LCD display doesn’t operate the same way as CRT displays , which fires electrons at a glass screen, a LCD display has individual pixels arranged in a rectangular grid. Each pixel has RGB(Red, Green, Blue) sub-pixel that can be turned on or off. When all of a pixel’s sub-pixels are turned off, it appears black. When all the sub-pixels are turned on 100%, it appears white. By adjusting the individual levels of red, green, and blue light, millions of color combinations are possible

The pixels of the LCD screen were made by circuitry and electrodes of the backplane. Each sub-pixel contains a TFT (Thin Film Transistor) element.  These structures are formed by depositing various materials (metals and silicon) on to the glass substrate that will become one part of the complete display “stack,” and then making them through photolithography. For more information about TFT LCDs, please refer to “

The etched pixels by photolith process are the Native Resolution. Actually, all the flat panel displays, LCD, OLED, Plasma etc.) have native resolution which are different from CRT monitors

HD TV has 1280×720 = 921,600 pixels; Full HD has 1920x 1080=2,073,600 pixels; 8K TV has 7,680×4,320=33,177,600 pixels. he “K” in 8K stands for Kilo (1000), meaning a TV that has achieved a horizonal resolution of about 8,000 pixels.

Although we can define a LCD display with resolution, a Full HD resolution on screen size of a 15” monitor or a 27” monitor will show different. The screen “fineness” is very important for some application, like medical, or even our cell phone. If the display “fineness” is not enough, the display will look “pixelized” which is unable to show details.

But you see other lower resolution available, that is because video cards are doing the trick. A video card can display a lower LCD screen resolution than the LCD’s built-in native resolution. The video cards can combine the pixels and turn a higher resolution into lower resolution, or just use part of the full screen. But video cards can’t do the magic to exceed the native resolution.

Abbreviation: QVGA, VGA, HD, FHD, 1080p, 1440p, 4K etc. It is very straight forward for different applications. For TV buyers, they can simply focus on 4K, 8K etc; for industrial engineers, they most likely focus on VGA, HD, WVGA etc.

Similarly, the curved Tft lcd display modules can be powered into a 4 source-light- throughout screen, and on the other hand. A curved Tft display modules, for example, are a type of Tft display modular.

Curved Tft display modules are made of two modules: curved Tft display modules, and more. The curved lcd display module is one of the most popular curved Tft display modules. It is one of the most popular curved Tft display modules that use 29.4 times per second, the curved Tft display modules can be divided into two main:: curved Tft display modules, and more. One of the most popular curved Tft display modules are the curved Tft display modules, which allow for users to display different products at different times. A curved lcd display module for curved Tft display modules can be divided into two main.

This LCD display screen is 7 inch, 1024 * 600 Used for Raspberry Pi 3/2 or Computer display Operating voltage: 12V power supply current requirements of more than 1A, if you are using the car power supply, you need to add a regulator to prevent interference Signal input: 2 AV + VGA + 1 channel HDMI high-definition reversing HDMI input: Version HDMI 1.2 VGA input: 1024x600 physical resolution, support the resolution range can be 640 x 480 --- 1600 x 1200 between the arbitrary adjustment! AV1 video input (can link DVD device or front camera) AV2 video input (to the car automatically switch to the camera screen) Support Plug and Play function Support image up and down left and right flip, image 4: 3/16: 9 display format conversion

compared with traditional leds, minileds have smaller particle size and higher brightness, which can bring better display effects to the lcd with a miniled back­light unit. meanwhile, it is more energy-efficient and supports accurate local dim­ming to avoid the uniformity problem that occurs with led backlight units. the active-matrix (am) driving glass substrate technology adopted by the chip-on-glass (cog) miniled backlight unit from boe is based on semiconductor technology and uses a glass substrate through boe’s lateral processing technology. glass is more suitable for making led backlight arrays with dense arrange­ment and heat concentration. the miniled unit is directly bonded to the glass substrate to realize the high-speed transfer of the led chips and can realize precise, independent dimming control of the back­light unit.

