As mentioned earlier, the commands that send text, numbers, formatters and control characters to a serial LCD are remarkably similar to the ones you use with DEBUG command.· That"s not just a coincidence either.· The DEBUG command is actually a special case of a command called SEROUT.· The SEROUT command has many uses, some of which include sending messages to serial LCDs, other BASIC Stamps, and computers.·

In this activity, you will display and animate text messages, numeric values.· The SEROUT command will be your tool for accomplishing these tasks.· You will use the SEROUT command to send text, numbers, control characters and formatters to the Parallax serial LCD.· As you will soon see, the text, numbers, and formatters are identical to ones you use with the DEBUG command.· The control characters will be a little different, but with a little practice, they"ll be just as easy to use as the DEBUG command"s CR, CLS, HOME, and CRSRXY control characters.···

Unlike the Debug Terminal, the serial LCD needs to be turned on with a command from the BASIC Stamp.· The LCD has to receive the value 22 from the BASIC Stamp to activate its display.· Here"s the PBASIC command for sending the serial LCD the value 22:

SEROUT 14, 84, [noparse]/noparse][/size][/font][font=Times New Roman][size=2][color=#ff0000]"See this?"[/color][/size][/font][font=Times New Roman][size=2], 13, [/size][/font][font=Times New Roman][size=2][color=#ff0000]"The LCD works!"[/color][/size][/font][font=Times New Roman][size=2

Ö·······If the LCD didn"t display properly, go through the instructions leading up to this program, and verify that each one was completed correctly.· Also double-check your wiring, program, and the SW settings on the back of the LCD.· Also try resetting power to your Board of Education.

Remember that 22 turns the display on, and 21 turns it off?· You can use these control characters to make the LCD text flash on and off.· All you have to do is replace the END command with this loop:

Most of the formatters that worked for displaying numbers with the Debug Terminal can also be used with the Parallax Serial LCD.· The DEC formatter is probably the most useful, but you can also use DIG, REP, ASC, BIN, SDEC, and most of the others.· For example, if you want to display the decimal value of a variable named counter, you can use commands like this:

Aside from demonstrating that you can display variable values on the serial LCD, this program also shows what happens if the text displayed tries to go beyond 16 characters in line 1; it wraps to line 2.

The LCD"s control characters are different from the DEBUG command"s control characters.· For example, HOME, and CRSRXY just don"t have the same effect they do with the Debug Terminal.· Take a look at the LCD documentation"s Command Set section.· It lists all the valid control characters for the LCD; here are a few more examples from the list:

The values from 128 to 143 and 148 to 163 are particularly useful.· Figure 10 shows where these values will place the cursor.· You can use values from 128 to 143 to place the cursor at characters 0 to 15 on the top line of the LCD.· Likewise, you can use values from 148 to 163 to place the cursor on characters 0 to 15 of the bottom line.

After placing the cursor, the next character you send the LCD will display at that location.· For example, here is a SEROUT command with an optional pacing value set to 200 ms.· This command will display the characters "L", "I", "N", "E", "-", and "2", evenly spaced across the top line, one character every 200 ms.

The LCD will still automatically shift the cursor to the right after each character, making it easy to place the cursor and then display a message.· For example, you can also place the cursor on character 7 of the top line and then display "ALL", then move the cursor to character 6 of the bottom line and display "DONE!" like this:

[color=#0000ff]FOR[/color][color=#000000] index = 1 [/color][color=#0000ff]TO[/color][color=#000000] 4 [/color]" Flash display 5 times

More elaborate displays can benefit from loops and lookup tables.· Here is an example of a "T E S T" display in a loop and with the help of lookup table.· Note that you can control the position of each character"s placement by adjusting the values in the second LOOKUP command"s table.

The Parallax Serial LCDs (liquid crystal displays) can be easily connected to and controlled by a microcontroller using a simple serial protocol sent from a single I/O pin. The LCD displays provide basic text wrapping so that your text looks correct on the display. Full control over all of their advanced LCD features allows you to move the cursor anywhere on the display with a single instruction and turn the display on and off in any configuration. They support visible ASCII characters Dec 32-127). In addition, you may define up to eight of your own custom characters to display anywhere on the LCD. An onboard piezospeaker provides audible output, with full control over tone note, scale and duration using ASCII characters Dec 208–232.

The LCDs currently for sale are updated to Revision F. Basic functionality remains the same, but power requirements and the layout of the backpack have changed. Please see the documentation for information on your model.

This device can be connected to a PC serial port using a MAX232 line driver. The circuit isn’t supported by Parallax, but it’s possible to make this connection with a few extra parts.

I think your program is similar to the way I envisioned it. I think you could prettify your code by eliminating "d" and by cleaning up your "for" loops. You"re placing the characters 1 by 1 in the "for" loop controlled by "i". I copied this concept. The LCDs I"m familiar with do not require placing the cursor prior to sequentially displaying the characters. In your program, you set the cursor prior to displaying each char. I left this in the "i" loop but I don"t think it is necessary. Instead, setting the cursor prior to the start of each text message should be sufficient.
