The NOKIA 5110 LCD screen has a resolution of 84×48(or 48×84, however you read it) i.e. the screen has pixels arranged in 84 rows and 48 columns making a total of 4032 pixels (84*48=4032). So, since a NOKIA 5110 LCD screen is called a ‘Graphical LCD screen’, one has access to all the pixels, i mean, access to control each and every pixel individually(you know what I mean) unlike some of the LCD screens which are named as ‘Alphanumeric LCD Displays’ where one can access a block of pixels, generally 7×5 and place only a single alphabet or a number in that block of 7×5. If you have already worked with some alphanumeric LCD screens earlier(without any libraries), you are half-way done. In case, you haven’t worked with one earlier, no probs. I’ll let you know every possible detail I know.

So, as said earlier, the above image shows the arrangement of pixels in 48 rows and 84 columns( or vice-versa). Just like how each block in a alphanumeric LCD screens is addressed by a unique 8-bit code, every 8 pixels in the NOKIA 5110 LCD screen are assigned with a unique 8-bit address. So, let me explain about this 8 pixels grouping in the NOKIA 5110 LCD screen. Every 8 pixels vertically is grouped, as shown above and let’s call it a block(different from the alphanumeric LCD screen’s block). So, each block has a unique address to access it.

You can use electricity conducting paste with PCB without connecting cable. Metal hooks on the module can repair module on PCB, which is easy to install and can replace them.

This is a low-cost monochrome LCD module comprised of 84x48 pixels that can be used to display rich graphic and text content. Though it"s an industrial module, this LCD display is extremely easy to use. This module is a revision that accepts 3-5V input. So no extra level shifter is needed. To have full control, you just need 5 pins. And as a classic display module among open source communities, there are handful related tutorials available over the Internet. So there is no need to panic even if you just got your foot in the door. Cause Nokia 5110 LCD module was discontinued, this product is made of recycled screen. Blemishes may exist. Please be aware of that. Features Classic display for learning with bunch of tutorials Adequate to general projects Low cost.

This Nokia 5110 LCD Display is a monochrome lcd module comprised of 84×48 pixels that can be used to display rich graphic and text content. Though it’s an industrial module, this lcd display is extremely easy to use. This module is a revision that accepts 3-5v input. So no extra level shifter is needed. To have full control, you just need 5 pins. and as a classic display module among open source communities.

Use serial interface communicate with the master processor, the number of interface signal line reduced greatly, only 8 signal lines including power and GND.

Can use the conductive glue to connect the module with the printed board, without cables. The metal hooks on the module can fix the module on the printed board, which is very easy to install and replace.

The Nokia 5110 LCD is very popular among the Arduino tinkerers. These modules are used on wide variety of applications that require some sort of interface or display data to the user.

Nokia 5110 LCD Module can be powered by 3.3V to 5V. But it is recommended to use with 3.3V. It consumes very low power as less than 3mA when no backlight is used.

All necessary functions for the display are provided in a single chip, including on-chip generation of LCD supply and bias voltages, resulting in a minimum of external components and low power consumption.