The xQDEF Diffuser Plate brings together the color and brightness performance of QDEF quantum-dot (QD) technology with the precise light diffusion necessary for perfect contrast levels in miniLED and full-array local-dimming LCDs. As a direct replacement for diffuser plate components in direct-lit LCDs, the xQDEF Diffuser Plate simplifies the display assembly process, allowing display makers to design and build the most cost-effective displays with the widest color gamut. Compared with other wide color gamut solutions, the xQDEF Diffuser Plate implementation results in close to no additional material costs. By the end of 2021, more than a million TVs with xQDEF Diffuser Plates inside shipped into the market.

With its 32‐inch LCD panel, 6K Retina resolution, and over 20 million pixels, Apple Pro Display XDR (Fig . 1) sets a new bar for the capabilities of a professional display. Designed for pro users who rely on color accuracy and true‐to‐life image reproduction, such as photographers, video editors, 3D animators, and colorists, Pro Display XDR delivers the most comprehensive set of features ever offered on a display in its price range.

Here"s how Pro Display XDR is engineered to produce industry‐leading imagery: Traditional LCD displays use edge‐lit backlight technology to diffuse light evenly across the display at the same brightness level. Instead, Pro Display XDR uses a locally dimmed backlight with 576 individual LEDs, controlled by an advanced algorithm in the timing controller chip. As a result, the display can exhibit incredibly bright, color‐accurate image areas and deep blacks simultaneously, delivering its 1,000,000:1 contrast ratio and up to 1600 nits peak brightness. An advanced thermal management system supports the display to maintain peak brightness indefinitely in environments up to 25° C. With these features, Pro Display XDR introduces Extreme Dynamic Range (XDR), far outperforming typical HDR brightness specifications for desktop displays and enabling pros to work with true‐to‐life content.

Pro Display XDR also incorporates several innovations to optimize image quality compared to traditional LCD displays. First, to minimize “blooming,” a halo effect surrounding bright objects on dark backgrounds, an Apple‐designed cavity reflector is layered on top of the LEDs and optimized geometrically. Along with several additional custom lenses and reflective layers, it directs the light upward while reducing halo effects and preserving light uniformity.

The display industry has experimented with various technologies to better reflect natural images and a wide range of colors on screens, and with the emergence of LED local dimming and HDR, display performance has substantially improved. However, traditional LCD screens’ brightness has long been considered relatively high in low grayscale. In other words, it isn"t black enough, and it"s difficult to use local image technology to differentiate the sense of depth with a high‐contrast ratio.

As a breakthrough in thin‐film transistor (TFT)‐LCD technology, BOE"s dual‐cell panel (Fig . 2) — referred to as “BD Cell” for short—offers several important technical advancements that conventional LCD screens don"t. The display uses pixel‐level ultra‐fine backlight control technology and a brand‐new integrated circuit (IC) driving technology to make the million‐level contrast ratio rate and 12 bits’ color depth come true, accurately displaying more natural and true‐to‐life colors.

The contrast ratio of a conventional LCD screen is 3,000:1 with 0.2 nits as the lowest brightness. The BD Cell"s screen is capable of raising the contrast ratio up to 150,000:1 and decreasing brightness to 0.003 nit. In terms of combining LED local dimming with BD Cell technology, the contrast ratio can be as high as 2,000,000:1. Moreover, while a conventional LCD screen"s color depth is 8 bit, BD Cell is capable of boosting the color depth as high as 12 bit with an enhanced IC driving algorithm. On the other hand, BD Cell incorporates advantages of an LCD screen"s stableness and technological maturity, with no image sticking.

In the end, “the successful development of BD Cell substantially increases the lifespan and the competitiveness of LCD technology, bringing a better visual experience to consumers and more possibilities for the entire display industrial chain,” says Feng Yuan, vice president of BOE Technology Group.

To achieve those specifications, Samsung has developed highly effective electroluminescent material and highly durable components. To make an inward foldable display with a bending radius of 1.5 millimeters (mm), all the layers within the panel should be folded without causing any cracks. As a result, the foldable display employs a cover window made of flexible, hardened plastic. Samsung says that it successfully reduced the thickness by more than 50 percent by taking advantage of materials that enable ultra‐thin layers. Furthermore, the stress of various layers (including the TFT, light‐emitting layers, polarizing plate, and cover window) is appropriately dispersed, allowing the product to pass a strict bending test more than 200,000 cycles.

