE. The TX26D202VM0BAA has a pixel pitch of 0.11325x0.11325, which equates to a pixel density of 224ppi.

The 16:10 aspect ratio display features IPS technology and a 16.7m colour palette, which enables highly accurate representation of image detail such as colour gradients and authentic colour reproduction. Outstanding optical performance is maintained with a contrast ratio of 800:1 and a brightness specification of 800cd/m², enabling bright, sharp display images.

The compact 10.1” display has mechanical outline dimensions of 232.0x153.0x4.7mm and an active display area of 217.44x135.9mm. A 50-pin, 2-channel LVDS interface supports 8-bit RGB, which enables a colour palette of up to 16.7m colours. The LED backlight is specified at 40,000 hours to half brightness lifetime and features an integrated dimming function. The operating temperature range of the TX26D202VM0BAA module is -30 to +80°C.

Typical applications for the WUXGA display include diagnostic systems, compact broadcast and video monitors, medical imaging, and test and measurement instrumentation. The TX126D202VM0BAA TFT display module is available now.

Mark Stephenson, Technical Marketing Manager, KOE Europe, said "KOE are one of the first LCD manufacturers to introduce compact, high resolution display modules developed specifically for industrial and professional applications. This reflects the trend for higher pixel density and enhanced image clarity found in consumer devices such as monitors, tablets and smartphones. The use of higher resolution displays with greater pixel density enables accurate reproduction and representation of graphical information such as measurement and diagnostic images, and video reproduction."

Asia has long dominated the display module TFT LCD manufacturers’ scene. After all, most major display module manufacturers can be found in countries like China, South Korea, Japan, and India.

However, the United States doesn’t fall short of its display module manufacturers. Most American module companies may not be as well-known as their Asian counterparts, but they still produce high-quality display products for both consumers and industrial clients.

In this post, we’ll list down 7 best display module TFT LCD manufacturers in the USA. We’ll see why these companies deserve recognition as top players in the American display module industry.

STONE Technologies is a leading display module TFT LCD manufacturer in the world. The company is based in Beijing, China, and has been in operations since 2010. STONE quickly grew to become one of the most trusted display module manufacturers in 14 years.

Now, let’s move on to the list of the best display module manufacturers in the USA. These companies are your best picks if you need to find a display module TFT LCD manufacturer based in the United States:

Planar Systems is a digital display company headquartered in Hillsboro, Oregon. It specializes in providing digital display solutions such as LCD video walls and large format LCD displays.

Planar’s manufacturing facilities are located in Finland, France, and North America. Specifically, large-format displays are manufactured and assembled in Albi, France.

Another thing that makes Planar successful is its relentless focus on its customers. The company listens to what each customer requires so that they can come up with effective display solutions to address these needs.

What makes Microtips a great display module TFT LCD manufacturer in the USA lies in its close ties with all its customers. It does so by establishing a good rapport with its clients starting from the initial product discussions. Microtips manages to keep this exceptional rapport throughout the entire client relationship by:

Displaytech is an American display module TFT LCD manufacturer headquartered in Carlsbad, California. It was founded in 1989 and is part of several companies under the Seacomp group. The company specializes in manufacturing small to medium-sized LCD modules for various devices across all possible industries.

The company also manufactures embedded TFT devices, interface boards, and LCD development boards. Also, Displaytech offers design services for embedded products, display-based PCB assemblies, and turnkey products.

Displaytech makes it easy for clients to create their own customized LCD modules. There is a feature called Design Your Custom LCD Panel found on their site. Clients simply need to input their specifications such as their desired dimensions, LCD configuration, attributes, connector type, operating and storage temperature, and other pertinent information. Clients can then submit this form to Displaytech to get feedback, suggestions, and quotes.

Clients are assured of high-quality products from Displaytech. This is because of the numerous ISO certifications that the company holds for medical devices, automotive, and quality management. Displaytech also holds RoHS and REACH certifications.

A vast product range, good customization options, and responsive customer service – all these factors make Displaytech among the leading LCD manufacturers in the USA.

Products that Phoenix Display offers include standard, semi-custom, and fully-customized LCD modules. Specifically, these products comprise Phoenix Display’s offerings:

Phoenix Display also integrates the display design to all existing peripheral components, thereby lowering manufacturing costs, improving overall system reliability, and removes unnecessary interconnects.

Clients flock to Phoenix Display because of their decades-long experience in the display manufacturing field. The company also combines its technical expertise with its competitive manufacturing capabilities to produce the best possible LCD products for its clients.

True Vision Displays is an American display module TFT LCD manufacturing company located at Cerritos, California. It specializes in LCD display solutions for special applications in modern industries. Most of their clients come from highly-demanding fields such as aerospace, defense, medical, and financial industries.

