pcap tft display pricelist

1st generation: with flat display area and flat touch area, the border can be curved. Orient Display uses glass touch sensor and IML (In-Mold Lamination) technology to produce the products.

2nd generation: with flat display area and flat touch area, the border area can be flat or cuver in the middle. Orient Display still uses glass touch sensor and cold bending lens to produce this kind of products.

3rd generation: with flat display area and curve touch area, the border area can be flat or cuver in the middle. Orient Display uses glass or film touch sensor and hot bending lens to produce this kind of products.

4th generation: with curve display area and curve touch area, the border area can be flat. Orient Display uses flexible touch sensor to produce this kind of products.

Based on the above five types of touch panel technology, Orient Display can also add different kinds of features like different material glove or stylus or pencil touch, water environment touch, salt water environment touch, hover touch, force (3 dimensional) touch, haptic touch etc. Orient Display can also provide from very low-cost fixed area button touch, single (one) finger touch, double finger (finger+ gesture) touch, 5 finger touch, 10 points touch or even 16 points touch.

Considering the different shapes of the touch surface requirements, Orient Display can produce different shapes of 2D touch panel (rectangle, round, octagon etc.), or 2.5D touch screen (round edge and flat surface to create edge-less impression) or 3D (totally curved surface) touch panel.

Considering different strength requirements, Orient Display can provide low-cost chemical tampered soda-lime glass, Asahi (AGC) Dragontrail glass and Corning highest generation Gorilla glass. With different thickness requirement, Orient Display can provide the thinnest 0.5mm OGS touch panel, to thickness more than 10mm tempered glass to prevent vandalizing, or different kinds of plastic touch panel to provide glass piece free (fear) or flexible substrates need.

Orient Display can also provide full customized or part customized solutions for our customers to enhance the viewing experience. Orient Display can provide all the different kinds of surface treatments, such as AR (Anti-reflection); AG (Anti-glare), AF (Anti-finger print or Anti-smudge); AS (Anti-smashing); AM (Anti-microbial), IMITO (Index Matching Indium Tin Oxide), Anti Sparkling etc.

Orient Display can also provide both dry bonding (OCA, Optical Clear Adhesive), or wet bonding (OCR, Optical Clear Resin and OCG, Optical Clear Glue) to get rid of light reflective in air bonding products to produce high end touch screen monitor much more readable under sunlight and much more robust as well.

Touch panels have been a much better human machine interface which become widely popular. Orient Display has been investing heavy for capacitive touch screen sensor manufacturing capacity and LCD module production ability. With Orient huge production capacity, top notch quality, and competitive pricing, Orient has been working with top LCD panel manufacturers ,AUO, BOE, LG, Innolux and top touch controller manufacturers , Atmel (Microchip, Cypress, Synaptics, Elan, NXP, Goodix, Sharp, Hydis etc. to provide the best touch display technology in the market, such as IPS, MVA, in-cell, on-cell, automotive grade etc.

It is a new technology replace ink printing cover plate with visual area and black border area are integrated with seamless black design using AG/AR surface treatment. Non ink printing AR/AR seamless black optical cover plate can be customized to match touch display module to achieve the best integrated seamless black solution.

Orient Display developed a special smoke film which is very low cost but gives the customer a optical bonding performance. Smoke film uses optical interference to reduce the glass-air interface reflection for air (perimeter) bonding between LCD and touch screen.

Take your design to the next level with our range of TFT Displays including latest IPS TFT, circular and bar shape as well as large size TFT. With or without touch, these are fully customisable to your system requirements.

TFT-LCD technology is now fairly mature. As a result, manufacturing processes are efficient and production yields are high, leading to very competitive unit prices. Upgrading from a monochrome display to a TFT is now an affordable way to give your product an uplift.

Users of industrial display devices are wanting the same experience they have come to expect from a consumer device with all-round viewing angles. Switching to a superior IPS TFT display has become very cost effective as production increases and unit prices decrease.

Choosing a circular display for your next product design could really set you apart from your competition. Models are available from 1" to 4.2"in TFT, PMOLED and AMOLED, we have something to suit every application.

It is now possible to transform from a monochrome display to a colour display in space constrained systemsby using a letterbox shaped display. These ultra-wide displays are ideal for applications with restricted build height such as rack mount systems or landscape format front panels.

Large TFT display systems are increasingly being used for transportation information, retail signage and vending machines and kiosks. We can supply a large range of TFT solutions up to 65" diameter and in bar-style, square or rectangular configurations.

We are now offering increasing cover lens customisation options and processes to make your TFT LCD user interface truly stand out! Anders’ experienced marketers and engineers work with our manufacturing partners around the world to keep informed of the latest innovations, including mirrored glass,tinted glass, spot-facing, three dimension glass, and many more!

