A 10.1” TFT display module, featuring WUXGA (1920x1200px) resolution, has been introduced by KOE. The TX26D202VM0BAA has a pixel pitch of 0.11325x0.11325, which equates to a pixel density of 224ppi.

The 16:10 aspect ratio display features IPS technology and a 16.7m colour palette, which enables highly accurate representation of image detail such as colour gradients and authentic colour reproduction. Outstanding optical performance is maintained with a contrast ratio of 800:1 and a brightness specification of 800cd/m², enabling bright, sharp display images.

The compact 10.1” display has mechanical outline dimensions of 232.0x153.0x4.7mm and an active display area of 217.44x135.9mm. A 50-pin, 2-channel LVDS interface supports 8-bit RGB, which enables a colour palette of up to 16.7m colours. The LED backlight is specified at 40,000 hours to half brightness lifetime and features an integrated dimming function. The operating temperature range of the TX26D202VM0BAA module is -30 to +80°C.

Typical applications for the WUXGA display include diagnostic systems, compact broadcast and video monitors, medical imaging, and test and measurement instrumentation. The TX126D202VM0BAA TFT display module is available now.

Mark Stephenson, Technical Marketing Manager, KOE Europe, said "KOE are one of the first LCD manufacturers to introduce compact, high resolution display modules developed specifically for industrial and professional applications. This reflects the trend for higher pixel density and enhanced image clarity found in consumer devices such as monitors, tablets and smartphones. The use of higher resolution displays with greater pixel density enables accurate reproduction and representation of graphical information such as measurement and diagnostic images, and video reproduction."

Asia has long dominated the display module TFT LCD manufacturers’ scene. After all, most major display module manufacturers can be found in countries like China, South Korea, Japan, and India.

However, the United States doesn’t fall short of its display module manufacturers. Most American module companies may not be as well-known as their Asian counterparts, but they still produce high-quality display products for both consumers and industrial clients.

In this post, we’ll list down 7 best display module TFT LCD manufacturers in the USA. We’ll see why these companies deserve recognition as top players in the American display module industry.

STONE Technologies is a leading display module TFT LCD manufacturer in the world. The company is based in Beijing, China, and has been in operations since 2010. STONE quickly grew to become one of the most trusted display module manufacturers in 14 years.

Now, let’s move on to the list of the best display module manufacturers in the USA. These companies are your best picks if you need to find a display module TFT LCD manufacturer based in the United States:

Planar Systems is a digital display company headquartered in Hillsboro, Oregon. It specializes in providing digital display solutions such as LCD video walls and large format LCD displays.

Planar’s manufacturing facilities are located in Finland, France, and North America. Specifically, large-format displays are manufactured and assembled in Albi, France.

Another thing that makes Planar successful is its relentless focus on its customers. The company listens to what each customer requires so that they can come up with effective display solutions to address these needs.

What makes Microtips a great display module TFT LCD manufacturer in the USA lies in its close ties with all its customers. It does so by establishing a good rapport with its clients starting from the initial product discussions. Microtips manages to keep this exceptional rapport throughout the entire client relationship by:

Displaytech is an American display module TFT LCD manufacturer headquartered in Carlsbad, California. It was founded in 1989 and is part of several companies under the Seacomp group. The company specializes in manufacturing small to medium-sized LCD modules for various devices across all possible industries.

The company also manufactures embedded TFT devices, interface boards, and LCD development boards. Also, Displaytech offers design services for embedded products, display-based PCB assemblies, and turnkey products.

Displaytech makes it easy for clients to create their own customized LCD modules. There is a feature called Design Your Custom LCD Panel found on their site. Clients simply need to input their specifications such as their desired dimensions, LCD configuration, attributes, connector type, operating and storage temperature, and other pertinent information. Clients can then submit this form to Displaytech to get feedback, suggestions, and quotes.

Clients are assured of high-quality products from Displaytech. This is because of the numerous ISO certifications that the company holds for medical devices, automotive, and quality management. Displaytech also holds RoHS and REACH certifications.

A vast product range, good customization options, and responsive customer service – all these factors make Displaytech among the leading LCD manufacturers in the USA.

Products that Phoenix Display offers include standard, semi-custom, and fully-customized LCD modules. Specifically, these products comprise Phoenix Display’s offerings:

Phoenix Display also integrates the display design to all existing peripheral components, thereby lowering manufacturing costs, improving overall system reliability, and removes unnecessary interconnects.

