You can refer to the examples under STM32CubeF4 package to see their structure and get inspired from them to configure your files: STM32Cube_FW_F4_V1.21.0\Projects\STM32F429I-Discovery\Applications\STemWin

One of my favorite features of the STM32F429 discovery board is the TFT-LCD display. After setting up the programming IDE I started looking at the code examples given by ST. One code example caught my eye: The "LTDC_Display_2Layers" project.

I imported the project as explained in my STM32F4 Tutorial and modified the code so that instead of the two ST logos moving around on the screen, a jumping monoclecat is displayed. When you press the "USER" button, the cat jumps higher.

I have tried to compile the example file GxTFT_FSMC_BlackSTM32F407V.ino. The necessary assisting files should be in place including STM32GENERIC in the hardware folder. After having worked for quite some time Arduino IDE stops with an error message. I list the last page of the verbose output:

"C:\Users\Peas\AppData\Local\Arduino15\packages\arduino\tools\arm-none-eabi-gcc\4.8.3-2014q1/bin/arm-none-eabi-g++" -mcpu=cortex-m4 -mfpu=fpv4-sp-d16 -mfloat-abi=hard -DF_CPU=168000000L -mthumb -DSTM32GENERIC -DRAM_LENGTH=131072 -DFLASH_LENGTH=524288 -c -g -Os -w -std=gnu++11 -ffunction-sections -fdata-sections -nostdlib -fno-threadsafe-statics --param max-inline-insns-single=500 -fno-rtti -fno-exceptions -Dprintf=iprintf -MMD -DSTM32F4 -DARDUINO=10807 -DARDUINO_BLACK_F407VE -DARDUINO_ARCH_STM32 -DSTM32F407VE -DHSE_VALUE=8000000 -DMENU_SERIAL_AUTO=SerialUSB "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\cores\arduino/stm32" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\cores\arduino/usb" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\system/CMSIS" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\system/STM32F4/CMSIS_Inc" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\system/STM32F4/CMSIS_Src" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\system/STM32F4/HAL_Inc" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\system/STM32F4/HAL_Src" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\system/STM32F4/stm32_chip" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\cores\arduino" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\variants\BLACK_F407VE" "-IC:\Users\Peas\Documents\Arduino\libraries\GxTFT\src" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\libraries\SPI\src" "-IC:\Users\Peas\Documents\Arduino\libraries\Adafruit_GFX_Library" "-IC:\Users\Peas\Documents\Arduino\hardware\STM32GENERIC-master\STM32\libraries\stm32_dma\src" "C:\Users\Peas\Documents\Arduino\libraries\GxTFT\src\GxIO\STM32GENERIC\GxIO_STM32F407ZGM4_FSMC\GxIO_STM32F407ZGM4_FSMC.cpp" -o "C:\Users\Peas\AppData\Local\Temp\arduino_build_724464\libraries\GxTFT\GxIO\STM32GENERIC\GxIO_STM32F407ZGM4_FSMC\GxIO_STM32F407ZGM4_FSMC.cpp.o"

C:\Users\Peas\Documents\Arduino\libraries\GxTFT\src\GxIO\STM32GENERIC\GxIO_STM32F407ZGM4_FSMC\GxIO_STM32F407ZGM4_FSMC.cpp: In constructor "GxIO_STM32F407ZGM4_FSMC::GxIO_STM32F407ZGM4_FSMC(bool)":

C:\Users\Peas\Documents\Arduino\libraries\GxTFT\src\GxIO\STM32GENERIC\GxIO_STM32F407ZGM4_FSMC\GxIO_STM32F407ZGM4_FSMC.cpp:97:11: error: "PG12" was not declared in this scope

C:\Users\Peas\Documents\Arduino\libraries\GxTFT\src\GxIO\STM32GENERIC\GxIO_STM32F407ZGM4_FSMC\GxIO_STM32F407ZGM4_FSMC.cpp:98:11: error: "PG0" was not declared in this scope

STM32F429 has also LTDC driver for LCD like that, but this driver we will use later. For now we will use SPI for driving in serial mode and some other pins for controlling.

Remember: This library can also be used, if you are not using STM32F429 Discovery. It can be used in previous STM32F4 Discovery board. All pins can be changed in defines.h file which is included in project.

A high-quality 4.3" TFT true-color display with a capacitive touch panel is the most distinctive feature of the mikromedia 4. The display has a resolution of 480 by 272 pixels, and it can display up to 16.7M of colors. The display module is controlled by the SSD1963 graphics driver IC from Solomon Systech. This is a powerful graphics coprocessor, equipped with 1215KB of frame buffer memory. It also includes some advanced features such as the hardware accelerated display rotation, display mirroring, hardware windowing, dynamic backlight control, programmable color and brightness control, and more.

The STM32 L4-series is an evolution of STM32L1-series of ultra-low power microcontrollers. An example of L4 MCU is STM32L432KC in UFQFPN32 package, that has:

Common peripherals included in all IC packages are USB 2.0 FS, two SPI, two I²C, three USART, eight 16-bit timers, two watchdog timers, temperature sensor, 16 to 24 channels into one ADC, two DACs, 37 to 83 GPIOs, seven DMA, real-time clock (RTC), cyclic redundancy check (CRC) engine. The STM32FL152 line adds a LCD controller.

capacitive touch sense and 32-bit random number generator (only L0x2 and L0x3 chips), LCD controller (only L0x3 chips), 128-bit AES engine (only L06x chips).