Although quantum dot (QD) technology realizes a high color gamut for LCD, most QD materials are cadmium (Cd)‐based, raising concerns about their potential toxicity: Exposure to cadmium has been connected to cancer and other serious health issues, as well as environmental harms. As a result, Cd‐based QD materials are not widely accepted in the display market, and the industry has shifted its focus to finding nontoxic alternatives. Still, Cd‐free QD materials can bring their own challenges, including issues with low luminance and color purity.

Because one of Toray"s core offerings is organic emitting materials with high color purity for organic EL devices, the company wondered if they might be useful for a high color gamut LCD and began developing the SCO sheet (Fig . 6). In the beginning, the biggest issue with the organic emitting materials was their lifetime. However, Toray ultimately achieved a lifetime 1,400 times longer compared to the initial development stage.

According to the company, their SCO sheet is especially innovative for a few reasons. First, the high color purity of Toray"s organic emitting material is based on a full width at half maximum (FWHM) parameter that"s much narrower than any other organic emitting materials so far developed. So by using the SCO sheet, a high color gamut LCD can be realized. In particular, the sheet can cover both Digital Cinema Initiatives (DCI)‐P3 and Adobe specifications.

Second, Toray says its original organic emitting material has a higher quantum efficiency than that of non‐Cd QDs. Therefore, an approximately 10 percent higher luminance can be realized with the sheet than with non‐Cd QDs. For that reason, the SCO sheet can contribute to lower power consumption of the LCD panel.

Because Toray"s SCO sheet is free of toxic elements, it"s not restricted by various environmental regulations, including the European Unions’ Restriction of Hazardous Substances (RoHS) Directive. Finally, with the sheet, more than 99 percent of DCI and more than 99 percent of Adobe coverage can be achieved in one LCD panel. (According to the company, non‐Cd QDs can"t say the same.) Recently, in the PC monitor market, there has been a strong demand for compatibility of DCI and Adobe in one PC monitor. Toray believes that with the SCO sheet, it will be able to develop a new PC monitor market.

Although OLED is a well‐known way to apply organic electronics materials to the display industry, this is the first instance of applying organic emitting materials to the LCD industry, an achievement that expands the possibilities of organic electronics materials.

A 7‐inch OLED was selected for the virtual exterior mirror. In early test drives, Senner notes, Audi realized that the limited contrast of an LCD and especially the slow response time in low temperatures was a significant issue. “So it became clear very early, that we have to use an OLED display for this application, because with the dark black and the temperature, independent fast switching‐time OLED is the best solution,” he says.

8K resolution TVs are to contain double the number of pixels per inch as compared to 4K models. As an example, a 8K TV display with a screen size of 55 inches packs in 160 pixels per inch while the 4K resolution offers just 80 pixels per inch.Read moreNumber of pixels per inch in 4K and 8K resolution TVs worldwide, by screen size(in inches)Characteristic4K8K---

Deloitte. (December 8, 2020). Number of pixels per inch in 4K and 8K resolution TVs worldwide, by screen size (in inches) [Graph]. In Statista. Retrieved January 10, 2023, from https://www.statista.com/statistics/1196348/pixels-per-inch-4k-8k-tv-by-screen-size/

Deloitte. "Number of pixels per inch in 4K and 8K resolution TVs worldwide, by screen size (in inches)." Chart. December 8, 2020. Statista. Accessed January 10, 2023. https://www.statista.com/statistics/1196348/pixels-per-inch-4k-8k-tv-by-screen-size/

Deloitte. (2020). Number of pixels per inch in 4K and 8K resolution TVs worldwide, by screen size (in inches). Statista. Statista Inc.. Accessed: January 10, 2023. https://www.statista.com/statistics/1196348/pixels-per-inch-4k-8k-tv-by-screen-size/

