optically bonded lcd monitors in stock

Alibaba.com offers 233 optical bonding monitors products. such as return and replacement, call center and on-line technical support, and repair. You can also choose from led, lcd. As well as from new, stock, and open-box. And whether optical bonding monitors is for home and student, or industrial.

Optically bonding an LCD, OLED or Plasma display improves both optical performance and durability. By selecting an appropriate adhesive that matches the index of refraction of the flat panel and the overlay, General Digital is able to remove all of the air gaps, thus reducing the number of internal reflecting surfaces that can lead to degradation of optical performance. Providing a durable adhesion between the flat panel and the overlay improves the displays’ ability to resist shock, vibration and moisture.

On the practical side, the adhesive must also provide adequate bond strength, have a reasonable pot life after preparing, not present any health or safety issues, be available at reasonable cost from reliable sources, and cure to the proper finished bond condition using temperatures and times that are friendly to optical bonding facilities. Fortunately, there exist a relatively large number of choices. Typical bonded overlays include contrast enhancement filters, EMI/RFI filters, vandal shields, touch screens, and thermal heaters.

Bonded display assemblies mimic shatterproof glass. Although the bonded overlay can fracture from impact, the adhesive prevents/minimizes broken pieces from becoming airborne and endangering the operator and other nearby personnel.

The in-the-frame design is currently in limited production, primarily for avionic applications. The adhesive is epoxy, which was selected so that the bezel could be affixed to the display’s metal frame, with the bonded antireflective glass extending into the opening, reducing any issues of viewing angle and parallax to the display.

One drawback to the under-the-frame and in-the-frame bonds is that they are not suitable for making a liquid-proof seal to the bezel of the monitor. To accomplish this, monitor builders usually prefer to form a seal to the antireflective glass. In this case, an over-the-frame bond is necessary. This bond design is also required in the case of an optically bonded touch sensor. The details of the bond may vary slightly, depending on the nature of the overlay. However, in general, an appropriate gasket is placed onto the face of the OEM frame, forming a well-defined bond thickness and protecting the edge of the seal from abrasion.

It is, of course, possible to bond more than one overlay to the display. A specific example is the use of a conductive glass to control EMI, which is bonded to a touch sensor. As of this writing, General Digital Optical Bonding Laboratories has produced over 475 displays of this design for an aerospace application.

This bond design is the preferred over-the-frame bond. A gasket is applied between the LCD, OLED or Plasma display and the overlay and the space between them is then filled with adhesive.

Catch up on the latest news from General Digital, including upcoming and newly released LCD monitors, display enhancement services, accomplishments, contracts, certifications and other noteworthy items of interest.

All TTVs use a series of locking mechanisms to allow users to set the display to their preferred viewing angle while securing the large LCD panels against high-shock events.

Specializes in designing and manufacturing industrial- and military-grade monitors, smart displays, computers, control electronics, systems integration and more

General Digital is excited to announce GenGard F801™, the next revolution of LCD bonding, specially processed for high altitude (up to 60,000 feet), extreme temperatures (-45° and beyond) and severe shock and vibration.

First, although our monitors and certain peripherals are built from mostly aluminum (and a lesser amount of steel and stainless steel) in order to withstand harsh industrial and military environments, they also contain many other materials, which have no tariffs levied against them.

With a disc drive integrated into your unit, no more will you waste valuable time fumbling with extra wires and looking for open USB ports. The combination of the Blu-ray drive and General Digital high definition displays (including ultra clear sunlight readable and optically-bonded screens) ensures you will enjoy the best possible viewing experience.

For years now, General Digital has offered dual mode displays, meaning that the LCD is capable of being sunlight readable and NVIS compatible. And the dual mode design is not off-the-shelf; we spent countless man-hours developing and testing our own unique configuration to better serve our customers. We are pleased to announce that we can now offer several displays that not only are dual mode, but have Full HD Resolution (1920 x 1080), as well. This means even sharper, cleaner images in bright sunlight or when wearing night vision goggles. The LCD sizes available as of this writing are 15.6", 17.3", 18.5" and 21.3", with more to follow soon. Any of our displays are easily incorporated into an enclosure to suit your application. For more information, please contact a Sales Engineer.