Clients flock to Phoenix Display because of their decades-long experience in the display manufacturing field. The company also combines its technical expertise with its competitive manufacturing capabilities to produce the best possible LCD products for its clients.

True Vision Displays is an American display module TFT LCD manufacturing company located at Cerritos, California. It specializes in LCD display solutions for special applications in modern industries. Most of their clients come from highly-demanding fields such as aerospace, defense, medical, and financial industries.

The company produces several types of TFT LCD products. Most of them are industrial-grade and comes in various resolution types such as VGA, QVGA, XGA, and SXGA. Clients may also select product enclosures for these modules.

Slow but steady growth has always been True Vision Display’s business strategy. And the company continues to be known globally through its excellent quality display products, robust research and development team, top-of-the-line manufacturing facilities, and straightforward client communication.

All of their display modules can be customized to fit any kind of specifications their clients may require. Display modules also pass through a series of reliability tests before leaving the manufacturing line. As such, LXD’s products can withstand extreme outdoor environments and operates on a wide range of temperature conditions.

Cystalfontz America is a leading supplier and manufacturer of HMI display solutions. The company is located in Spokane Valley, Washington. It has been in the display solutions business since 1998.

Crystalfontz takes pride in its ISO 9001 certification, meaning the company has effective quality control measures in place for all of its products. After all, providing high-quality products to all customers remains the company’s topmost priority. Hence, many clients from small hobbyists to large top-tier American companies partner with Crystalfontz for their display solution needs.

We’ve listed the top 7 display module TFT LCD manufacturers in the USA. All these companies may not be as well-known as other Asian manufacturers are, but they are equally competent and can deliver high-quality display products according to the client’s specifications. Contact any of them if you need a US-based manufacturer to service your display solutions needs.

We also briefly touched on STONE Technologies, another excellent LCD module manufacturer based in China. Consider partnering with STONE if you want top-of-the-line smart LCD products and you’re not necessarily looking for a US-based manufacturer. STONE will surely provide the right display solution for your needs anywhere you are on the globe.

If you want to buy a new monitor, you might wonder what kind of display technologies I should choose. In today’s market, there are two main types of computer monitors: TFT LCD monitors & IPS monitors.

The word TFT means Thin Film Transistor. It is the technology that is used in LCD displays.  We have additional resources if you would like to learn more about what is a TFT Display. This type of LCDs is also categorically referred to as an active-matrix LCD.

These LCDs can hold back some pixels while using other pixels so the LCD screen will be using a very minimum amount of energy to function (to modify the liquid crystal molecules between two electrodes). TFT LCDs have capacitors and transistors. These two elements play a key part in ensuring that the TFT display monitor functions by using a very small amount of energy while still generating vibrant, consistent images.

Industry nomenclature: TFT LCD panels or TFT screens can also be referred to as TN (Twisted Nematic) Type TFT displays or TN panels, or TN screen technology.

IPS (in-plane-switching) technology is like an improvement on the traditional TFT LCD display module in the sense that it has the same basic structure, but has more enhanced features and more widespread usability.

Both TFT display and IPS display are active-matrix displays, neither can’t emit light on their own like OLED displays and have to be used with a back-light of white bright light to generate the picture. Newer panels utilize LED backlight (light-emitting diodes) to generate their light hence utilizing less power and requiring less depth by design. Neither TFT display nor IPS display can produce color, there is a layer of RGB (red, green, blue) color filter in each LCD pixels to produce the color consumers see. If you use a magnifier to inspect your monitor, you will see RGB color in each pixel. With an on/off switch and different level of brightness RGB, we can get many colors.

Winner. IPS TFT screens have around 0.3 milliseconds response time while TN TFT screens responds around 10 milliseconds which makes the latter unsuitable for gaming

Winner. the images that IPS displays create are much more pristine and original than that of the TFT screen. IPS displays do this by making the pixels function in a parallel way. Because of such placing, the pixels can reflect light in a better way, and because of that, you get a better image within the display.

As the display screen made with IPS technology is mostly wide-set, it ensures that the aspect ratio of the screen would be wider. This ensures better visibility and a more realistic viewing experience with a stable effect.

Winner. While the TFT LCD has around 15% more power consumption vs IPS LCD, IPS has a lower transmittance which forces IPS displays to consume more power via backlights. TFT LCD helps battery life.

