WF32DTLAJDNT0 is a 3.2 inch 240x320 portrait mode TFT LCD module with Resistive Touch Panel (RTP). This module is built in with ILI9341 driver IC, it supports 8080 MCU 8bit /9bit/16bit/18bit/ SPI (3 Wire/4 Wire) interface. The brightness of WF32DTLAJDNT0 module is 350 nits typical value, contrast ratio 500:1 (typical value), view direction 6 o"clock, gray scale inversion direction 12 o"clock, glare surface glass. If customers require high brightness backlight, please choose WF32DSLAJDNT0.

As an option, you can order this TFT pre-assembled onto a breakout/carrier board. The board allows easy prototyping through its 0.1" headers. You can also include the carrier board in your end product to simplify construction and assembly. The carrier board contains a constant-current switching LED driver. The PCB is sized to fit neatly within the outline of the display, with a total weight of 51 grams.

We believe in open source hardware designs for Crystalfontz carrier boards and development kits. Under the Datasheets & Files tab is a downloadable zip file that contains everything you need to manufacture your own carrier boards: Gerber files, PADs source schematic and layout, and full BOM.

This kit consists of a CFAF240320B1-032T-TS TFT LCD module mounted on a carrier board. The carrier board supports a current driver for the LED backlight of the display. It is available under Additional Options on the website page for CFAF240320B1-032T-TS.

Raystar is a professional manufacturer of TFT LCD modules. Here we’d like to introduce our TFT LCD modules ranging from3”-3.9” diagonal. The available sizes are 3.2", 3.5", 3.9", 3.97" with resolution options such as 240x320, 320x240, 320x480, 480x128, 480x800. Based on the interface, we can categorize our TFTs into 8080, MCU, MPU, UART, RGB TFT LCD, SPI TFT LCD, MIPI DSI TFT LCD. In addition, there are different IC options for those who are seeking for specific types, including IL19341, IL19488, RA8875, SSD1963, SSD2119, PIC24, ST7511, ST7272A, and so on. In order to expand our product diversity, we have developed not only full color TFT, but also monochrome type, and high brightness TFT modules for our valued customers to choose from.

This 3.2 inch TFT LCD module adopts TN type LCD with 240*320 resolution. CTP touch and RTP touch can be added extraly.  Based on the LCD product’s high stability and long life cycle characteristics, this 3.2-inch LCD module can be used in a wide range of industrial and consumer electronics.