We’ve been busy creating data sheets for many new Display Head Assembly ( DHA) products. We offer DHAs in standard sizes from 6.5" to 24", though we can accommodate nearly any size our customers require. Most displays we offer can be equipped for sunlight readability, use with night vision goggles, glare and reflection reduction, EMI shielding, touch screen overlays and much more. You can download the released data sheets for review on our DHA page. On a related note, we have also released our Display Product Line-Up Sheet, in PDF format, of many of the optically-enhanced DHAs we produce. Included on this sheet are the basic specifications of the displays to help you decide which will best suit your needs. Contact a Sales Engineer with any questions you may have, or for a no-obligation quote.

General Digital has just finished constructing our first 4K monitor. The first configuration is equipped with a 23.8" LCD, though other sizes will be available soon (27", 30" and larger). The 3840 x 2160 resolution screen displays 1.07 billion colors at a contrast ratio of 1000:1. Enclosed in our rugged Saber Standalone housing, this ultra high definition display is ideal for industrial and military applications. It features DVI-D, HDMI (x3), and DisplayPort video inputs, as well as an internal AC power supply. Call a Sales Engineer today to discuss how we can configure a 4K display that will suit your requirements.

General Digital is pleased to announce the release of our Barracuda PanelMount Solar/NVIS 901D marine-grade MIL-STD-901D-compliant 15.0" and 17.0"LCD monitors, complete with sunlight readable and NVIS-compatible displays. Environmentally sealed to meet IP67 standards, and equipped with advanced features like an EMI micro-mesh filter, military-grade +9 to +36 VDC power supply, optically-bonded touch screen, circular polarizer and 1/4-wave retarder to enhance contrast in high ambient light conditions. The waterproof Barracuda is ideal for shipboard, ground vehicle and mobile applications. Download the 17.0" data sheet to learn more, and then call a Sales Engineer today to discuss how we can configure a Barracuda display to perfectly meet your needs.

General Digital’s Optical Bonding Laboratories has successfully applied an antiglare film film to a large format 55 inch LCD monitor. A large form factor display can be quite a challenge to work with, but our team’s patience and expertise paid off. This display will be used in an avionic simulator by our customer, a prominent force in the aviation industry. Next, we are looking to tackle an 84 inch display.

Our sales team enjoyed great success after visiting many customers and prospects in the Charleston, South Carolina, and Huntsville, Alabama, areas. We introduced our new VueSim smart monitor for simulators, and other monitors with dual mode LED backlights that are both sunlight readable and NVG compatible. Everything we presented for all of the programs stimulated great interest. Many future opportunities exist for our Saber PanelMount, Titan Lite, and VueSim variants.

General Digital debuted the newest iteration of our VueSim HMI™ flight simulator monitor at I/ITSEC 2015. The 7104 model is a smart monitor that accepts ARINC 429, as well as Ethernet signals, successfully displaying its versatility. Featuring bonded glass and a high quality display with guaranteed 10-year product availability, the 7104 is available with many options, including sunlight readability and night vision goggle compatibility. Another option is an extended color gamut, displaying a more dynamic color range of its high definition graphics.

To accompany this advanced simulation display, we designed two software applications for simple operation by the end user: VueSim Author™ for creating high quality user-defined graphics; and VueSim RT™, which reads aircraft data and renders graphics to display on the LCD.

General Digital has been awarded a contract for 240 custom Barracuda 6.5" waterproof monitors. The 1024 x 768 resolution sunlight readable displays will be compatible with night vision goggles. The desert tan Barracudas will be sealed to IP67 standards and built to meet many military specifications.

General Digital has been awarded yet another contract for our Titan monitor—this time for eighteen Titan Standalone 65.0" units for the Canadian Navy’s Arctic Patrol Ships. The monitors will be equipped with mutiple video inputs, including Dual DVI-D, HDMI, VGA, Composite BNC and HD Component. The displays will be shatter resistant, and have an antireflective and ITO-coated protective glass overlay. Also included is an internal power supply, USB pass-through port, stereo speakers and IR Remote Control.