Deloitte. "Number of Pixels per Inch in 4k and 8k Resolution Tvs Worldwide, by Screen Size (in Inches)." Statista, Statista Inc., 8 Dec 2020, https://www.statista.com/statistics/1196348/pixels-per-inch-4k-8k-tv-by-screen-size/

Deloitte, Number of pixels per inch in 4K and 8K resolution TVs worldwide, by screen size (in inches) Statista, https://www.statista.com/statistics/1196348/pixels-per-inch-4k-8k-tv-by-screen-size/ (last visited January 10, 2023)

Number of pixels per inch in 4K and 8K resolution TVs worldwide, by screen size (in inches) [Graph], Deloitte, December 8, 2020. [Online]. Available: https://www.statista.com/statistics/1196348/pixels-per-inch-4k-8k-tv-by-screen-size/

Blackmagic URSA Mini Pro 12K is a revolution in digital film with a 12,288 x 6480 12K Super 35 sensor and 14 stops of dynamic range, built into the award winning URSA Mini body. The combination of 80 megapixels per frame, new color science and the flexibility of Blackmagic RAW makes working with 12K a reality. Oversampling from 12K gives you the best 8K and 4K images with the subtle skin tones and extraordinary detail of high end still cameras. You can shoot at 60 fps in 12K, 120 fps in 8K and up to 240 fps in 4K Super 16. URSA Mini Pro 12K features an interchangeable PL mount, as well as built in ND filters, dual CFast and UHS-II SD card recorders, a SuperSpeed USB-C expansion port and more. DaVinci Resolve Studio is included for creative control through post from editing to color, VFX and more!

URSA Mini Pro 12K’s extreme resolution goes well beyond traditional motion picture film! You get the benefits of shooting with film including incredible detail, wide dynamic range and rich, deep color. Perfect for feature films, episodic television and immersive, large format IMAX. The incredible definition around objects makes it ideal for working with green screen and VFX including compositing live action and CGI. Super sampling at 12K means you not only get better color and resolution at 8K, but also a smoothness that comes from making aliasing invisible. This new generation of digital film technology ushers in an analog style purity and subtlety to deliver a better than film experience.

The Blackmagic URSA Mini Pro 12K features a revolutionary new sensor with a native resolution of 12,288 x 6480, which is an incredible 80 megapixels per frame! The Super 35 sensor has a superb 14 stops of dynamic range and a native ISO of 800. The new 12K sensor has equal amounts of red, green and blue pixels and is optimized for images at multiple resolutions. You can shoot 12K at 60 fps or use in-sensor scaling to allow 8K or 4K RAW at up to 120 fps without cropping or changing your field of view. URSA Mini Pro’s interchangeable lens mount lets you choose from the widest range of vintage and modern cinema lenses, so you can capture every ounce of character and detail from your favorite optics.

The URSA Mini Pro 12K sensor and Blackmagic RAW were designed together to make 12 bit RAW workflows in 12K effortless. As an incredibly efficient next generation codec Blackmagic RAW lets you shoot 12K and edit on a laptop, a capability that simply isn’t possible with other codecs. The massive resolution of the sensor means you can reframe shots in post for delivery in 8K and 4K. It’s like a multi camera shoot with only one camera. And it’s perfect for great looking vertical and square video, too. The advanced design of the sensor and Blackmagic RAW means that you can work in any resolution in post production instantly, without rendering, while retaining the full sensor’s color accuracy.

Only Blackmagic RAW makes cinema quality 12‑bit, 80 megapixel images at up to 60 frames a reality! Constant quality Q0 and Q5 options and new Q1 and Q3 lock the quality level, allowing compression to adapt, matching the detail of the scene. Constant bitrate encoding options 5:1, 8:1, 12:1 and the new 18:1 are designed to give you the best possible images with predictable and consistent file size. You can record RAW to two cards simultaneously so you can shoot 12K or 8K to either CFast or UHS‑II cards, even at high frame rates! Blackmagic RAW stores camera metadata, lens data, white balance, digital slate information and custom LUTs to ensure consistency of image on set and through post production.

