Every year, motorcycle manufacturers make various improvements to their lineup, everything from little internal details, to new paint, to full-on redesigns. Over the years we’ve watched these machines get better, faster, and safer. In the 2020 model year, though, the majority of motorcycle manufacturers seem to be hopping on the TFT wagon. What does that mean for us, the riders?

We are all familiar with the Thin Film Transistor, or TFT screen, on our smartphones, hand-held video game displays, computer monitors, and car “infotainment” systems. The technology has advanced rapidly in the last few years, and motorcycle manufacturers have suddenly determined that they are ready for the harsh environment a motorcycle display needs to endure. During an attentive walk around of the International Motorcycle Show in New York City this past weekend, we noticed that new bikeswithoutTFT screens are becoming the rare exception.

Some manufacturers began outfitting their newest bikes with TFT screens a couple of years ago, but the 2020 model year has seen a sudden industry-wide shift. Major manufacturers like BMW, Kawasaki, Honda, and Yamaha, and even smaller companies like Energica, outfit their bikes with a TFT.

All of us who have been riding for many years are used to analog dials and gauges. Some of us are concerned about the longevity of the TFT, and in my opinion, those concerns are valid. Certainly, we’ve all seen our smartphone screens give up the ghost after only a few years of use. Some of us have an affinity for older motorcycles and have repaired or restored those old analog speedometers and gauges. We know that they often work flawlessly for decades. When they need repair, it’s a question of fixing or replacing internal mechanical parts. Not so with the futuristic TFT screens.

Those of us who are not hopeless luddites tend to sing the praises of a screen that can and does change to show machine and engine speed, a navigation display, the state of the motorcycle’s electronic suspension, tire pressure, the traction control setting, and a whole host of other information. The versatility of a TFT over traditional analog gauges is unquestionable: we might soon be able to program them ourselves with our preferred screen settings, just like our smartphones.

From a manufacturing point of view, TFTs simplify the process. The same TFT can be used on every motorcycle in a manufacturer’s lineup, with only a change of software to make the screen bike-specific. Does that mean a TFT will eventually be extremely inexpensive and easy to replace, should it ever go bad? Right now they’re too new to know for sure, but manufacturers are installing them everywhere, so we will all find out soon enough!

Gauge cluster design is a dying art. Speedometers and tachometers used to sit at the front of motorcycles like single-handed mechanical watches, projecting only the most pertinent information to the rider: vehicle speed, engine speed and the odometer. Then, like most analog things, digital became the preference and, for the most part, still is the preferred way to display even more information to riders like time, temperature, ride modes, traction control and any other minute pieces data the manufacturer deems necessary.

No one is saying having access to all that data is unnecessary or overbearing — quite the opposite. The more you can know about what’s going on with your bike the better, but, on a modern bike, all that information is more than an analog gauge can handle. So digital displays are a necessary evil, but their principal downside is they lack style, character and they all seem to look the same. However, it seems like the motorcycle industry is at a crossroads and the opportunity for unique, yet modern design is on its way back.

Thin-film-transistor liquid-crystal — or full-color TFT displays — are gaining popularity in the motorcycle industry. TFT is merely a more refined version of the well-known liquid crystal display (LCD), whose potential is already on display in the Lexus LFAand Audi’s Virtual Cockpit. And now, motorcycle manufacturers like Ducati are bringing that technology to the two-wheeled universe to exploit the benefits of a TFT display even further.

Ducati Monster Line Product Manager Stephano Trabusi explained, “TFT is more visible during the day, even in direct sunlight, the resolution is much higher than normal LCD so that you can have much more information on a display.” Given that the cockpit of a motorcycle doesn’t have the benefit of shade from a roof, more common digital and LCDs fall victim to severe glare. The Bosch system Ducati runs even goes one step further with a night mode that can tell if it’s night time, if you’re in a tunnel or a low light environment and flips the display background to black and the font white, so it’s easier to read.