General Digital has enjoyed great success supplying our Titan Series of monitors to the U.S. Navy for Los Angeles- and Virginia-class submarines, not to mention future Ohio-class subs. Our Titan PanelMount 39.0" LCD monitors have been selected for the retrofitting of Brazilian Navy Submarine plotter tables. We will provide a rugged tempered glass overlay for the plotter tabletop to protect the Titan monitor and other electronics within the table enclosure. We were awarded this contract in conjunction with the recommendations and support of the U.S. Naval Undersea Warfare Center (NUWC) and Lockheed Martin.

General Digital is nearing completion of our completely redesigned FAA air traffic control tower monitor, the GenStar IV™. Available with either a 19.0" or 21.3" display, our newest GenStar LCD monitor features a host of improvements over the previous generation, including an Advanced Display Interface System, active monitoring and reporting of system performance and faults, dual ambient light sensors, a field-replaceable power supply, and a 2.00" reduced depth enclosure.

As promised, our upgraded outdoor 19-inch Barracuda LCD monitor product line has arrived. It recently demonstrated its capabilities by enduring the rigors of our submersion chamber, meaning it has to remain under water at a depth of 1 meter for a minimum of 30 minutes. Sporting the compact design and sleeker look of its 15-inch and 17-inch predecessors, this IP67 environmentally sealed model can support an increased variety of video signals, as well. All Barracuda models are available in rack mount, panel mount and standalone enclosures, and can be configured with sunlight readable displays.

General Digital’s Barracuda line of waterproof and IP67 environmentally-sealed LCD monitors continue to grab attention. Oriental Express Rickshaw, a pedicab company serving Universal Orlando Resort in Florida, plans to install our 15-inch Sunlight Readable Barracuda Standalone into its pedicabs. With a bright, easy to read and completely weatherproof display, our outdoor monitors will enable local advertisers to promote their products and services while customers are shuttled from one location to another. Watch the Pedicab video.

First introduced in 2008, our Barracuda™ line of waterproof and IP67-environmentally sealed LCD monitors is undergoing some important changes. With 15 inch and 17 inch models already available in rack mount, panel mount, and standalone configurations, a 19 inch monitor is coming soon. Eliminating the large bezel that once characterized the Barracuda, this redesign will feature a more compact enclosure. Sporting a sleeker look, the new design will prove more configurable, thereby reducing expected lead time from order placement to delivery. A more cost-effective Barracuda: yet another innovation from General Digital.

From June 5–7, General Digital’s Optical Bonding Laboratories business unit exhibited at SID Display Week 2012 at the Boston Conventions and Expositions Center in Boston, MA. The SID (Society for Information Display) trade show is a great venue in which to see up close the latest display and display accessory technologies. We had several monitors on display, showcasing numerous innovations Optical Bonding Laboratories has recently developed:

8.4" Barracuda PanelMount, Sealed Enclosure, Transflective Display Optically Bonded with GD Proprietary Cold Temperature Formulation, Tested to -55° C

General Digital has redesigned the 19" rack mount sleeve unit for the SlimLine Lite II™ Series of rugged flip-up LCD monitor / keyboard / trackball, including the sunlight readable models. One unit is designed for use with the 15" model, the other is for use with the 17", 19", and 20" models (the only difference being the length of the slides). The chart below highlights the major changes and advantages.

General Digital is now accepting orders for rack mount flip-up LCD monitor / keyboard units, and an integral CAC (Common Access Card) Smart Card Reader. Previously available with only our SlimLine Lite II, we are now offering the convenience of Smart Card technology in our SlimLine 1U and TwoView products. Mounted to the front of the unit, this small device simplifies access to sensitive data, while providing the security that data requires. Contact us for a free consultation to determine if your application will benefit from an optional integrated Smart Card Reader.