The company produces several types of TFT LCD products. Most of them are industrial-grade and comes in various resolution types such as VGA, QVGA, XGA, and SXGA. Clients may also select product enclosures for these modules.

Slow but steady growth has always been True Vision Display’s business strategy. And the company continues to be known globally through its excellent quality display products, robust research and development team, top-of-the-line manufacturing facilities, and straightforward client communication.

All of their display modules can be customized to fit any kind of specifications their clients may require. Display modules also pass through a series of reliability tests before leaving the manufacturing line. As such, LXD’s products can withstand extreme outdoor environments and operates on a wide range of temperature conditions.

Cystalfontz America is a leading supplier and manufacturer of HMI display solutions. The company is located in Spokane Valley, Washington. It has been in the display solutions business since 1998.

Crystalfontz takes pride in its ISO 9001 certification, meaning the company has effective quality control measures in place for all of its products. After all, providing high-quality products to all customers remains the company’s topmost priority. Hence, many clients from small hobbyists to large top-tier American companies partner with Crystalfontz for their display solution needs.

We’ve listed the top 7 display module TFT LCD manufacturers in the USA. All these companies may not be as well-known as other Asian manufacturers are, but they are equally competent and can deliver high-quality display products according to the client’s specifications. Contact any of them if you need a US-based manufacturer to service your display solutions needs.

We also briefly touched on STONE Technologies, another excellent LCD module manufacturer based in China. Consider partnering with STONE if you want top-of-the-line smart LCD products and you’re not necessarily looking for a US-based manufacturer. STONE will surely provide the right display solution for your needs anywhere you are on the globe.

If you want to buy a new monitor, you might wonder what kind of display technologies I should choose. In today’s market, there are two main types of computer monitors: TFT LCD monitors & IPS monitors.

The word TFT means Thin Film Transistor. It is the technology that is used in LCD displays.  We have additional resources if you would like to learn more about what is a TFT Display. This type of LCDs is also categorically referred to as an active-matrix LCD.

These LCDs can hold back some pixels while using other pixels so the LCD screen will be using a very minimum amount of energy to function (to modify the liquid crystal molecules between two electrodes). TFT LCDs have capacitors and transistors. These two elements play a key part in ensuring that the TFT display monitor functions by using a very small amount of energy while still generating vibrant, consistent images.

Industry nomenclature: TFT LCD panels or TFT screens can also be referred to as TN (Twisted Nematic) Type TFT displays or TN panels, or TN screen technology.

IPS (in-plane-switching) technology is like an improvement on the traditional TFT LCD display module in the sense that it has the same basic structure, but has more enhanced features and more widespread usability.

Both TFT display and IPS display are active-matrix displays, neither can’t emit light on their own like OLED displays and have to be used with a back-light of white bright light to generate the picture. Newer panels utilize LED backlight (light-emitting diodes) to generate their light hence utilizing less power and requiring less depth by design. Neither TFT display nor IPS display can produce color, there is a layer of RGB (red, green, blue) color filter in each LCD pixels to produce the color consumers see. If you use a magnifier to inspect your monitor, you will see RGB color in each pixel. With an on/off switch and different level of brightness RGB, we can get many colors.

Winner. IPS TFT screens have around 0.3 milliseconds response time while TN TFT screens responds around 10 milliseconds which makes the latter unsuitable for gaming

Winner. the images that IPS displays create are much more pristine and original than that of the TFT screen. IPS displays do this by making the pixels function in a parallel way. Because of such placing, the pixels can reflect light in a better way, and because of that, you get a better image within the display.

As the display screen made with IPS technology is mostly wide-set, it ensures that the aspect ratio of the screen would be wider. This ensures better visibility and a more realistic viewing experience with a stable effect.

Winner. While the TFT LCD has around 15% more power consumption vs IPS LCD, IPS has a lower transmittance which forces IPS displays to consume more power via backlights. TFT LCD helps battery life.

Normally, high-end products, such as Apple Mac computer monitors and Samsung mobile phones, generally use IPS panels. Some high-end TV and mobile phones even use AMOLED (Active Matrix Organic Light Emitting Diodes) displays. This cutting edge technology provides even better color reproduction, clear image quality, better color gamut, less power consumption when compared to LCD technology.

This kind of touch technology was first introduced by Steve Jobs in the first-generation iPhone. Of course, a TFT LCD display can always meet the basic needs at the most efficient price. An IPS display can make your monitor standing out.

