Shop for Repair, Replacement Parts and Accessories for your Samsung Model Number UN58J5190AFXZA, Samsung UN58J5190A, UN58J5190 including the main board, motherboard, power supply board, remote control, stand base, stand guide, stand screws, lcd/led display panel (screen replacement) and more.

In 1991, a business unit called Samsung Display was formed to produce the panels used in products made by its parent company, Samsung Electronics. Afterward, it was a leading supplier of LCD panels not just for Samsung Electronics but for other companies in the industry as well.

The business received a stay of execution when the pandemic led to a global surge in demand for consumer electronics, but that demand is now declining, and projections aren"t good for LCD panel revenue.

Add to that the fact that emerging technologies like QD-OLED are the future for TV and monitors, and the case for keeping Samsung Display"s LCD business going becomes a hard one to make.

Samsung Display will now focus heavily on OLED and quantum dot. Most of the employees working in the LCD business will move to quantum dot, the publication claims.

Even if there isn"t a statement about a change in direction, the writing has been on the wall for Samsung"s LCD business. Unless something radical changes, it"s more a question of when than if at this point.

LED TV Chassis : UNE50 Model : UN58J5190AF SERVICE Manual LED TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram UN58J5190AF...

3. Disassembly and Reassemble Description Picture Description Screws Remove screws of Main Board and Power Torque : Board. 7~ 8Kgf.cm 6001-002756 Remove the speakers and power cables. Remove the cables, function assy and Panel drive cable.

3. Disassembly and Reassemble How to reassembly „ Description Picture Description Refer Attach the PTC Bottom first to the Panel. Secure the plastic latch on the left and right side of the PTC as shown.

3. Disassembly and Reassemble Description Picture Description Refer Visually inspect the spacing between the PTC and the Panel for equal clearance. CAUTION Combine to stick the PTC Rib into the middle mold.

ANNEX. Exploded View & Part List ANNEX. Exploded View & Part List [UN58J5190AFXZA IS01] 1-1. Exploded View 1-1-1. Parts List Code No. Description & Specification Q’ty SA/SNA Remark BN95-01724A PRODUCT LCD-INX; v580HJ1,CY-HH058BGNV1H/V BN96-33358A ASSY CHASSIS TOP P; Y14 F-LED 58,PC+ABS+G BN96-30902X ASSY BOARD P-FUNCTION;...

ANNEX. Exploded View & Part List 2-1. Electrical Parts List Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE) Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark UN58J5190AFXZA (IS01) BN90-05304X ASSY W/I;UN40F6400AFXZA BN81-08159Z PART SET-ELEC W/I;UF**,UH**,UG**,ELEC BN81-09500R PART SET-MECH W/I;UH5H,U58HF* S001A BN90-06123A...

2. Product specifications 2. Product Specifications 2-1. Product information Model UN58J5190AF Front View * W : Width H : High D : Depth Detail View Color Front : Black, Stand : Black With Stand 1308 x 843.4 x 295.9 mm / 51.9 x 33.2 x 11.6 inches Dimensions 58"...

2. Product specifications 2-2-2. Specifications Specifications „ Model UN58J5190AF Item Description Screen Size (Diagonal) 58 inches Display Resolution 1,920 x 1,080 Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated Input Sync Signal H/V Separate, TTL, P. or N.

4. Troubleshooting 4-1-9. Other Issues The Problem Try this! Watching TV for an extended period of time causes the panel to generate heat. The heat from the panel is dissipated through internal vents running along the top of The TV is hot. the TV.

4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1. Detail Factory Option NOTE If you replace the main board with new one, please change the factory option as well. The options you must change are "Type". UN58J5190AFXZA „ Inches 58" Vendor PANEL Code BN95-01724A Spec.

4. Troubleshooting Factory Menu Name Data Range PH RATE PD EN PEQ Inx WF Scale WF Type Num of Network Stream DP V Size Backend Device BT_AUDIO_ON_OFF Config_AV_PATH USING_PSI_UPDATE ECO Stanby Fast Logo Delay Num of PANEL KEY Panel Detail Panel Init Time Tcon Init Time WRITE MAC Address...

4. Troubleshooting Factory Menu Name Data Range Panel Temperature LOGIC Waveform Day Logic Check Sum SAPC Timer APC Speed Hotel Option Hospitality Mode Power On Menu OSD Operation Music Mode External Source Eco Solution Cloning Shop Option Shop Mode Exhibition Mode 3D Cube Asia Option Unbalance...

5. Wiring Diagram 5-3. Connector Functions Connector Function Supply main power and dimming signal from IP Board to Main Board. CN201  CNM803 The LVDS signal transfered from Main Board to Panel. CN1401  CON3...
