Passing on the cheaper cost, I am please to supply the module at £16 plus postage, payable via bank transfer or paypal, pm me for details and availability.

To you and any new forum members, if you can see your post, you can pm. Your first post needs moderator approval, but once that is done, you can then send pm"s

Yes - they are made available on a replication of the GPIO port on the shield pcb - you can just see part of the silkscreen through the top left mounting hole of the TFT pcb in the picture.

just to confirm the current requirements - when the Pi is first switched on, and the display is uninitialised, the current drawn by the display + backlight is 28.1mA.

Once the display is initialised during the boot sequence, current goes down to 26.2mA. It doesn"t matter if the display is dark or white, it draws the same. This is from the +3.3v rail.

I"m looking to display twitter messages and strugling to find an interface display that can show the 140 character messages. I"m currently experimenting with a 20 character x 4 lines LCD

Well it"s a graphic display with 128 x 160 resolution. This means it uses fonts just like Windows for example, rather than a character display like the 20 x 4 you mentioned. So typically you could fit typically 26 x 16 character on screen assuming 5 x 7 font. See the pygame example for an example if displaying text.

Can some one refer me to the available tutorial or suggest what to do for dc pin mentioned in the below tutorial.I have not connected it because i dont want to break my tft

Once the display is wired correctly (with level converters if needed) then it is a case of finding the right library for the driver chip that is fitted inside the TFT screen.

Maclight have whole series 1.8 inch tft lcd module, our standard 1.8 inch tft lcd have the resolution with 128x160 pixels, with MCU/SPI/RGB interface. our 1.8" tft touch screen could custom make capacitive touch screen( CTP / PCAP), to the 1.8" PCAP, frame bonding and optical bonding to the CTP is welcome to us. to the 1.8 inch capacitive touch, we could custom make the CTP cover glass with 3mm cover glass and anti-finger print, anti-glare surface treatment. Maclight 1.8 inch tft lcd display is also including 1.8" sunlight readable tft lcd display with 1000 nits high brightness tft lcd, that is suitable for outdoor application. The FPC of our 1.8 tft lcd could custom make base on your requirements.

Pacer offers an extensive range of colour TFT LCD panels from 1.8″ through the popular 3.5″ and 5.7″ sizes to 82″. Our range includes sunlight readable panels from 5.6″ to 70″, bar cut panels, and SMART TFT displays with built-in control. We offer TFT displays with high brightness, high contrast ratio, wide viewing angle, wide temperature operation, longer lamp life, and lower power consumption.

TFT displays are used extensively in many industrial, commercial and scientific applications, including ATMs, POS terminals, kiosks, security systems, lottery and gambling gaming machines, medical equipment, factory automation, digital advertisement signage, transportation information, and marine equipment.

TFT technology is being used to replace Mono LCD in many applications, and Raystar Optronics now offers a 5.2″ TFT module designed specifically to fit the footprint of the industry standard RG24064-series 240×64 mono graphic STN LCD. The RFS520A can replace traditional STN displays of 8×2 or 16×2 format as it shares the same 16 pin footprint.

Our TFT modules are fully supported with a variety of options including wide operating temperatures, high brightness and contrast, built-in DC-DC and temperature compensation circuitry and most with white LED backlights. Resistive Touchscreens and Projected Capacitive Touchscreens are available for most models. Many panels can be configured as a kit – see our Interface Kits page for more details.

IMPORTANT ANNOUNCEMENT – Mitsubishi has decided to end production of TFT-LCD modules, as the company is no longer able to maintain the products’ competitiveness after significant price falls in the global market. Production of TFT-LCD modules is scheduled to end in June 2022 with a Last Time Buy date of June 2021. Please contact us as soon as possible to discuss last time buy or identification of suitable alternative displays.

Raystar is a professional TFT (Thin Film Transistor) module manufacturer. Whether you need a TFT display with control board, high brightness, wide viewing angle, monochrome or bar type, we have TFT active matrix display models for you to choose from.

Mitsubishi’s Electric Diode InfraRed sensor (MelDIR) is a thermal sensor for applications in the fields of security, surveillance, crime prevention, people counting, heating, ventilation and air conditioning (HVAC) and smart buildings.

LITEMAX® Industrial Display solution provide a wide range of reliable displays from 5.7″ to 85″ including LCD panel modules, open frame LCD displays, outdoor displays, and panel mount monitors. LITEMAX have developed and focused on LCD display technologies such as high brightness technology, optical bonding solutions, and color enhancement technology that bring more add-on value to enhance their products.

This is a single-chip controller/driver for 262K-color, graphic type TFT-LCD.  It consists of 396 source line and 162 gate line driving circuits. This chip is capable of connecting directly to an external microprocessor, and accepts Serial Peripheral Interface (SPI), 8-bit/9-bit/16-bit/18-bit parallel interface.