Normally, high-end products, such as Apple Mac computer monitors and Samsung mobile phones, generally use IPS panels. Some high-end TV and mobile phones even use AMOLED (Active Matrix Organic Light Emitting Diodes) displays. This cutting edge technology provides even better color reproduction, clear image quality, better color gamut, less power consumption when compared to LCD technology.

This kind of touch technology was first introduced by Steve Jobs in the first-generation iPhone. Of course, a TFT LCD display can always meet the basic needs at the most efficient price. An IPS display can make your monitor standing out.

As an Industrial LCD module distributor, we can supply a wide range of TFT LCDs in many sizes. Common resolutions are QVGA, VGA, SVGA and XGA. Wide aspect ratio displays are also available in many similar sizes and resolutions such as WQVGA, WVGA, WSVGA, and WXGA.

Get in touch to work closely with one of our LCD Solutions Specialists to determine the perfect display for your project. We can also recommend and supply the proper LCD controller board, inverter, LED driver, cables, touch screen, or other associated enhancement.

Distributor of component LCDs for equipment which provide high-contrast ratio, color saturation, luminance and performance enhancements such as advanced wide viewing (AWV) for true color fidelity, super-high brightness (SHB) and wide temperature range. Focus on industrial, instrumentation, hand-helds, medical and other low-to-medium volume markets. High-bright LED backlights for outdoor use. LVDS interfaces decrease EMI. Factory installed touch screen solutions. 3.5" to 12.1" QVGA, HVGA, VGA, WVGA, SVGA, XGA, WXGA. Also distributes other related products including LED drivers, lamps, indicators, LED assemblies, segment displays, LED mounts, LEDs, and light pipes. Distributor of electronic components, hardware and fasteners and provides design/value engineering support, fulfillment strategies, procurement services and transactional models to meet specific needs and priorities.

As you might already be aware, there’s a large variety of versatile digital display types on the market, all of which are specifically designed to perform certain functions and are suitable for numerous commercial, industrial, and personal uses. The type of digital display you choose for your company or organization depends largely on the requirements of your industry, customer-base, employees, and business practices. Unfortunately, if you happen to be technologically challenged and don’t know much about digital displays and monitors, it can be difficult to determine which features and functions would work best within your professional environment. If you have trouble deciphering the pros and cons of using TFT vs. IPS displays, here’s a little guide to help make your decision easier.

TFT stands for thin-film-transistor, which is a variant of liquid crystal display (LCD). TFTs are categorized as active matrix LCDs, which means that they can simultaneously retain certain pixels on a screen while also addressing other pixels using minimal amounts of energy. This is because TFTs consist of transistors and capacitors that respectively work to conserve as much energy as possible while still remaining in operation and rendering optimal results. TFT display technologies offer the following features, some of which are engineered to enhance overall user experience.

The bright LED backlights that are featured in TFT displays are most often used for mobile screens. These backlights offer a great deal of adaptability and can be adjusted according to the visual preferences of the user. In some cases, certain mobile devices can be set up to automatically adjust the brightness level of the screen depending on the natural or artificial lighting in any given location. This is a very handy feature for people who have difficulty learning how to adjust the settings on a device or monitor and makes for easier sunlight readability.

One of the major drawbacks of using a TFT LCD instead of an IPS is that the former doesn’t offer the same level of visibility as the latter. To get the full effect of the graphics on a TFT screen, you have to be seated right in front of the screen at all times. If you’re just using the monitor for regular web browsing, for office work, to read and answer emails, or for other everyday uses, then a TFT display will suit your needs just fine. But, if you’re using it to conduct business that requires the highest level of colour and graphic accuracy, such as completing military or naval tasks, then your best bet is to opt for an IPS screen instead.

Nonetheless, most TFT displays are still fully capable of delivering reasonably sharp images that are ideal for everyday purposes and they also have relatively short response times from your keyboard or mouse to your screen. This is because the pixel aspect ration is much narrower than its IPS counterpart and therefore, the colours aren’t as widely spread out and are formatted to fit onto the screen. Primary colours—red, yellow, and blue—are used as the basis for creating brightness and different shades, which is why there’s such a strong contrast between different aspects of every image. Computer monitors, modern-day HD TV screens, laptop monitors, mobile devices, and even tablets all utilize this technology.