VGA was first released in 1987 by IBM as part of their PS/2 line of computers. Since its initial inception, VGA has taken on a few different meanings in recent years and is characterized by its 640×480 resolution. It also refers to the 15-pin D-subminiature VGA connector and the analog computer display standard. Currently, it’s used for high-definition resolutions of 1080p or higher.

Developed in 1988 (just one year after IBM introduced VGA) by NEC Home Electronics, SVGA was an improvement on its predecessor. It increased graphics display resolutions by up to 36%, which amounted to 800×600 pixels. SVGA was designed to be compatible with the IBM PC and eventually replace VGA.

If you’re not sure what XGA looks like, you’ve definitely seen it before. Most modern laptop computers—around 80% of the current market—use XGA, which is an LCD display that exhibits 1024×768 resolutions. Sizes range from 15.1 inches to 10.4 inches.

As the name suggests, SXGA+ is an extension or modified version of XGA. With a 1400×1050 resolution, this screen is designed specifically and exclusively to accommodate laptop computers. It also has a much higher display accuracy than its predecessor thanks its compatibility with the horizontal and vertical dot pitch that all standard-sized laptop computers have.

QXGA has a resolution of 2048×1536. This particular display mode is commonly used by graphics designers, computer engineers, and other users who require or prefer exact image details when using various programs for specific projects. It’s also ideal for users who use their devices to watch online videos.

With a resolution of 1280×800, WXGA is an extended and wider version of the standard XGA that’s used for most modern laptops. It has an aspect ratio (the image projection in proportion to the width and height of an image as it appears on the screen) 16:10 so that the size of the screen can be expanded.

Like WXGA, WSXGA+ is also a display mode that’s meant to be an improved version of the standard XGA, except it has a screen resolution of 1440×900 with an aspect ratio of 15:10, which makes it more compatible with smaller screens.

WSXGA is basically a widescreen version of the original WXGA featuring a screen resolution of 1680×1050 with 32-bit pixels. It’s most commonly applied to wide screen LCD displays that are 15.4 inches diagonally.

Although it’s rarely used in technological applications, WUVGA has an aspect ratio of 4:3 and display resolution of 1920×1200 in its most advanced format. The reason it’s rarely used in technological applications is because of how expensive this formatting is.

qHD has become the standard display mode for modern high-end smartphones and certain gaming consoles. With a 960×540 resolution coupled with a 16:9 aspect ratio, qHD accounts for a quarter of 1080p’s screen resolution, but it still packs a powerful punch for mobile devices.

Also known as full HDTV, ultra-HD, and true HDTV, 1080p is a display mode that’s applied to most modern television screens as it has a far superior picture quality compared to 720p. It has a screen resolutionof 1920×1080, which indicates that there are 1080 vertical scans that occur right before the viewers’ eyes.

While most modern flat screen televisions boast a 4K standard resolution, electronic companies are also starting to adapt an 8K display mode. What does this mean? The K in all these abbreviations stands for “kilo”, meaning “thousand”. 2K, which is the standard used for most commercial movie screen projectors and high-end mobile devices, has a screen resolution of 2560×1440. 4K has a resolution of 4096×2160 and is also used for some high-end mobile devices. 8K, which has a resolution of 7680×4320 and is considered to be the highest screen resolution that humans can view. It’s also projected to be the next reigning champion of screen resolution standards as the technology continues to evolve.

As one of the leading designers, manufacturers, and distributors of high-end military and commercial-grade displays in North America, Nauticomp Inc. is at the forefront of this technological renaissance. We build and deliver high-end monitors and displays that are customized to meet the needs and daily operations of our customers. Contact us today to learn more or to place your order!

Two separate colors (yellow and sky blue), make this graphic OLED module easy-to-read, unique display. Less than an inch diagonal, this lightweight display uses super low power, making it great for handheld devices.

An ePD retains the content of your Display without applied power. Only for changing the display-content, a short supply with power is necessary. Microtips has partnered with an experienced E-paper manufacturer. We represent a full series of E-paper technology, including true color to meet your specific needs.

Thin Film Transistor or TFT screens are active-matrix LCDs capable of controlling individual pixels on the screen. Thus, they assure better visibility than other variants. These flat-panel displays are suitable for a variety of applications owing to their wide range of beneficial features.

Round TFT LCDs are gaining popularity as they have become a perfect replacement for analog gauges, and they help make any application look versatile. Microtips Technology has introduced a new 3.4-inch round display, with a high resolution of 800 x 800 pixels.

High-definition Multimedia Interface (HDMI) is a proprietary technology used to transmit uncompressed audio and video data from an HDMI-compliant digital controller to a television, computer, video projector, or any other HDMI-compliant device. Microtips Technology has developed the 7" RFH70XB-1IW-LHS medium-sized HDMI display with an HDMI interface and a high resolution.