Night vision is just the tip of the TFT iceberg, though. The complex levels of traction control and ride modes that come along with the Bosch system mean the screen has to be able to cycle through numerous menus and pages and display the traction control, engine modes and ABS settings once programmed. “Given that the bikes are so much more complex nowadays, they have more and more functions and more electronics; we need that higher resolution to display all that information.” And not only that but Trabusi justifies Ducati’s use of the display in the most modern way possible, “you always see the display when you’re riding, and it has to have a premium feel for a premium ride. Today, we are so used to our smartphones with color displays — it has become just so familiar. And to have this level of resolution and color on our bikes — it was common sense.”

Therein lies the problem with the Bosch system. Because it’s from a third party electronics and software company, and because it’s so close to a complete plug-and-play package, a handful of other manufacturers — BMW, KTM, Aprilia — use similar if not identical systems. So we wind up with cookie cutter displays no better than the uninspired digital systems they replaced. But thumbing through, pages, levels, toggling ride modes and taking calls via Bluetooth, it’s undoubtedly intuitive, but there’s an overwhelming sense that no one is exploiting the display for all it can do. It’s the same as getting an iPhone X and only using it for dim-lit selfies and tri-color wallpaper.

There’s no reason Ducati couldn’t create its own version of Audi’s Virtual Cockpit — between the maps, different gauge cluster layouts and creative displays, it would be like nothing else on two wheels. The creative potential is there, but until someone unlocks it, we’re stuck in this dull purgatory of right angles and primary colors.

BMW Motorrad and Bosch are set to give riders what they want, in a move that the cutting edge German engineering and technology company estimates will lead to a safer and more convenient riding experience. In a survey of 2600 motorcyclists, Bosch found that 90% of riders utilize their mobile devices for planning purposes or as part of wrapping up their ride. But perhaps more surprisingly, a third of riders responded that they use their phones while actually riding.

In general, eight out of 10 of those surveyed were in favor of integrating smartphone and instrument cluster information. To address this desire, some of BMW’s new motorcycles will come with Bosch’s 10.25-inch TFT (thin-film transistor) display with split-screen capabilities. Riders will now be provided with the information they previously had to look to the instrument cluster and their mobile device for, in one location.

The new Bosch display will utilize their smartphone integration system called mySPIN to enable content from motorcycle-centric apps like REVER to display appropriately on one half of the screen, while speed or warning indications will display on the other half.

The content being shown can be regulated by the rider with controls on the handlebar. The screen itself is TFT LCD — this technology improves image quality over the traditional LCD displays. Similar Bosch mySPIN split screens will appear on Ducati and Kawasaki motorcycles, as well, but the display sizes may be smaller.

Some critics of the 10.25-inch Bosch split-screen have expressed concerns that such a large screen with app integration will lead to more dangerous distraction than increased safety for riders and those on the road around them. But there is one feature of the Bosch mySPIN that truly has the potential to save lives: Help Connect.

According to Bosch, “The digitally connected emergency call system for motorcycles enhances road safety by enabling the fast, automatic dispatch of rescue services in the event of an accident.”

But you don’t have to worry about EMS showing up if your bike happens to take a nap in a parking lot: Bosch purports that the technology is smart enough to know if you’ve had a drop or an accident … but just in case, you’ll get a call to confirm the former before they send lights and sirens your way.

The very first gasoline internal combustion motorcycle was the Daimler Reitwagen, built in 1885. Robert Bosch created his namesake company a year later, in 1886. Coincidence? Probably, but it makes a nice segue into the advancements that Robert Bosch GmbH, better known simply as Bosch, has made in the motorcycle industry. As the company points out, “As a leading supplier of motorcycle safety systems, Bosch has sought for years to make motorcycles first and foremost safer, but also comfortable – without diminishing riding enjoyment.” As part of this commitment, the company just released their new line of five-inch TFT displays for motorcycles – the TFT Cluster 5” and the Connectivity Cluster 5”.

These displays were designed to be used by motorcycle manufacturers as original equipment dashboards, and as such, are completely customizable. With a compact footprint, the displays can be installed in a very confined space, something the engineers at Suzuki no doubt appreciated when the TFT Cluster 5” was selected for use in the 2023 V-STROM 1050 and V-STROM 1050DE.

