If you plan on using an LCD with your Raspberry Pi, there’s a good chance you’ll need to program it in Python at some point. Python is probably the most popular programming language for coding on the Raspberry Pi, and many of the projects and examples you’ll find are written in Python.

In this tutorial, I’ll show you how to connect your LCD and program it in Python, using the RPLCD library. I’ll start with showing you how to connect it in either 8 bit mode or 4 bit mode. Then I’ll explain how to install the library, and provide examples for printing and positioning text, clearing the screen, and controlling the cursor. I’ll also give you examples for scrolling text, creating custom characters, printing data from a sensor, and displaying the date, time, and IP address of your Pi.

BONUS: I made a quick start guide for this tutorial that you can download and go back to later if you can’t set this up right now. It covers all of the steps, diagrams, and code you need to get started.

You can also connect the LCD via I2C, which uses only two wires, but it requires some extra hardware. Check out our article, How to Setup an I2C LCD on the Raspberry Pi to see how.

There are two ways to connect the LCD to your Raspberry Pi – in 4 bit mode or 8 bit mode. 4 bit mode uses 6 GPIO pins, while 8 bit mode uses 10. Since it uses up less pins, 4 bit mode is the most common method, but I’ll explain how to set up and program the LCD both ways.

Each character and command is sent to the LCD as a byte (8 bits) of data. In 8 bit mode, the byte is sent all at once through 8 data wires, one bit per wire. In 4 bit mode, the byte is split into two sets of 4 bits – the upper bits and lower bits, which are sent one after the other over 4 data wires.

Theoretically, 8 bit mode transfers data about twice as fast as 4 bit mode, since the entire byte is sent all at once. However, the LCD driver takes a relatively long time to process the data, so no matter which mode is being used, we don’t really notice a difference in data transfer speed between 8 bit and 4 bit modes.

If this is your first time writing and running a Python program, you might want to read How to Write and Run a Python Program on the Raspberry Pi, which will explain everything you need to know to run the examples below.

The RPLCD library can be installed from the Python Package Index, or PIP. It might already be installed on your Pi, but if not, enter this at the command prompt to install it:

The example programs below use the Raspberry Pi’s physical pin numbers, not the BCM or GPIO numbers. I’m assuming you have your LCD connected the way it is in the diagrams above, but I’ll show you how to change the pin connections if you need to.

Let’s start with a simple program that will display “Hello world!” on the LCD. If you have a different sized LCD than the 16×2 I’m using (like a 20×4), change the number of columns and rows in line 2 of the code. cols= sets the number of columns, and rows= sets the number of rows. You can also change the pins used for the LCD’s RS, E, and data pins. The data pins are set as pins_data=[D0, D1, D2, D3, D4, D5, D6, D7].

The text can be positioned anywhere on the screen using lcd.cursor_pos = (ROW, COLUMN). The rows are numbered starting from zero, so the top row is row 0, and the bottom row is row 1. Similarly, the columns are numbered starting at zero, so for a 16×2 LCD the columns are numbered 0 to 15. For example, the code below places “Hello world!” starting at the bottom row, fourth column:

The RPLCD library provides several functions for controlling the cursor. You can have a block cursor, an underline cursor, or a blinking cursor. Use the following functions to set the cursor:

Text will automatically wrap to the next line if the length of the text is greater than the column length of your LCD. You can also control where the text string breaks to the next line by inserting \n\r where you want the break to occur. The code below will print “Hello” to the top row, and “world!” to the bottom row.

This program will print the IP address of your ethernet connection to the LCD. To print the IP of your WiFi connection, just change eth0 in line 19 to wlan0:

Each character on the LCD is an array of 5×8 of pixels. You can create any pattern or character you can think of, and display it on the screen as a custom character. Check out this website for an interactive tool that creates the bit array used to define custom characters.

First we define the character in lines 4 to 12 of the code below. Then we use the function lcd.create_char(0-7, NAME) to store the character in the LCD’s CGRAM memory. Up to 8 (0-7) characters can be stored at a time. To print the custom character, we use lcd.write_string(unichr(0)), where the number in unichr() is the memory location (0-7) defined in lcd.create_char().

In general, you take the input variable from your sensor and convert it to an integer to perform any calculations. Then convert the result to a string, and output the string to the display using lcd.write_string(sensor_data()):

Well, that about covers most of what you’ll need to get started programming your LCD with Python. Try combining the programs to get some interesting effects. You can display data from multiple sensors by printing and clearing the screen or positioning the text. You can also make fun animations by scrolling custom characters.