TFT (Thin Film Transistor) is a thin-film field-effect transistor display that is designed to visualize millions of clear, bright, and high-contrast color pixels. Over the years, this display has gained immense popularity owing to its several benefits.

The 7 inch low-cost color display is one of the most popular touch screen displays available for raspberry pi, HDMI display screen and other mini PCs. Featuring IPS screen with larger visible angle and more clear display effect, this 7 inch display with touch screen can be used in all environmental conditions because of its wide temperature liquid crystal fluid.

Microtips Technology has introduced a high brightness High-Definition Multimedia Interface (HDMI) interface IPS TFT LCD module. These modules are compatible and assure seamless interface with any version of Raspberry Pi Single Board Computers (SBCs), PCs, or devices such as HDTV, DVD player, or any device that is compatible with HDMI.

AMOLED (stands for Active Matrix Organic Light Emitting Diodes) display is one of the best screen technologies popularly used in today’s laptop screens and PC monitors and high-end smart phones.

The Thin-Film-Transistor display (TFT display) is an active matrix display where each pixel of the flat panel is illuminated individually. In recent times, TFT display is increasingly used in the electronics industry owing to its several benefits.

Microtips Technology, one of the leading 5-inch color TFT display module manufacturers, has introduced the new low-cost 5-inch color TFT display. The thin film transistor (TFT) technology is just another variant of the LCD technology.

Thin-film transistor (TFT) LCD displays assure improved image quality over traditional LCD displays. They offer more control over colors and images, and require less power than other technologies.

Microptips Technology has introduced a 3.9" bar type TFT display that has a high contrast ratio. This panoramic 3.9 inch RGB bar TFT LCD comes with a resolution of 480x128 pixels. This display is suitable for several modern electronic appliances like server and audio systems, auto/marine equipment, advertising displays, drone controls and many more.

Microtips Technology, one of the leading 4.3-inch TFT LCD module manufacturers, has introduced the new low-cost 4.3-inch TFT display. TFT or thin film transistor is primarily a variant of the LCD technology. TFTs are active matrix LCDs, which help improve contrast, color, and picture quality.

Thin-Film- Transistor displays or TFT displays are active matrix LCD displays that assure better color perception than regular Twisted Nematic LCDs. The demand for TFT displays has increased in recent years owing to several advantages they offer. These displays assure a clear view from any angle, and they can display millions of bright color pixels.

Microtips is proud to announce a new line of HDMI Displays designed to work seamlessly with development boards and computers like the Raspberry Pi. This video outlines our current options for these displays...

Microtips is excited to announce our 10.1”, high bright, TFT display with increased resolution and widened viewing angles. This 10.1”, WXGA 1280*800 TFT display is an IPS panel equipped with an HDMI signal input...

Simple monochrome displays, like 7 Segments & Icons, have been around for a very long time. These displays are still widely used by customers in wide variety of industries. But have you thought about Color TN Displays instead?

Microtips MTD0550AZOM-T is a 5.49 inch display module with a resolution of 1080(RGB) x 1920. This display is composed of an AMOLED panel, driver ICs, On-cell Touch Panel and FPC.

Regional Sales Manager, George, explains OLED Displays, their benefits, and other characteristics that make them better than standard Liquid Crystal Displays for some applications.

As your Kyocera Display distributor and solution provider, Edge can help you choose the appropriate LCD display for your project and supply you with compatible accessories or enhancements such as a controller board or inverter. We supply Kyocera Display"s full line of LCD displays including active TFT LCDs, passive displays, and OLEDs.

Kyocera is a leading manufacturer of LCD products, focused on total solutions for the industrial and automotive markets. Kyocera offers high performance TFT display products, applied LTPS TFT array technology, and high performance passive displays.

Kyocera Display products feature superior optical performance, such as high transmittance, high contrast, high brightness, and high reliability in both standard TFT-LCDs and full custom products.

Our strong engineering team provides technical support and guidance from initial design to the production phase of product development. We offer various technical solutions to customers, including toolkits, touch screen solutions, optical bonding, and assembly services, which distinguish the company as a preferred and reliable display solution supplier.

As an Industrial LCD module distributor, we can supply a wide range of TFT LCDs in many sizes. Common resolutions are QVGA, VGA, SVGA and XGA. Wide aspect ratio displays are also available in many similar sizes and resolutions such as WQVGA, WVGA, WSVGA, and WXGA.

Get in touch to work closely with one of our LCD Solutions Specialists to determine the perfect display for your project. We can also recommend and supply the proper LCD controller board, inverter, LED driver, cables, touch screen, or other associated enhancement.