Here at Anders we don"t just strive to design a best in class display solution for your product, but we also want to make sure the display is driven with the right embedded system. We can help achieve a hardware solution that ensures your display works perfectly within your application. Hardware solutions include:

Get started quickly on your new user interface with our HMI development kits. The display, the processor and the OS work together out of the box with optimised QT GUI images. We"ll then optimise the kit to meet exactly your system requirements with our design services.

At Anders we understand that no two customers are the same, which is why we specialise in custom display solutionsand offer unique productstailored to your end application.

See below our range of TFT Displayswith sizes ranging from0.96" to 64.5" and including circular and bar type shape. All our displays can be tailored to suit your application antimicrobial coating technology,

We aim to offer reliable and long-term solutions to our B2B customers. If you are a business and would like to discuss your display and/or embedded system requirements please contact us below

A TFT display is a form of Liquid Crystal Display with thin film transistors for controlling the image formation. The TFT technology works by controlling brightness in red, green and blue sub-pixels through transistors for each pixel on the screen.

There are many display technologies, but do you know which one would be better for your application? Particularly when considering optimum viewing angle and contrast. We discuss 2 of the best options.

Compare IPS vs TFT displays - the TFT display is the display of choice for industrial designs, but it can have its limitations. A newer technology called IPS (in plane switching) offers better viewing angles and colours, but is it really the best choice - we discuss benefits and negatives of both types of TFT display.

WF0200BTYAJDNG10 is a 2-inch Portrait Mode IPS TFT-LCD display with a Projected capacitive touch panel (PCAP) resolution of 240x320 pixels. This TFT module is built-in with ST7789VI driver IC; supports MCU and SPI interfaces; the PCAP touchscreen is built-in with GT911 IC, which communicates via the I2C interface. The WF0200B TFT series has without touch panel option; please check our webpage of WF0200BSYAJDNN0 (with high brightness) for more detailed information.

WF0200BTYAJDNG10 is adopted IPS panel which is having the advantage of wider view angle of Left:80 / Right:80 / Up:80 / Down:80 degree (typical), contrast ratio 800:1 (typical value), brightness 400 nits (typical value), aspect ratio 3:4, the supply voltage for analog 2.4V to 3.6V, typical value 3.3V. This TFT module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃.

WF22GN5AB2DNN0 is a 2.13-inch Portrait Mode Mono TFT display with an LPRD (Low Power Reflective LCD) resolution of 122x250 pixels, built-in ST7306 driver IC that supports 8-bit MCU, 4-line SPI/3-line SPI interfaces. This WF22G Mono TFT series adopted a Reflective type LCD, which has the below advantages:

WF22GN5AB2DNN0 adopted mono TFT with LPRD technology featured of view angle of Left:65 / Right:65 / Up:65 / Down:65 degree (typical), the supply voltage for logic (VDDA) is 2.55 to 3.6V, with the typical value of 3.3V, aspect ratio 18:9, anti-glare glass. This Mono TFT module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃.

WF101JSYFHLHBV is a 10.1-inch high brightness version IPS TFT display with resolution 1024x600 pixels. WF101JSYFHLHBV has a PCB board featuring an HDMI connector that supports HDMI signal (only for DVI) interface and has a 40-pin GPIO connector designed to make Raspberry Pi usage easy. This module featured four studs for the backlight, and the PCB adopted the locking method attached to the module. WF101JSYFHLHBV is adopted IPS panel which has a wider viewing angle of Left:85 / Right:85 / Up:85 / Down:85 degree (typical value). This TFT model is built-in with EK79001HN and EK73215BCGA driver ICs, high brightness of 950 nits (typical value). This TFT model is built-in with ILI2511 touch panel driver IC on the module, which supports USB interface, and single-touch or multi-touch (option) detection points.

WL0F00050000FGAAASA01 is a 5-inch high brightness TFT Smart Display CAN series display that is running CANopen protocol via CAN bus command to render display content on the screen and return touch event data with protocol objects. WL0F00050000FGAAASA01 features Winstar high brightness IPS TFT WF50FSWAGDNG0 and a 4-layers FR4 PCBA built-in firmware code developed by the Winstar RD team. This 5" CAN series TFT is an easy-to-use product that allows you to create projects rapidly and cost-effectively.

Winstar already developed Windows Apps (GUI & GUI Builder) for Smart Display GUI design. This 5" IPS TFT Smart Display can use a computer with USB2CAN dongle or Raspberry Pi (+PiCAN2) or even an MCU scale like Arduino (+CAN adaptor) as a HOST platform. Winstar GUI builder software is designed for customers to simulate their UI design in advance using the drag-and-drop Widget preview function. Furthermore, customers can create their ideal UI objects using this software and then go through simulation to check UI design without a hardware module. Winstar GUI builder software only supports the Windows system; it can fulfill What You See Is What You Get (WYSIWYG).