Shooting RAW in 12K preserves the deepest control of detail, exposure and color during post. Oversampling means you get extremely sharp 8K without harsh edges. Best of all, Blackmagic RAW is designed to accelerate 12K for post production, making it as easy to work with as standard HD or Ultra HD files. It is highly optimized, multi‑threaded, works across multiple CPU cores and is also GPU accelerated to work with Apple Metal, CUDA and OpenCL. So you can always work with your camera RAW files without having to make proxies. Blackmagic RAW 12K images provide unprecedented resolution and quality for color, keying, compositing, reframing, stabilization and tracking in 4K or 8K.

URSA Mini Pro 12K is multiple cameras in one, shooting standard resolutions and frame rates in 4K, 8K and even insanely detailed 12K! With a massive 80 megapixels per frame at 60 fps in RAW you can capture perfect stills and motion shots in a single camera at the same time! You can shoot up to 60 fps in 12K 12,288 x 6480 17:9! For higher frame rates, you can shoot 120 fps at 8192 x 4320, 160 fps at 8192 x 3408 and even window the sensor to Super 16 to capture 4K at an incredible 240 fps at 4096 x 2160 DCI! URSA Mini Pro 12K has flexible frame rate and resolution options, and captures with improved motion rendering which means that you get smoother edges in 8K and 4K even at lower frame rates.

URSA Mini Pro is the ultimate high bandwidth recorder with 3 options for recording 12K, which contains almost 10 times the resolution of Ultra HD. You get dual built in CFast and UHS‑II SD card recorders, and a SuperSpeed USB‑C expansion port for recording to fast SATA and NVMe drives. With "Record RAW on 2 Cards" turned on, URSA Mini Pro 12K can record simultaneously across two cards up to an incredible 900MB/s to 2 CFast cards, or an impressive 500MB/s to 2 UHS‑II SD cards. The SuperSpeed USB‑C expansion port on the rear can record to USB‑C flash storage up to 900MB/s as a third recording option so you won’t be short of choices for capturing stunning 12K up to 60 fps or 8K up to 120 fps!

URSA Mini Pro is designed to include everything you need in a portable camera so you can take it anywhere! The evenly weighted camera body is made from lightweight, robust magnesium alloy. Buttons, switches and dials are laid out in a logical order that makes them easy to find by feel while using the viewfinder. An external backlit LCD status display lets you view critical information. Plus there’s a 4" fold out touchscreen for reviewing shots and accessing the menu settings. You get connections such as 12G‑SDI in and out, USB‑C, 48 volt phantom power XLR audio, timecode and reference in. The optional Blackmagic Shoulder Mount Kit lets you go from tripod to handheld in seconds!

URSA Mini Pro features high quality ND filters that let you quickly reduce the amount of light entering the camera. Designed to match the colorimetry and color science of the camera, the 2, 4 and 6 stop filters provide you with additional latitude even under harsh lighting. The IR filters have been designed to filter both optical wavelengths and IR wavelengths evenly to eliminate IR contamination of the images from which many ND filters can suffer. URSA Mini Pro ND filters are true optical filters with a precision mechanism that quickly moves them into place when the ND filter dial is turned. Filter settings can even be displayed as either an ND number, stop reduction or fraction on the LCD!

The new Blackmagic URSA Mini Recorder lets you record 12‑bit Blackmagic RAW files onto fast 2.5 inch SSDs, including the latest U.2 NVMe Enterprise SSDs. SSDs such as the latest 7mm U.2 NVMe disks are super fast, delivering data transfer speeds of up to 900 MB/s! This blazing fast performance allows you longer recording times for full resolution 4K, 8K and 12K 12‑bit Blackmagic RAW files in the highest quality Q0 encoding. The unique design of the Blackmagic URSA Mini Recorder means it attaches directly to the back of your URSA Mini Pro 12K between the camera and the battery. It’s controlled via the USB‑C so you don’t have to worry about manually starting or stopping the SSD recorder.

No native resolution. Currently, the only display technology capable of multi-syncing (displaying different resolutions and refresh rates without the need for scaling).Display lag is extremely low due to its nature, which does not have the ability to store image data before output, unlike LCDs, plasma displays and OLED displays.