Take your design to the next level with our range of TFT Displays including latest IPS TFT, circular and bar shape as well as large size TFT. With or without touch, these are fully customisable to your system requirements.

TFT-LCD technology is now fairly mature. As a result, manufacturing processes are efficient and production yields are high, leading to very competitive unit prices. Upgrading from a monochrome display to a TFT is now an affordable way to give your product an uplift.

Users of industrial display devices are wanting the same experience they have come to expect from a consumer device with all-round viewing angles. Switching to a superior IPS TFT display has become very cost effective as production increases and unit prices decrease.

Choosing a circular display for your next product design could really set you apart from your competition. Models are available from 1" to 4.2"in TFT, PMOLED and AMOLED, we have something to suit every application.

It is now possible to transform from a monochrome display to a colour display in space constrained systemsby using a letterbox shaped display. These ultra-wide displays are ideal for applications with restricted build height such as rack mount systems or landscape format front panels.

Large TFT display systems are increasingly being used for transportation information, retail signage and vending machines and kiosks. We can supply a large range of TFT solutions up to 65" diameter and in bar-style, square or rectangular configurations.

We are now offering increasing cover lens customisation options and processes to make your TFT LCD user interface truly stand out! Anders’ experienced marketers and engineers work with our manufacturing partners around the world to keep informed of the latest innovations, including mirrored glass,tinted glass, spot-facing, three dimension glass, and many more!

Here at Anders we don"t just strive to design a best in class display solution for your product, but we also want to make sure the display is driven with the right embedded system. We can help achieve a hardware solution that ensures your display works perfectly within your application. Hardware solutions include:

Get started quickly on your new user interface with our HMI development kits. The display, the processor and the OS work together out of the box with optimised QT GUI images. We"ll then optimise the kit to meet exactly your system requirements with our design services.

At Anders we understand that no two customers are the same, which is why we specialise in custom display solutionsand offer unique productstailored to your end application.

See below our range of TFT Displayswith sizes ranging from0.96" to 64.5" and including circular and bar type shape. All our displays can be tailored to suit your application antimicrobial coating technology,

We aim to offer reliable and long-term solutions to our B2B customers. If you are a business and would like to discuss your display and/or embedded system requirements please contact us below

A TFT display is a form of Liquid Crystal Display with thin film transistors for controlling the image formation. The TFT technology works by controlling brightness in red, green and blue sub-pixels through transistors for each pixel on the screen.

There are many display technologies, but do you know which one would be better for your application? Particularly when considering optimum viewing angle and contrast. We discuss 2 of the best options.

Compare IPS vs TFT displays - the TFT display is the display of choice for industrial designs, but it can have its limitations. A newer technology called IPS (in plane switching) offers better viewing angles and colours, but is it really the best choice - we discuss benefits and negatives of both types of TFT display.

Chino, CA, March 1, 2021– Tianma, a leading global manufacturer of flat panel displays, has introduced a new product family of TFT LCD Modules (Thin Film Transistor - Liquid Crystal Display). The new P-Series (Professional Series) of standard products is dedicated to support the various requirements of the industrial and medical display markets. The first products in this new series will include XGA displays (8.4”, 10.4” and 12.1”), as well as wide-format products, from 7” WVGA to 13.3” FHD.

The P-Series display products will be available in three grades – Advanced, Basic and Entry – to better support the different customer needs in a variety of markets, including a range of features and product specifications around pixel density, viewing angle, contrast ratio, color gamut, black level uniformity, etc.

The Basic grade of P-Series displays will offer a very good performance-to-cost ratio, meeting the standard specification and performance requirements of the market with typical brightness ratings and long-life LED backlights. The Entry level provides more cost-effective solutions for price-sensitive markets and applications.

All three grades of the P-Series family will be available in production for a minimum of five years (typically seven years or more) with a small minimum order quantity (MOQ). The P-Series will also be engineered around dedicated design rules to meet the particular requirements of the professional market. Further, the manufacture and assembly of the TFT-LCDs and PCAP sensors will all be done in-house, with industrial level driver support.

Samples from the initial P-Series product offering will be available starting Q1 2021. These first displays will include wide-format 7” WVGA, 10.6” WXGA, and 13.3” FHD products, in the Advanced high brightness versions. The first products with 4:3 format will all have XGA resolution and include both Advanced high brightness and Basic, in sizes 8.4”, 10.4” and 12.1”.

Regarding Tianma’s legacy Professional TFT LCD products, both standard TM-series and all NL-series modules will be promoted alongside the new P-series product offering. All of these products will remain in production and will continue to be fully supported.