The Connectivity Cluster 5” differs from the TFT Cluster 5”, in that, as you might have guessed, it has connectivity capabilities. Previously, adding GPS navigation to a motorcycle not already equipped required a separate aftermarket unit or smartphone mounted to the motorcycle in conjunction with the stock dashboard display. The Connectivity Cluster 5” allows the rider to wirelessly connect their smartphone to the dashboard, bringing smartphone functionality to the display, such as GPS, music, and messaging. At the same time, important information regarding the motorcycle operation, such as warnings or speedometer readout, is retained.

Bosch claims that the compact size and customizable nature of their new displays makes them suitable not only for conventional motorcycles, but also electric motorcycles, e-scooters, and ATVs. Expect to see Bosch’s new displays as original equipment on more motorcycles, as riders demand increased functionality, legibility, and connectivity from their bikes’ instrument clusters.

It goes without saying that TFT screens are becoming a more common feature on motorcycles these days. Even entry-level beginner-focused two-wheelers are starting to feature this fancy tech—heck, even some e-bikes come equipped with full-color TFT screens. That said, what exactly is a TFT display, and is it even any better than an analog instrument cluster? On top of that, why do more and more manufacturers seem to be slapping a TFT screen on all their models?

Well, for starters, a TFT, or Thin-Film-Transistor Liquid Crystal Display, is similar to what you find on your smartphone. Although not necessarily as fancy and capable of displaying millions of colors as your brand new iPhone, the TFT screens on most premium motorcycles are touted as full-color, and feature graphics and animations that really elevate the riding experience. As such, it’s no surprise that more and more manufacturers are outfitting their bikes with this tech. Indeed, three years ago, the notion of having a bike with a full-color display was exciting. These days, however, it’s pretty much a standard feature.

I’m sure you remember the days when an SD card with a 512MB memory would set you back thousands of pesos. Nowadays, you can pick up a 256GB microSD card for the same amount of money, and from a reputable brand. The same is true with TFT screens, and quite frankly, all facets of technology. That being said, it could be argued that fitting a motorcycle with a TFT display is in fact cheaper and more cost effective than opting for an analog instrument cluster, especially if you’re a manufacturer with economies of scale at your disposal.

Take, for example KTM, and its full color screens found across the board in its model range. The screen on the 390 series is pretty much the same as that of the 790 and 1290 models, albeit encased in a different housing. Underneath it all, however, it’s pretty much the same tech, and so it makes perfect sense for KTM to fit all its bikes with this technology—much to the delight of tech-hungry consumers like ourselves.

Indeed, well-crafted analog displays like that on the Triumph Thruxton could very well soon be a thing of the past, or something reserved for enthusiasts and collectors. Like a beautifully crafted watch, a high-quality analogue gauge cluster is truly something to behold, and something purists and classic aficionados hold near and dear to their hearts. As such, it could be argued that the mechanical instrument cluster could soon be considered a premium feature among high-end classic-style motorcycles.

At the end of the day, TFT displays have their benefits, and it can be argued that these benefits are strong enough to send analog gauge clusters the way of the dinosaurs. For starters, they’re adjustable, and easily configurable. They’re also a lot more visible with auto-contrast technology allowing them to adjust automatically to ambient light. Furthermore, they simply allow manufacturers to stuff in more data, keeping the rider informed about their bike. A TFT screen is pretty much like a tablet for your bike, allowing you to keep tabs on all the information it has to offer you.

According to the Bosch survey nearly 90 percent of riders use their smartphone to prepare or follow-up on trips. One third puts themselves in great danger using their smartphone even while riding. Bosch has developed the smartphone integration solution mySPIN to make the usage of smartphone content safe and more comfortable. Available in the powersports segment since 2018 – this includes for example so-called all-terrain vehicles or personal watercrafts – in BRP vehicles, mySPINnow will be introduced in the motorcycle segment for the first time. Ducati will introduce it together with Bosch’s also new 6.5-inch connectivity display without the split-screen option. “We want motorcyclists to be able to access smartphone content in an integrated and easy way while riding their bike. With the mySPIN platform and integrated connectivity cluster, we have found the right way to do it”, says Vincenzo De Silvio, Research and Development Director at Ducati. From 2021, the solution will also be introduced by Kawasaki.