Winstar developed a Windows app. for Smart Display GUI design. Winstar GUIbuilder software allows customers to simulate their GUI design in advance using the drag-and-drop Widget preview function; customers can also create their ideal GUI. Winstar GUI builder software supports Windows systems only; it can fulfill What You See Is What You Get (WYSIWYG). The upgraded version of built-in software is a 3-in-1 APP; we combined three application templates for optional, including industrial, vehicle, and medical applications. Please press the preferred application and hold power on for 3 seconds the first time. Customers can change to another template by using GUIbuilder to change the application.

Smart Display has been widely used in various fields such as medical, industrial control, and automotive after products launched. Simply put, it is a display combined with a microcontroller, which can handle complex graphics loading, setting, display, and even input, and the outside device (host i.e.) can perform interactive operations with simple commands, so it is very suitable for various needs. Various types of applications displayed or controlled.

Smart Display supports a variety of communication interfaces. Currently the most commonly used ones are CAN/CANopen, RS485/Modbus, and more choices will be provided in the future. Among them, RS485/Modbus is a popular communication interface in the industry, and various RS485 devices at reasonable prices are easily available on the market. The line structure is simple, as long as two wires (RS485_A/RS485_B) can communicate, and the communication interface is usually presented in the form of "Serial Port" on an operating system, and each platform has a corresponding development function library. In addition, the Modbus protocol is quite easy to understand, so we put it as an example as following for experiments and explanations.

This article will introduce how to control Smart Display from simple to deep, understand its control principle, and finally introduce how to make cross-platform applications. Whether you are an industrial equipment expert or a DIY player, welcome to the world of Smart Display with us!

In order to understand how to collaborate in Smart with a host. First issue we need to get the control code. The easiest way is to get it from Smart Display GUI Builder. GUI Builder is an excellent support software for Smart Display. It can help us learn, operate, design, and display user interface without hardware physical device, design UI without writing any program at all. With the WYSIWYG feature, user interface design can be done by dragging or clicking buttons or objects. In addition, there is a built-in simulator that shares source code with Smart Display, thus ensuring the same appearance and behavior as the physical device. Even better, it"s free!

Double click GUI Builder to run the app in Windows OS, open a project. Here we choose the 5" RS485 Smart Display WL0F00050000FGDAASA00, and the default scenario below is Vehicle. Input the project name, press Create button to create project. If it has been created before, you can also select project directly from the menu on the right.

Select RS485 for the Interface, and the RS485 Port of host should be set as the actual port of the connected port for RS485 dongle. If there is any doubt, you can check the port name in the device administrator (repeatedly unplug it and see that it disappears or shows which one is displayed). Baudrate can keep the default value of 115200.

However, if there is no Smart Display RS485 device yet, it does not matter, as long as the Interface selects RS485, the RS485 Port can be ignored for now, because now we will just utilize the simulator, and will not connect to the Smart display device practically.

Every action will see two commands TX/RX, because the display device (even if it is actually an emulator now) will send back the same command as acknowledge after receiving the command to indicate that it has been received.

For Smart Display control programs, the most commonly used are 06: Write single register (write a 16-bits value) and Read holding registers (read the value of multiple registers).

Use 03: Read Holding Registers/16: Write Multiple Register to read and write. These data affect the appearance of objects and usually do not change outside the design stage. To change the content, the Smart Display must be temporarily turned off before it can be updated.

Early Smart Display supports only 10 objects, so the widgetID range is 0 ~ 9 (inclusive). The new version of the firmware has been expanded to 64, but the addressing method has been changed, which will not be discussed here.

With these data (although not complete, but enough for now), we can package the control instructions and send them to Smart Display for control. As for how to pack and how to add CRC code, it will be explained in the following chapters.

In order to put Smart Display into practical application, a suitable human-machine interface (especially Graphics User Interface, GUI) is still needed to maximize its effectiveness. At present, there are many choices for the cross-platform GUI development platform, and we use Qt to implement it here.

The previous example is only for a setting of the object value. There is a more complete example SmartDisplayConsole application program for interested readers to learn more about. The following picture is the execution screen on the Raspberry Pi:

We have explained every step of controlling the Smart Display, and also provide a variety of control methods. Using this knowledge and rich imagination, I believe that various sparks can be stirred up and more diverse products can be produced. Let"s create a better future with Smart Display together!

OTL195 is a touchmonitor using industrial grade LED, with low power consumption, ultra-thin body design, high resolution display and excellent multi-touch interactive experience. Compared to the average consumer TV or monitor, the OTL195 industrial-grade high performance and professional design is better suited for  applications in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education and healthcare.