Tianma America (TMA) is the leading provider of small- to medium-size display solutions to the Americas market utilizing advanced technologies and manufacturing resources of the Tianma Group Companies, which includes Tianma Micro-electronics (Shenzhen and Shanghai) and Tianma Japan, Ltd. (formerly known as NLT Technologies Ltd.), as well as manufacturing locations in Chengdu, Wuhan, Xiamen, Shenzhen and Shanghai China. Tianma America technologies can be found in smartphones, tablet PCs, industrial and medical instrumentation, wearables, home automation, household appliances, office equipment, and automotive and rear seat entertainment devices. Additional applications include test and measurement systems, instrumentation equipment, point-of-sale and ATM systems, gaming systems, global positioning systems, radio-frequency identification devices and barcode scanners.

Tianma America’s technology portfolio comprises TFT, LTPS, Oxide-TFT, AM-OLED, flexible, transparent, 3D, PCAP and In-cell/On-cell integrated touch. With a network of best-in-class distributors and value-added partners, Tianma America provides complete display module solutions for a broad base of customers and applications.

These wide viewing angle Small Format TFT LCDs with optional touch are industrial grade and cost competitive. Therefore these products are a popular display choice to integrate in many projects.

Using only high-tech factories that we partner with, we provide clients with the service of designing liquid crystal display panel (LCD) and liquid crystal display module(LCM), and is committed to the customized service, R&D, sales, after-sales service of display products. Our factories have hundreds of engineers focusing on creating the highest quality displays including monochrome LCD (TN, STN), colour LCD (CSTN and TFT), Custom LCD’s, LCD module (both COG* and COB*) which are widely used in mobile phones and many other applications.

Our state of the art factory produces High Resolution TFT glass panel cells, has TN, HTN, STN and TFT technologies for LCD panels. The Factory has class 1000 clean rooms, high accuracy bonding, pre bonding and heat seal machinery, many production lines specifically for TFT production, OCA and OCF bonding machines,  In-House LCD glass cleansing process, output thousands of pieces per month.

Touchscreen overlay cover glass only available (so you do not have to purchase the display)These displays can come with: touchscreen components, touchscreen overlays, industrial touch screen,Wide LCDs, LED TFTs, and TFT Colour displays.

Other options are: LCD drivers, LVDS Touchscreen displays, automotive LCD Display, TFT high resolution screens, TFT LCD capacitive touchscreens, TFT capacitive touchscreens, high brightness LCDs, Letterbox Displays, small VGA Displays, LCD panel without backlights,Variations of our Small Format TFT LCDs include: TFT Display touchscreens, TFT IPS Display, monochrome displays, TFT or LCD, embedded components, LCD components, TFT Drivers, industrial range of Displays,

CDS also offers industrial TFT LCDs,Our displays are used in: touch screen vending machines, automotive touch screen displays, vending machine display panel, Touch screen vending, TFT Automotive, LCD Dislay panel kits, Touch screen TFT monitors, LCD Display components, LCD Screen components,  and POS LCD Displays.As you can see from the tables above we have sizes including:  8.8 inches, 4.3 inch LCD Display, 10.1″ TFT LCD,  3.5 inch LCD Display, 4.3 inch display, 3.5 inch TFT LCD Display, 4.3″ screen, 7 inch LCD panel, 3 inch LCD Displays, and 4.3″ TFT LCDs as well as other small LCD Display screens.We have options on and equivalents to the following displays and TFT panel manufacturers:  Raystar, Kingtech LCD, Digital View, OLED modules, OLED products, Powertip LCD Displays, Data Vision LCD, LG TFT Display, Tianma NLT, Powertip Displays, Mitsubishi LCD Displays, DMC components, Kyocera LCDs, NLT Technologies Ltd, Sharp LCD TFT modules, LCD manufacturers in the USA, PMOLED Displays, innolux display corp, Industrial touchscreens, A Grade TFT LCD Displays, Panoramic TFT Displays, Samsung TFT Displays, Touchscreen components, Transparent TFT Displays, Touchscreen components,  TFT LCD controllers, as well as other TFT LCD manufacturers and Liquid crystal Display manufacturers.

CDS offers the widest range of displays and touchscreens including Abon touchscreens, Ampire LCD distributor, alternative Prisma interface baord supplier including Prisma iiia, Solomon Goldentek, Panasonic TFT, Winmate display, USB IO, and Apollo monitors

Our range includes AMOLED, circular displays, circular monitors, circular screens, circular TFT screens, round displays, Round TFT LCD displays, TFT AMOLEDs, TFT and IPS, TFT display interface microcontroller, TFT LCD or AMOLED, TFT LCD super AMOLED, WXGA TFT Displays, and WXGA TFT screens

As well as large format displays CDS also offers DSI TFT Display, large monochrome LCD displays, mono displays, mono OLEDC displays, mono TFT LCDs, monochrome displays, PCT Touchscreens, projected capacitive touch PCT technology, sq monitors and squid IDS.