Already available in display sizes from 15 to 19 inches (diagonal), a 20-inch TwoView will soon be making its way to the production floor. While continuing to offer all the features of our other TwoView models, these 3U high rack mount, dual flip-up flat panel LCD monitors will grant even higher resolution (1600 x 1200) and greater viewing area to our customers. Other new features include an integrated power supply, a host of video inputs and an optional KVM switch. As always, sunlight readable variants are on the roster. These new models are coming soon, so keep an eye out for these latest additions to our ever-increasing line-up of industry innovations.

General Digital is in the early stages of engineering a slim profile, touch sensitive, widescreen 24" LCD monitor with integrated power supply. The 300 nit LED backlight ensures consistent brightness acrosss the display face, while the SAW (Surface Acoustic Wave) touch screen improves user interface. The modified Saber Standalone also features standard VESA mounting capability, as well as a built-in, front-monted speaker. This commercial-/industrial-grade monitor is slated for release in 2011.

In addition to a revised web site, General Digital is implementing a new naming structure for its RGB and Chassis Monitor line of LCD monitors. This change was instituted in an effort to simplify our many LCD product offerings. Therefore, the RGB and Chassis Monitor lines (PanelMount, RackMount, Industrial) will be merged into the Saber Series (PanelMount, RackMount, Standalone). The OEM Monitor Kit and Chassis Monitor Kit will be merged into the Impact Series. Also, the extension of Solar to any model name indicates that the monitor series is available with daylight readable and sunlight readable capability. The model number system will remain unchanged.

General Digital is incorporating more of its rugged LCD monitors with LED backlit displays. LED backlights have several advantages over CCFL (cold cathode fluorescent lamp) backlights: they"re able to withstand harsher shock and vibration environments, they can easily operate at temperatures as low as -40° C, their low voltage allows them to run at high altitudes with no risk of arcing, their low IR (infrared) signature makes them ideal for NVIS (Night Vision Imaging System) applications. General Digital has designed and sold several systems with display sizes of 8.4" to 20.1". Contact a Sales Engineer today to discuss how LED backlighting can benefit your application.

General Digital’s popular 1U high (1.75") SlimLine 1U™ flip-up LCD monitor/keyboard and SlimLine Micro™ flip-up LCD monitor will be available in 2U high (3.50") versions. Built just as rugged, the new models (unnamed as of this writing) will incorporate many peripherals in the lower layer of the enclosure, such as a CD/DVD drive, smart card reader, auxiliary USB ports, integrated AC-DC and/or DC-DC power supplies and more. Stay tuned for more info or contact a Sales Engineer.

Briefly, the TwoView is comprised of two high-resolution LCD monitors (15", 17" or 19"), with an enclosure that has been beefed up to handle the extra load of dual monitors.

The General Digital-designed Intelligent Backlight Controller monitors and records key system performance data through the use of our “Intelligent Replace Before Fail” ICARUS™ and DAEDALUS™ software utilities. This lets maintenance crews track performance data, allowing them to predict potential failures, identify current failures, and evaluate the root cause of each failure, as well as facilitating service before a critical failure.

General Digital is pleased to announce an economical alternative to our venerable GenStar™ high brightness 20.1" LCD monitor. It was designed especially for those applications that require an affordable, sunlight readable solution with a large flat screen monitor. The 20.1" SXGA sunlight readable LCD display utilizes a combination of our GenFlective™ passive enhancements, and active enhancements in the form of brighter backlights, thereby achieving 600 nits of luminance. Our DHG-20W Series, DHP-20W Series and DHR-20W Series LCD monitors can easily incorporate these sunlight readable enhancements.

Just when you thought a rack mount flip-up LCD monitor couldn"t get any bigger. We’ve added a 20.1" display to our popular SlimLine Lite II™ line. You can now have the world’s first of its kind 20.1" flip-up LCD monitor with keyboard and trackball that will fit nicely in your 19" rack.

Housed inside a redesigned compact enclosure, with an externally-mounted power supply for increased cooling, are two XGA (1024 x 768 pixels) resolution LCDs. In their standard configuration each LCD produces a luminance of 300 nits and a 350:1 contrast ratio. Adding the cost-effective GenFlective™ brightness enhancements increases the luminance to 530 nits and a 575:1 contrast ratio.