IPS (in-plane-switching) technology is almost like an improvement on the traditional TFT display module in the sense that it has the same basic structure, but with slightly more enhanced features and more widespread usability. IPS LCD monitors consist of the following high-end features.

IPS screens have the capability to recognize movements and commands much faster than the traditional TFT LCD displays and as a result, their response times are infinitely faster. Of course, the human eye doesn’t notice the difference on separate occasions, but when witnessing side-by-side demonstrations, the difference is clear.

Wide-set screen configurations allow for much wider and versatile viewing angles as well. This is probably one of the most notable and bankable differences between TFT and IPS displays. With IPS displays, you can view the same image from a large variety of different angles without causing grayscale, blurriness, halo effects, or obstructing your user experience in any way. This makes IPS the perfect display option for people who rely on true-to-form and sharp colour and image contrasts in their work or daily lives.

IPS displays are designed to have higher transmittance frequencies than their TFT counterparts within a shorter period of time (precisely 1 millisecond vs. 25 milliseconds). This speed increase might seem minute or indecipherable to the naked eye, but it actually makes a huge difference in side-by-side demonstrations and observations, especially if your work depends largely on high-speed information sharing with minimal or no lagging.

Just like TFT displays, IPS displays also use primary colours to produce different shades through their pixels. The main difference in this regard is the placement of the pixels and how they interact with electrodes. In TFT displays, the pixels run perpendicular to one another when they’re activated by electrodes, which creates a pretty sharp image, but not quite as pristine or crisp as what IPS displays can achieve. IPS display technologies employ a different configuration in the sense that pixels are placed parallel to one another to reflect more light and result in a sharper, clearer, brighter, and more vibrant image. The wide-set screen also establishes a wider aspect ratio, which strengthens visibility and creates a more realistic and lasting effect.

When it comes to deciphering the differences between TFT vs. IPS display technologies and deciding which option is best for you and your business, the experts at Nauticomp Inc. can help. Not only do we offer a wide variety of computer displays, monitors, and screen types, but we also have the many years of experience in the technology industry to back up our recommendations and our knowledge. Our top-of-the-line displays and monitors are customized to suit the professional and personal needs of our clients who work across a vast array of industries. For more information on our high-end displays and monitors, please contact us.

Ampire’s AM-19201200B1TZQW-00 WUXGA TFT display with 1000 cd/m² is very bright and its wide temperature range of -20 to + 70°C makes it suitable for outdoor use. The AM-19201200B1TZQW-T51-A can be operated within the same temperature range and features a brightness of 850 cd/m². Its built-in PCAP touch screen enables easy operation with 2 fingers. Both displays feature a wide viewing angle of v/h 170°/170° due to IPS technology, an integrated LED backlight driver and are controlled via a LVDS interface. We are happy to supply you with a fully tested kit solution with one of our TFT controller boards and all the necessary cables.

Two separate colors (yellow and sky blue), make this graphic OLED module easy-to-read, unique display. Less than an inch diagonal, this lightweight display uses super low power, making it great for handheld devices.

An ePD retains the content of your Display without applied power. Only for changing the display-content, a short supply with power is necessary. Microtips has partnered with an experienced E-paper manufacturer. We represent a full series of E-paper technology, including true color to meet your specific needs.

Thin Film Transistor or TFT screens are active-matrix LCDs capable of controlling individual pixels on the screen. Thus, they assure better visibility than other variants. These flat-panel displays are suitable for a variety of applications owing to their wide range of beneficial features.

Round TFT LCDs are gaining popularity as they have become a perfect replacement for analog gauges, and they help make any application look versatile. Microtips Technology has introduced a new 3.4-inch round display, with a high resolution of 800 x 800 pixels.

High-definition Multimedia Interface (HDMI) is a proprietary technology used to transmit uncompressed audio and video data from an HDMI-compliant digital controller to a television, computer, video projector, or any other HDMI-compliant device. Microtips Technology has developed the 7" RFH70XB-1IW-LHS medium-sized HDMI display with an HDMI interface and a high resolution.

TFT (Thin Film Transistor) is a thin-film field-effect transistor display that is designed to visualize millions of clear, bright, and high-contrast color pixels. Over the years, this display has gained immense popularity owing to its several benefits.