CDS added a number of additional controller boards nd accessories which include TFT adaptor boards, TFT boards, TFT display controller boards, USB c LCD controller, USB touch kit, resistive touch screen, TFT accessories com, LCD controller board, LCD controller board USB c, LCD controller board, HDMI to MiPi DSI board, HDMI to MiPi DSI bridge, HDMI to MiPi LCD controller board, EDP adaptor bard, elite C microcontroller, Displaylink DL 3000 .

Whether it be bar type LCDs or any of CDS display solutions or many TFT displays we can help with comparing mipi dsi vs lvds interfces or mipi to edp wch can include use on pos shelf displays and rgb epaper for example.

Industrial display manufacturer, KOE, has announced the introduction of a new 7.0-inch Rugged+ TFT display. The TX18D212VM0BAA features WXGA (1280 x 768 pixels) resolution, a 5:3 wide aspect ratio, an extended operating temperature range and IPS (in-plane switching) wide viewing angle technology that delivers exceptional optical performance.

Designed for use in high reliability industrial, in-vehicle, medical, aerospace and marine environments the Rugged+ 7.0-inch display is suitable for use where extreme temperature, mechanical shock and vibration are present. The environmental and optical specifications of KOE’s Rugged+ display modules are derived from the same exacting standards as used in automotive specification display modules.

When used in human-machine interfaces, IPS display technology delivers exceptional colour saturation and image stability, high contrast and deep black levels with 170° wide viewing angles (vertical and horizontal). The 7.0-inch display features a contrast ratio of 1000:1 and a white LED backlight with a brightness specification of 1000cd/m². The display module has a built-in dimming control allowing backlight brightness to be controlled with a PWM or DC voltage input.

Jason Tsai, Marketing Manager, KOE, said, “KOE’s new high performance, high resolution 7.0-inch display benefits with exceptional optical performance, highly consistent colour reproduction and wide viewing angles through the implementation of IPS technology. Additionally, Rugged+ displays have been specifically designed and developed to have robust electrical, mechanical and environmental characteristics that are highly resistant to vibration, shock, electro-static discharge and temperature variation.”

The 20-pin LVDS interface supports 8-bit RGB, which enables a colour palette of up to 16.7M colours.The display module is manufactured using COG (chip-on-glass) construction and has mechanical outline dimensions of 164.4mm (w) x 105mm (h) x 13.5mm (d) and an active display area of 152.45mm (w) x 91.47mm (h). The Rugged+ module supports a wide operating temperature range of -40°C to +85°C and storage temperature range -40°C to +90°C.

KOE is committed to ensuring long-term product availability, with continuity of supply essential for many industrial products and equipment. The latest KOE Rugged+ displays can be sourced and supplied for a minimum of 5 years. The new 7.0-inch Rugged+ TX18D212VM0BAA TFT display module is available immediately from KOE’s sales channel distribution partners.

This 14-inch LCD display is a ALL o’clock TFT LCD (Thin Film Transistor Liquid Crystal Display) module. This model is Composed of a TFT LCD panel, a driving circuit and a back-light, with a 14.1 inch diagonally measured active display area with WXVGA (1920horizontal by 1080 vertical pixel) resolution in a stripe arrangement. Display 16.7M colors by 6-bit R.G.B signal input. This TFT display is a landscape type 14” TFT LCD panel with 16:9 aspect ratio and with outline dimension 320.39x205.12x2.50mm and active area 309.312(H)x173.988(V)mm, it can be operated at temperature from 0 to 45 degree, stored at temperature from - 20 to 60 degree with typical 30,000 hours LED life time, mainly used for Laptop and TFT LCD Monitor applications.

For many years, TFT displays have been the dominating technology in visualization. TFT LCDs are all around in our daily lives — in consumer and automotive applications, in our business environments, in healthcare, and within communication devices, home appliances, and factory automation products. While there are many LCD products available today, they’re not all suitable for every application. This is especially the case for industrial LCD monitors. To determine the best LCD display for your application, it’s important to understand your target market and its unique design issues.

The vast majority of LCD displays are designed for consumer devices such as smartphones, cameras, tablet computers, and gaming devices. But they have very different requirements than those for industrial applications. Due to very competitive pricing and quick production cycles, consumer display modules don’t always incorporate the durability, reliability, and advanced features required to survive in an industrial environment. Product life cycles are also typically much shorter in consumer applications. Screens manufactured for these applications are generally only available for one, in best case two years.