Six of General Digital’s LCD monitors and our 1U Rack Mount 75 Watt Power Supply have undergone rigorous testing to establish their ability to meet military standard requirements for a variety of conditions. We’re happy to report they performed quite well. The results are listed below.

Note 4: Standard monitor configuration tested did not include any ITO overlays in front of the LCD. General Digital can provide optional filters (e.g., 5 ohm or 10 ohm) in front of the LCD that will allow the monitors to comply with RE102 requirements. Internal test data is available to support these claims.

General Digital has obtained U.S. Patent Number 6,825,828 B2 for our Intelligent Backlight Controller™ (IBC), designed specifically for use in the GenStar™. The GenStar is General Digital’s backlit liquid crystal display (LCD) monitor comprising a backlight assembly, a cooling subassembly, a rear cover assembly and a controller. The IBC monitors bulb luminance and adjusts bulb current accordingly. Also, faults are monitored and logged so that predictive repair before failure analysis may be performed.

A patent is pending for General Digital’s™ XO-Fraim™, which uses a heavy frame to isolate an LCD from the antireflective, antiglare or other protective overlays of an LCD. It prevents the transmission of mounting stresses into the active cells of the LCD.

A patent is pending for General Digital’s™ GenSeal™, the application of a desiccating gasket between an LCD and a protective overlay, which prevents moisture from penetrating into the space between the LCD and the non-optically bonded overlay.

A true 1600 x 1200 resolution 20.1" LCD display in the form of our DH Series RGB Industrial™ standalone monitor, the DHG-20U-806. Now you can have UXGA resolution without the need for scaling the image. To complement this large, high resolution screen is our new video controller, which delivers 1600 x 1200 pixel resolution at 60 Hz. In addition, it offers DVI-D (Digital Video Interface-Digital), SXGA analog video and Composite Video (NTSC, PAL, SECAM, RS-170). This video controller will be available on many of our other LCD monitors, as well.

General Digital’s GenStar™, our sunlight readable 20.1" LCD monitor designed for the Federal Aviation Administration (FAA) and Air Traffic Control applications, was featured in the April 2005 issue of Connecticut Life. The article, “Eye in the Sky at Bradley International” by Doug Malan, detailed a Day in the Life of an air traffic controller. Central to their day, which includes the safe passage of 20,000 aircraft monthly, are the LCD monitors used to track each one of those aircraft. They utilize a sophisticated program, Standard Terminal Automation Replacement System (STARS), to track up to 1350 aircraft simultaneously, while reducing the amount and duration of air travel delays. STARS can also transmit important information to controllers, even in the event of a total hardware or software failure. Obviously, for such critical work, reliable equipment is crucial. That’s why Raytheon, the company who worked with the FAA and the Department of Defense (DoD) to design STARS, chose General Digital™ to supply the sophisticated and robust LCD monitors. Having been a customer for over 20 years, Raytheon knew General Digital™ had the technical expertise to build an efficient and reliable product to perfectly fit their needs. There are 50 airports in the U.S. expected to receive the STARS upgrade and General Digital™ expects to supply LCD monitors for each of them.

General Digital™ has designed a 20.1" model for our popular Rack Mount Hinge™ LCD Monitor. Remarkably, it is housed within a 2U (3.50") high, 20" deep, rack mount flip-up monitor enclosure. The LCD monitor also features multiple video inputs such as one UXGA input, two NTSC video inputs, and two S-Video inputs. Additionally, the 20.1" Rack Mount Hinge has the ability to display multiple video images in Picture-In-Picture windows. We expect to release it during the second quarter of 2005.

The 19.0" SlimLine 1U™ LCD Monitor/Keyboard/Trackball has successfully passed UL and FCC testing for use in FAA air traffic control towers and TRACONs and is now shipping. The SL1-19W-702 will serve as the official replacement model of the current model, SL1-19W-700, which is still available for a limited time.