The 7 inch low-cost color display is one of the most popular touch screen displays available for raspberry pi, HDMI display screen and other mini PCs. Featuring IPS screen with larger visible angle and more clear display effect, this 7 inch display with touch screen can be used in all environmental conditions because of its wide temperature liquid crystal fluid.

Microtips Technology has introduced a high brightness High-Definition Multimedia Interface (HDMI) interface IPS TFT LCD module. These modules are compatible and assure seamless interface with any version of Raspberry Pi Single Board Computers (SBCs), PCs, or devices such as HDTV, DVD player, or any device that is compatible with HDMI.

AMOLED (stands for Active Matrix Organic Light Emitting Diodes) display is one of the best screen technologies popularly used in today’s laptop screens and PC monitors and high-end smart phones.

The Thin-Film-Transistor display (TFT display) is an active matrix display where each pixel of the flat panel is illuminated individually. In recent times, TFT display is increasingly used in the electronics industry owing to its several benefits.

Microtips Technology, one of the leading 5-inch color TFT display module manufacturers, has introduced the new low-cost 5-inch color TFT display. The thin film transistor (TFT) technology is just another variant of the LCD technology.

Thin-film transistor (TFT) LCD displays assure improved image quality over traditional LCD displays. They offer more control over colors and images, and require less power than other technologies.

Microptips Technology has introduced a 3.9" bar type TFT display that has a high contrast ratio. This panoramic 3.9 inch RGB bar TFT LCD comes with a resolution of 480x128 pixels. This display is suitable for several modern electronic appliances like server and audio systems, auto/marine equipment, advertising displays, drone controls and many more.

Microtips Technology, one of the leading 4.3-inch TFT LCD module manufacturers, has introduced the new low-cost 4.3-inch TFT display. TFT or thin film transistor is primarily a variant of the LCD technology. TFTs are active matrix LCDs, which help improve contrast, color, and picture quality.

Thin-Film- Transistor displays or TFT displays are active matrix LCD displays that assure better color perception than regular Twisted Nematic LCDs. The demand for TFT displays has increased in recent years owing to several advantages they offer. These displays assure a clear view from any angle, and they can display millions of bright color pixels.

Microtips is proud to announce a new line of HDMI Displays designed to work seamlessly with development boards and computers like the Raspberry Pi. This video outlines our current options for these displays...

Microtips is excited to announce our 10.1”, high bright, TFT display with increased resolution and widened viewing angles. This 10.1”, WXGA 1280*800 TFT display is an IPS panel equipped with an HDMI signal input...

Simple monochrome displays, like 7 Segments & Icons, have been around for a very long time. These displays are still widely used by customers in wide variety of industries. But have you thought about Color TN Displays instead?

Microtips MTD0550AZOM-T is a 5.49 inch display module with a resolution of 1080(RGB) x 1920. This display is composed of an AMOLED panel, driver ICs, On-cell Touch Panel and FPC.

Regional Sales Manager, George, explains OLED Displays, their benefits, and other characteristics that make them better than standard Liquid Crystal Displays for some applications.

Tianma Europe GmbH introduces a new 10.1” wide format Active-Matrix LCD module (“TFT LCD”) with WXGA resolution and PCAP (Projected Capacitive Touch).

The TM101JVHG32 is a new standard touch display with high luminance of 850 cd/m2. The PCAP sensor glass is separated from the LCD surface by an air-gap. The sensor area can detect up to 5 touch points simultaneously.

This display is part of a family. The products from this family have similar outline, the same interface connector, pinout and same touch driver IC. At the beginning the family will include four TFT LCDs: 7” WXGA and 10.1” WXGA, each size with and without PCAP.

This 14-inch LCD display is a ALL o’clock TFT LCD (Thin Film Transistor Liquid Crystal Display) module. This model is Composed of a TFT LCD panel, a driving circuit and a back-light, with a 14.1 inch diagonally measured active display area with WXVGA (1920horizontal by 1080 vertical pixel) resolution in a stripe arrangement. Display 16.7M colors by 6-bit R.G.B signal input. This TFT display is a landscape type 14” TFT LCD panel with 16:9 aspect ratio and with outline dimension 320.39x205.12x2.50mm and active area 309.312(H)x173.988(V)mm, it can be operated at temperature from 0 to 45 degree, stored at temperature from - 20 to 60 degree with typical 30,000 hours LED life time, mainly used for Laptop and TFT LCD Monitor applications.