I"m trying to use some Python code to write text on a 16x2 LCD display ("compatible" with classics Hitachi HD44780) connected to a RaspberryPi model B+ via an I2C "back-pack".

The problem is that running multiple times this sample code, in sequence, one time it goes OK and the next time the LCD displays random characters; then again, one OK, one wrong.

I found an LCD in the surplus store that didn"t have much information, but after some searching and playing around, saw that it was based of the popular HD44780U. This is a 16 character LCD, and looks like 16x1 unit

I used Adafruit"s tutorial to set it up - see http://learn.adafruit.com/drive-a-16x2-lcd-directly-with-a-raspberry-pi/overview for more information - I"ll not repeat how to set up the circuit here. The main difference is that this LCD has only 15 leads, not 16, and the last 15th lead is for a non-existent backlit display. Ignore the 16th lead in Adafruit"s setup.

I also used Adafruit"s python library for character LCD displays - Adafruit_CharLCD.py - however, I had to make a few important modifications for my needs. First of all, I made some changes for it to support the 8x2 display (to automatically scroll over to the 2nd line when the first 8 characters have been filled up).

I also added another method to support scrolling text. With a simple call, the LCD will do a marquee type scrolling of the text. The caller can provide it any arbitrary length string without worrying about scrolling details. I tried to search for any existing work doing this already, but could not, so hopefully this will help others looking for something similar.

I"ve also attached my modifications to Adafruit_CharLCD.py - replace that in your environment with this file (first back that up, by copying it to Adafruit_CharLCD.py.bak (that"s the convention I use)).

Once you’ve played with LEDs, switches and stepper motors the next natural step is 16×2 alphanumeric LCD modules. These modules are cheap (less than $10) and easy to interface to the Raspberry Pi. They have 16 connections but you only need to use 6 GPIO pins on your Pi.

Most of the 16×2 modules available are compatible with the Hitachi HD44780 LCD controller. This allows you to buy almost any device and be sure it is going to work in much the same way as any other. There are loads to choose from on eBay with different coloured backlights. The one I purchased had a blue backlight.

You can control a HD44780 style display using any programming environment you like but my weapon of choice is Python. I use the RPi.GPIO library to provide access to the GPIO.

This script can be downloaded using this link or directly to your Pi using the following command :wget https://bitbucket.org/MattHawkinsUK/rpispy-misc/raw/master/python/lcd_16x2.py

If you use this code the only thing you will need to change is the GPIO pin mapping depending on what pins you use on your Pi GPIO header. Here are some photos :

Additional Notes : RS is low when sending a command to the LCD and high when sending a character. RW is always low to ensure we only ever input data into the module. 8 bit bytes are sent 4 bits at a time. Top 4 bits first and the last 4 bits second. Delays are added between certain steps to ensure the module can react to the signal before it changes.

The code above was inspired by code submitted by ‘texy’ on the RaspberryPi.org forum. I changed the way the bytes are broken down to bits as this significantly increased the response time of the display.

Are you looking to retrieve stock market data using Python? You"re at the right place. In this article, you"ll learn how to get stock market data using Python. You can further use the data to analyze, visualize, and get insights from it.

Yahoo Finance is one of the widely used platforms that provides stock market data. You can easily download the dataset from their website, but if you want to access it directly from a Python program, you can use the yfinance library. To install yfinance using pip, you need to run the following command at a command prompt:

The yfinance Python library is free to use and it does not require an API key.The code used in this project is available in a GitHub repository and is free for you to use under the MIT license.

This example uses the regularMarketPrice and regularMarketPreviousClose properties to get the required data. The yfinance library provides numerous other properties that you can explore. These include zip, sector, fullTimeEmployees, longBusinessSummary, city, phone, state, and country. You can get the complete list of the available properties using this code: import yfinance as yf

You can export a DataFrame object to a CSV file using the to_csv() method. Since the above data is already in the form of a pandas DataFrame, you can export the data into a CSV file using the following code: import yfinance as yf

Pandas is the widely used data-analysis Python library. If you"re not much comfortable with this library, you should get started with basic operations using Pandas.

The yfinance Python library is one of the most convenient libraries to set up, fetch data, and perform data analysis tasks with. You can use this data to visualize results and capture insights using libraries like Matplotlib, Seaborn, or Bokeh.