Chino, CA, March 1, 2021– Tianma, a leading global manufacturer of flat panel displays, has introduced a new product family of TFT LCD Modules (Thin Film Transistor - Liquid Crystal Display). The new P-Series (Professional Series) of standard products is dedicated to support the various requirements of the industrial and medical display markets. The first products in this new series will include XGA displays (8.4”, 10.4” and 12.1”), as well as wide-format products, from 7” WVGA to 13.3” FHD.

The P-Series display products will be available in three grades – Advanced, Basic and Entry – to better support the different customer needs in a variety of markets, including a range of features and product specifications around pixel density, viewing angle, contrast ratio, color gamut, black level uniformity, etc.

The Basic grade of P-Series displays will offer a very good performance-to-cost ratio, meeting the standard specification and performance requirements of the market with typical brightness ratings and long-life LED backlights. The Entry level provides more cost-effective solutions for price-sensitive markets and applications.

P-Series modules will be available with Tianma’s PCAP (Projected Capacitive) touch technology, featuring Tianma designed and manufactured PCAP touch sensors. PCAP will be integrated in-house, with optical bonding or air gap (perimeter bond) construction. Wet & Glove touch sensing technology is available for high-end devices, and customized cover glass is optional.

All three grades of the P-Series family will be available in production for a minimum of five years (typically seven years or more) with a small minimum order quantity (MOQ). The P-Series will also be engineered around dedicated design rules to meet the particular requirements of the professional market. Further, the manufacture and assembly of the TFT-LCDs and PCAP sensors will all be done in-house, with industrial level driver support.

Samples from the initial P-Series product offering will be available starting Q1 2021. These first displays will include wide-format 7” WVGA, 10.6” WXGA, and 13.3” FHD products, in the Advanced high brightness versions. The first products with 4:3 format will all have XGA resolution and include both Advanced high brightness and Basic, in sizes 8.4”, 10.4” and 12.1”.

Regarding Tianma’s legacy Professional TFT LCD products, both standard TM-series and all NL-series modules will be promoted alongside the new P-series product offering. All of these products will remain in production and will continue to be fully supported.

Tianma America (TMA) is the leading provider of small- to medium-size display solutions to the Americas market utilizing advanced technologies and manufacturing resources of the Tianma Group Companies, which includes Tianma Micro-electronics (Shenzhen and Shanghai) and Tianma Japan, Ltd. (formerly known as NLT Technologies Ltd.), as well as manufacturing locations in Chengdu, Wuhan, Xiamen, Shenzhen and Shanghai China. Tianma America technologies can be found in smartphones, tablet PCs, industrial and medical instrumentation, wearables, home automation, household appliances, office equipment, and automotive and rear seat entertainment devices. Additional applications include test and measurement systems, instrumentation equipment, point-of-sale and ATM systems, gaming systems, global positioning systems, radio-frequency identification devices and barcode scanners.

Tianma America’s technology portfolio comprises TFT, LTPS, Oxide-TFT, AM-OLED, flexible, transparent, 3D, PCAP and In-cell/On-cell integrated touch. With a network of best-in-class distributors and value-added partners, Tianma America provides complete display module solutions for a broad base of customers and applications.

This industrial display belongs to the Schneider Electric"s Harmony P6 range. This 2 point multi-touch projected capacitive HMIDM6 display has a glass-top surface design with backlight service life of 50,000 hours. HMIDM6600WC is a W12.1 inch screen of 16 million colors and 1,280 × 800 pixel resolution (WXGA). Three touch mode configurations are available namely Standard mode, Glove mode, and Water detection mode. The modularity of the iPC display facilitates fast deliveries, multiple choices, easier mounting, and optimum ergonomics. The front panel when properly installed in an enclosure provides IP66F, IP67F, Type 1, Type 4X (NEMA indoor use only), and Type 13 degree of protection. The power consumption when this DM6 display is paired with P6 Advanced Modular Box is 158VAmax. (AC model) and 138Wmax. (DC model), with P6 Standard Modular Box is 79VAmax. (AC model) and 69Wmax. (DC model). Its dimensions are 308.5mm (width) x 230.5mm (height) x 30mm (depth) and weighs 2.60Kg. Harmony P6 industrial PCs caters to the complex machine, line monitor and processes at Edge Control and Apps Analytics level of EcoStruxure. It complies with CE, RCM, UL 61010-2-201 and CSA C22.2 No. 61010-2-201 for both AC and DC models. They are configurable noise-resistive touch drivers. This display when combined with any of the Harmony P6 Boxes makes a Panel PC. It can be mounted on front enclosure or VESA 100 × 100 mount on the rear of Box PC. The stylish wide Harmony P6 displays provide high visibility during operation featuring glass-top capacitive multi-touch panel with narrow frame and thin design. The Harmony P6 online Configurator with enlarged line-up offers many possibilities and when linked with EcoStruxure Plant Builder eases the design of complete automation architectures and solutions.