General Digital™ announces a new LCD element for our popular 19.0" SlimLine 1U™ LCD Monitor/Keyboard/Trackball. Currently, the SL1-19W-702 is undergoing UL and FCC testing for use in FAA air traffic control towers and TRACONs. It is expected to get approval shortly. The current model of the SL1-19W-700 is still available for customers who don’t require a UL/ FCC-approved model.

Images shown on a monitor are reflections generated by light from the LCD module passing through the gap and the panel. The gap and panel have different refractive indexes, causing the light to bend when it passes through them. This results in a loss in its intensity, affecting the screen’s readability. By adhering the LCD module and panel together with optical bonding, the transmission of light is increased, improving the visibility of the display. This is useful when viewing a monitor with bright ambient lighting conditions.  In most cases, a rugged monitor acts as a second line of visibility. Optical bonding strengthens the ability to see data clearly on the screen in environments where it might be difficult to read.

TRU-Vu offers the largest selection of industrial-grade small LCD monitors and touch screens in the world. Choose from over 125 models of 8.4 inch to 12″ industrial-grade small lcd monitors, including small HDMI monitors, waterproof monitors, Sunlight Readable monitors, 4:3 and 16:9 aspect ratio, panel-mount and custom displays.

TRU-Vu offers over 235 standard, off-the shelf 13.3” to 19” industrial-grade LCD monitors and touch screens. Industrial LCD monitors offer many advantages over consumer or commercial-grade displays. They are more rugged, have higher shock and vibration resistance and can be modified or customized to meet your needs. Industrial and medical-grade monitors, Sunlight Readable, waterproof, open frame monitors and more.

TRU-Vu offers the largest selection of industrial LCD monitors and large touch screens in the world. We have an impressive line-up of over 175 off-the-shelf industrial LCD monitors with large screen sizes from 21.5" to 75". This includes Medical-Grade, Sunlight Readable, open frame, bezel-less, waterproof, 4K, custom and OEM widescreen monitors, with a wide range of configurations and enclosure types.

TRU-Vu Sunlight Readable Monitors and Daylight Screens (with Optical Bonding) and touch screen monitors are ideal for use in direct sunlight, or in other high-ambient light environments. These outdoor monitors offer 1,000 nits to 2,500 screen brightness. They are ideal for outdoor digital signage, military, law enforcement, amusement parks, way-finding, marine, and more.

Industrial-grade monitors and touch screens with standard brightness (250-350 nits) are ideal for use indoors or in environments without sunlight or bright lighting. We offer waterproof monitors, panel mount monitors, custom LCD displays, private label monitors, Medical Grade monitors, outdoor monitors, 16:9 and 4:3 aspect ratio, and more, from 7" to 65" lcd monitor screen sizes.

Our waterproof monitors and water proof touch screens are perfect for use as outdoor monitors, or in industrial settings where high humidity, liquids, and daily wash-downs may exist. Stand-alone or panel mount waterproof enclosures are available in stainless steel, painted steel or aluminum, with protection ratings up to IP68.

We offer a wide range of rugged and waterproof Touch Screen monitors for both indoor and outdoor use. Select from 5-wire resistive touch, surface capacitive, P-Cap, IR touch and SAW touch screen technologies in order to best meet your specific application requirements. Large touch screen monitors up to 46", and small touchscreen monitors down to 8.4".

Panel mount monitors and panel mount touch screens can be flush-mounted into doors, walls, kiosks and cabinets for improved ergonomics and safety. They are available with standard and high brightness screens, waterproof front face, and 4:3 and 16:9 aspect ratio, in a wide range of sizes and configurations.

11.6inch Capacitive Touch Screen LCD, with Case and Toughened Glass Cover, 1920×1080, HDMI, IPS, Optical Bonding Screen, Various Systems & Devices Support, Including Raspberry Pi, Jetson Nano, PC...

An optically bonded display eliminates the internal reflection between the screen glass and the LCD cell. This results in improved contrast, which enables the display to be better seen in brighter environments. Whether you have student desks at the front corners of the classroom, or you have to cram seats up the front sides of the meeting room, everyone will be able to see the screen clearly without reflection.
