The project is a speed checker system that can detect rash driving and any kind of speed violation on highways and alert the traffic authorities. The conventional system uses a handheld radar gun which is aimed at the vehicle to record its speed and if there is any speed violation, nearest police station is informed. This process involves a lot of time consumption. Hence the proposed system is used to check the speed by calculating the time taken to travel between two set points at certain distance.

An IR transmitter and a receiver are installed on the set points on either side of the road. A control unit calculates the time taken by the vehicle to travel from one set point to other and calculates the speed that is displayed on seven segment display. If the calculated speed limit exceeds the set speed, a buzzer is sound which alerts the road transport authority.

The gps car speedometer built in automatic light sensor. Notice: when install, Do not occlude the light sensor in the back.In addition, the brightness can be set manually, and do not set it to the brightest state, which may affect the use during the day.

The blinking satellite icon means that you are searching for satellites, move the car to a spacious road, if the satellite icon stops blinking, it means that the satellite search is successful, the speed is displayed, and you can use it normally.

Check if the unit is correct, km KM/mile MPH, (speed unit switching reference setting item); automakers increase the factory speed displayed on the instrument panel by 5-7%, but the international standard is based on satellite data; fine-tuning the speed such as the instrument shows 100Km /h, this station displays 105Km/h, adjust the parameter value to 102.

Underground car parks, tunnels, under pedestrian bridges, the signal may be unstable when there are obstacles, mobile satellites heading towards the open road.

Afghanistan, Africa, Albania, American Samoa, Andorra, Anguilla, Antigua and Barbuda, Argentina, Armenia, Aruba, Azerbaijan Republic, Bahamas, Bahrain, Bangladesh, Barbados, Belize, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, British Virgin Islands, Brunei Darussalam, Cambodia, Cayman Islands, Chile, China, Cook Islands, Costa Rica, Dominica, Dominican Republic, Ecuador, El Salvador, Falkland Islands (Islas Malvinas), Fiji, French Guiana, French Polynesia, Georgia, Gibraltar, Greenland, Grenada, Guadeloupe, Guatemala, Guernsey, Guyana, Haiti, Honduras, Iceland, Iraq, Jamaica, Jersey, Jordan, Kazakhstan, Kiribati, Kuwait, Kyrgyzstan, Laos, Lebanon, Liechtenstein, Macau, Macedonia, Maldives, Malta, Marshall Islands, Martinique, Micronesia, Moldova, Monaco, Mongolia, Montenegro, Montserrat, Nauru, Nepal, Netherlands Antilles, New Caledonia, Nicaragua, Niue, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, Philippines, Qatar, Russian Federation, Saint Kitts-Nevis, Saint Lucia, Saint Pierre and Miquelon, Saint Vincent and the Grenadines, San Marino, Saudi Arabia, Serbia, Solomon Islands, Sri Lanka, Suriname, Svalbard and Jan Mayen, Tajikistan, Tonga, Trinidad and Tobago, Turkey, Turkmenistan, Turks and Caicos Islands, Tuvalu, Ukraine, United Arab Emirates, Uzbekistan, Vanuatu, Vatican City State, Venezuela, Wallis and Futuna, Western Samoa, Yemen

I appreciate your speed delivery of the components and all the other materials provided, but some of the components provided are not working. We assembled the circuit and started its testing and later we came to know that the adapter was not working. So I just feel that I have wasted my money. Now the circuit too is not working. I don"t know what to do with it as I have a presentation to give on this project. I want my money back, whatever the adapter"s charge is, or atleast compensation.

The system basically comprises two laser transmitter-LDR sensor pairs, which are installed on the highway 100 metres apart, with the transmitter and the LDR sensor of each pair on the opposite sides of the road. The installation of lasers and LDRs is shown in Fig. 1. The system displays the time taken by the vehicle in crossing this 100m distance from one pair to the other with a resolution of 0.01 second, from which the speed of the vehicle can be calculated as follows:

As per the above equation, for a speed of 40 kmph the display will read 900 (or 9 seconds), and for a speed of 60 kmph the display will read 600 (or 6 seconds). Note that the LSB of the display equals 0.01 second and each succeeding digit is ten times the preceding digit. You can similarly calculate the other readings (or time).

Figure below shows the circuit of the speed checker. It has been designed assuming that the maximum permissible speed for highways is either 40 kmph or 60 kmph as per the traffic rule.

The circuit is built around five NE555 timer ICs (IC1 through IC5), four CD4026 counter ICs (IC6 through IC9) and four 7-segment displays (DIS1 through DIS4). IC1 through IC3 function as monostables, with IC1 serving as count-start mono, IC2 as count-stop mono and IC3 as speed-limit detector mono, controlled by IC1 and IC2 outputs. Bistable set-reset IC4 is also controlled by the outputs of IC1 and IC2 and it (IC4), in turn, controls switching on/off of the 100Hz (period = 0.01 second) astable timer IC5.

The time period of timer NE555 (IC1) count-start monostable multivibrator is adjusted using preset VR1 or VR2 and capacitor C1. For 40kmph limit the time period is set for 9 seconds using preset VR1, while for 60kmph limit the time period is set for 6 seconds using preset VR2. Slide switch S1 is used to select the time period as per the speed limit (40 kmph and 60 kmph, respectively). The junction of LDR1 and resistor R1 is coupled to pin 2 of IC1.

For IC2, the monostable is triggered in the same way as IC1 when the vehicle intersects the laser beam incident on LDR2 to generate a small pulse for stopping the count and for use in the speed detection. LED2 glows for the duration for which pin 3 of IC2 is high.

The outputs of IC1 and IC2 are fed to input pins 2 and 1 of NAND gate N1, respectively. When the outputs of IC1 and IC2 go high simultaneously (meaning that the vehicle has crossed the preset speed limit), output pin 3 of gate N1 goes low to trigger monostable timer IC3. The output of IC3 is used for driving piezobuzzer PZ1, which alerts the operator of speed-limit violation. Resistor R9 and capacitor C5 decide the time period for which the piezobuzzer sounds.
