arduino uno tetris tft lcd free sample

A goal I set for myself for easter 2018: get aTetris gamerunning on a 32x32 LED matrix panel. This one uses Arduino/Genuino Uno as controller, which is rather limited in memory as I experienced. Large parts of the project consisted of finding ways around those limitations. Maybe I"ll do a Arduino Mega adaptation for more memory in the near future.

This is a moderately advanced project and requires experience soldering and programming in the Arduino environment. You"ll be working with organic matter and all its inherent quirks, so measurements may need to be adapted to fit the pumpkin you"re using.

The LED matrices you"ve made will be controlled by two Mini 8x8 LED Matrix Backpacks from Adafruit. Each controller allows you to drive 64 LEDs with only two wires from the Arduino, and you can chain multiple controllers together on those same two wires.

Download the Adafruit LED Backpack library and Adafruit GFX libraries and install them on your computer by copying each to the "libraries" folder of your computer"s Arduino sketch folder. Upload the "matrix8x8" file to your Arduino and verify that the LED backpack is working. The pins of the LED matrix might not make good contact in the female headers, so you may need to wiggle or partially remove it in order to make contact and allow all rows and columns to light.

Download the attached Pumpktris.ino.zip, unzip it, and open the file in the Arduino development environment. Compile and upload it to your Arduino. You should now be able to play on the mini LED matrix you set up in the previous step. I"ve tried to comment the code as much as possible, but here"s a general overview of the main processes:

Put a bowl or plastic food storage container at the bottom of the pumpkin to keep any dangling electronics from touching the bottom.Plug the joystick into your Arduino, the LED backpacks into the Arduino, and the LED matrices into the backpacks. Plug a power source into your Arduino. Now play yourself some Pumpktris!

Thank you! I originally wanted to grow pumpkins into Tetris shapes (no idea where that idea came from, though). By the time I remembered, it was too late in the season so the idea morphed into making Tetris on a pumpkin.0

By the way: in the video, did you recreate the Tetris theme, or did you find it online? I found it quite fitting for a halloween project!More CommentsPost Comment