In contrast, display modules for industrial applications require Long product life cycles— often up to ten years or more. Plus, when an industrial module is discontinued by the manufacturer, a successor product should be backward-compatible so as to fit into the existing enclosure without requiring a redesign of the entire system.

The ability to withstand temperature variations as well as shock and vibration is also a key consideration when selecting displays for today’s industrial applications. They must be resilient enough to withstand frequent bumps or jiggles by machine operators and surrounding equipment, and also must be able to handle various operating temperatures.

Industrial displays are typically housed in an enclosure as part of a larger piece of equipment. In these situations, the heat generated by the surrounding equipment gets trapped within the enclosure, which can be detrimental to many displays. Therefore, it’s important to keep the real storage and operating temperature requirements in mind when choosing a display. While measures can be taken to dissipate the generated heat — such as using fans within the enclosure — the most efficient way to ensure compliance with the storage and operating temperature requirements is to select a display that is optimized for these types of environments. Fortunately, improvements in liquid-crystal materials have made it possible to extend the operating temperature ranges of LCDs from –30 to 80°C presently.

It’s important that displays used in industrial applications support clear and precise viewing from multiple angles under a variety of ambient light conditions. The brighter the environment, the more difficult it can be to read a standard transmissive LCD display with a typical brightness of 250 to 300 cd/m2. NVD has developed displays that can perform in the 800-cd/m2-and-higher range by implementing high-efficiency LEDs for the backlight unit– if necessary, in combination with special brightness enhancement films.

Increasing the display’s contrast ratio is another effective way that display manufacturers can improve display readability in bright environments. Typical contrast ratios for non-industrial displays are in the range of 200:1 to 300:1, which may not be sufficient when a machine operator is viewing the display from a distance. Displays with contrast ratios around 500:1 or greater are better suited for industrial environments. Another benefit of this method is that it doesn’t increase power consumption.

Multi-angle readability is another key selection factor. In a typical industrial environment, a machine operator is more likely to be positioned at an off-angle rather than right in front of the screen. Implementing a display designed for consumer applications typically doesn’t work well in this situation, as there is image distortion and color shifting when viewed at an angle. But, a number of technologies have been employed to improve off-angle viewing in displays, making them suitable for industrial applications. Some film-based technologies yield viewing angles of 160º horizontally and 140º vertically, but in some cases, this is still not sufficient. In-plane switching technology (IPS), multi-domain vertical alignment (MVA), and fringe field switching (FFS)offer alternatives. These proprietary technologies are able to achieve viewing angles of almost 90-degrees into all four directions without any color shift.

Size and resolution also play a role in overall readability. Displays between 2 and 15-inch diagonal sizes are used most often in industrial applications. These sizes provide sufficient area to view figures, waveforms, and other graphical data without taking up too much real estate on a piece of equipment.

From an aspect ratio 4:3 initially, industrial displays are now shifting to wide formats with WVGA to WXGA resolutions. The wide-aspect format enables users to view longer waveforms and more data on a single display. These display modules can also be designed to incorporate touch-key functions, allowing equipment manufacturers to skip physical switches and buttons and design HMIs based more on software than hardware.

New Vision Display’s experts are prepared to assist in defining appropriate solutions for all applications and in helping find the right balance between manufacturing cost and performance.

IPS (In-Plane Switching) lcd is still a type of TFT LCD, IPS TFT is also called SFT LCD (supper fine tft ),different to regular tft in TN (Twisted Nematic) mode, theIPS LCD liquid crystal elements inside the tft lcd cell, they are arrayed in plane inside the lcd cell when power off, so the light can not transmit it via theIPS lcdwhen power off, When power on, the liquid crystal elements inside the IPS tft would switch in a small angle, then the light would go through the IPS lcd display, then the display on since light go through the IPS display, the switching angle is related to the input power, the switch angle is related to the input power value of IPS LCD, the more switch angle, the more light would transmit the IPS LCD, we call it negative display mode.

The regular tft lcd, it is a-si TN (Twisted Nematic) tft lcd, its liquid crystal elements are arrayed in vertical type, the light could transmit the regularTFT LCDwhen power off. When power on, the liquid crystal twist in some angle, then it block the light transmit the tft lcd, then make the display elements display on by this way, the liquid crystal twist angle is also related to the input power, the more twist angle, the more light would be blocked by the tft lcd, it is tft lcd working mode.

A TFT lcd display is vivid and colorful than a common monochrome lcd display. TFT refreshes more quickly response than a monochrome LCD display and shows motion more smoothly. TFT displays use more electricity in driving than monochrome LCD screens, so they not only cost more in the first place, but they are also more expensive to drive tft lcd screen.The two most common types of TFT LCDs are IPS and TN displays.