NUCLEO-F446RE board for STM32F446RET6 MCU with 180 MHz Cortex-M4F core, 512 KB flash, 128 KB SRAM, external quad-SPI memory interface, external flexible memory interface.

NUCLEO-F412ZG board for STM32F412ZGT6 MCU with 100 MHz Cortex-M4F core, 1024 KB flash, 256 KB SRAM, external quad-SPI memory interface, external static memory interface.

NUCLEO-F429ZI board for STM32F429ZIT6 MCU with 180 MHz Cortex-M4F core, 2048 KB flash, 256 KB SRAM, 4 KB battery-back SRAM, external flexible memory interface, ethernet.

NUCLEO-F439ZI board for STM32F439ZIT6 MCU with 180 MHz Cortex-M4F core, 2048 KB flash, 256 KB SRAM, 4 KB battery-back SRAM, external flexible memory interface, ethernet, cryptographic acceleration.

NUCLEO-F446ZE board for STM32F446ZET6 MCU with 180 MHz Cortex-M4F core, 512 KB flash, 128 KB SRAM, 4 KB battery-back SRAM, external quad-SPI memory interface, external flexible memory interface.

A discovery board for STM32F429ZIT6 microcontroller with 180 MHz ARM Cortex-M4F core, 2048 KB flash, 256 KB RAM, 4 KB battery-backed RAM in LQFP144 package.

This board includes an integrated ST-LINK/V2 debugger via Mini-B USB connector, 8 MB SDRAM (IS42S16400J), 2.4-inch 320x200 TFT LCD color display (SF-TC240T), touchscreen controller (STMPE811), gyroscope (L3GD20), 2 user LEDs, user button, reset button, Full-Speed USB OTG to second Micro-AB USB connector, and two 32x2 male pin headers.

A discovery board for STM32F407VGT6 microcontroller with 168 MHz ARM Cortex-M4F core, 1024 KB flash, 192 KB RAM, 4 KB battery-backed RAM in LQFP100 package.

This board includes an integrated ST-LINK/V2 debugger via Mini-B USB connector, 24-segment LCD, touch sensors, 2 user LEDs, user button, reset button, and two 28x1 male pin headers.

This board includes an integrated ST-LINK/V2 debugger via Mini-B USB connector, 24-segment LCD, touch sensors, 2 user LEDs, user button, reset button, and two 28x1 male pin headers.

A prototyping environment for a variety of STM32 variants, which allows users to create their applications using an application programming interface (API) to implement device peripherals and a range of evaluation features on the EvoPrimer base including TFT color touchscreen, graphical user interface, joy stick, codec-based audio, SD card, IrDA and standard peripherals such as USB, USART, SPI, I2C, CAN, etc.

This article will explain how to program the Black Pill STM32F4 microcontrollers. It can be considered the big brother of the STM32F1 series, more powerful, and with all the features of the F1 version.

The ARM® Cortex®-M4-based STM32F4 MCU series leverages ST’s NVM technology and ART Accelerator™ to reach the industry’s highest benchmark scores for Cortex-M-based microcontrollers with up to 225 DMIPS/608 CoreMark executing from Flash memory at up to 180 MHz operating frequency.

The STM32F4 series consists of eight compatible product lines of digital signal controllers (DSC), a perfect symbiosis of the real-time control capabilities of an MCU, and the signal processing performance of a digital signal processor (DSP):

Advanced lines: 180 MHz CPU/225 DMIPS, up to 2 Mbytes of dual-bank Flash memory with SDRAM and Chrom-ART Accelerator™STM32F469/479– Quad-SPI interface, LCD-TFT controller and MPI-DSI interface

Access lines:The entry-level microcontrollers of the STM32F4 series!84 MHz CPU/105 DMIPS, the smallest, cost-effective solution with outstanding power efficiency (Dynamic Efficiency™)STM32F401 –Less than 3 x 3mm with USB 2.0FS OTG and SDIO interfaces

100 MHz CPU/125 DMIPS, outstanding power efficiency (Dynamic Efficiency™) and Batch Acquisition Mode (BAM), a new smart DMA-optimizing power consumption for data batchingSTM32F410 –New milestone in outstanding power efficiency (89 µA/MHz and 6 µA in Stop mode), true random number generator, low-power timer, and DAC.

STM32F412– High RAM and Flash memory density, USB interface, and enhanced peripheral set including a flexible external static memory controller with up to 16-bit data bus for LCD and external memory control, dual-mode Quad-SPI, CAN, DFSDM, and TRNG.

STM32F413/F423– Extends STM32F412 features with higher RAM and Flash memory density and an enhanced peripheral set including 10 UARTs, 3 CANs, SAI interface, a low-power timer, 2 DACs, 2 DFSDM with up to 6 filters. The STM32F423 includes AES encryption.
