Powertip has grown to become a leading manufacturer of small to mid-size full color TFT and monochrome displays as well as resistive and capacitive touch panels. Powertip is headquartered in Taichung, Taiwan with production facilities located in Taiwan and Nanjing, China. Powertip’s product offerings address major industries to include medical, industrial, automotive, consumer, white goods, communications, test and measurement and gas pumps / parking meters.

Powertip’s manufacturing capabilities comprise Surface Mount Technology (SMT), Chip-On-Board (COB), Chip-On-Glass (COG), Chip-On-Flex (COF), Tape Automated Bonding (TAB) and screen printing. Production of a typical LCD panel would require Powertip to take Mother Glass, scribe, cut, fill the cells with liquid crystal and then seal the two sandwiched glass panels. Powertip would then add polarizers, color filters and all other required backend manufacturing processes to create a completed LCD module to specification.

With more than 3,300 employees in production and engineering and with factories in China and Taiwan, Powertip is a leader in LCD displays. Founded in 1991, Powertip now has more than 90,000 m2 of production space and can therefore effortlessly respond to all issues and developments in the market for a wide range of LCD technologies and applications.

Within LCD manufacturing, Powertip has many different products on offer, with more than 79 standard series and more than 1,000 different model configurations. This makes Powertip a uniquely positioned manufacturer with an exceptional diversity and flexibility in development and production.

Powertip has with an ISO quality certificate and a reputation for being a very proactive and innovative player built up a leadership position in the current display market, reinforced by a global network of reliable, representative partners. This makes the application of Powertip displays a safe choice. For use in a wide range of applications and machines, Powertip can offer the right display solution.

We offer LCD modules, HMI and embedded solutions including: Smart UART display, MPU embedded display, TN/STN/FSTN LCM, COG LCM, TFT LCM, FSLCD, graphic LCM, character LCM, custom LCD, custom LCM, EM touch display, projected capacitive touch display, resistive touch display and EMS.

WO1602I3 and WO1602I5 are two models of 16 characters by 2 lines of COG LCD P/N WO1602I with PCB board on module. WO1602I3 and WO1602I5 are built in with ST7032i IC; it supports I2C interface. The advantage of WO1602I3/WO1602I5 is having circuit layout on PCB board and with screw holes which make modules can be fixed on customers’ applications easily. Also, there are three kinds of connector pitch sizes of 2.54mm (default), 1.0mm and 0.5mm for options.

The supply voltage for logic (VDD) of WO1602I3 is 3.3V; as to the WO1602I5 is 5V, 1/16 duty circle, 1/5 bias. The module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃. WO1602I3 and WO1602I5 are available in FSTN positive Transflective LCD and with White LED backlight; please contact us if you need different types of LCDs or LED combinations.

WO12864K and WO12864K1 models are monochrome COG graphic LCD modules made of 128x64 dot matrix format. WO12864K/WO12864K1 COG Module is built in with ST7565 IC, it supports 8-bit 6800, 8-bit 8080 parallel and 4-wire serial SPI interface, power supply voltage 3V, VOP 9.5V, 1/65 duty. The WO12864K item is adopted ST7565V IC which is built-in with negative voltage, as to the WO12864K1 item is adopted ST7565P IC which is built- in with positive voltage.

This module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃. WO12864K/K1 are available in STN Negative, Blue Transmissive LCD and with White LED backlight. Please contact us if you need different types of LCDs or LED combinations.

WO128128A2 model is a round COG LCD display WO128128A model with a PCB board on module. This Round STN COG module is built in with ST75161 IC; it supports 8080 parallel (default), 6800 parallel, 3-wire and 4-wire serial SPI, I2C interface, power supply voltage 3V, 1/136 driving duty, 1/12 BIAS. The advantage of WO128128A2 is having circuit layout on PCB board and with screw holes which make modules can be fixed on customers’ applications easily. Also, there are three kinds of connector pitch sizes of 2.54mm (default), 1.0mm and 0.5mm for options. WO128128A2 also have VDD 5V power supply voltage for optional.

The supply voltage for logic of WO128128A2 is 2.7V to 3.3V, typical value 3V. This module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃. WO128128A2 is available in FSTN positive LCD type with white LED backlight. Please contact us if you need different types of LCDs or LED combinations.

WO240128B2 model is a COG LCD display WO240128B model with a PCB board on module, which is made of 240x128 dots. WO240128B2 is built in with ST7586S controller IC; it supports 6800 8-bit (default), 8080 8-bit parallel and serial SPI interface, power supply voltage 3.3V, 1/128 duty, 1/12 Bias. The advantage of WO240128B2 is having circuit layout on PCB board and with screw holes which make modules can be fixed on customers’ applications easily. Also, there are three kinds of connector pitch sizes of 2.54mm (default), 1.0mm and 0.5mm for options. WO240128B2 also have VDD 5V power supply voltage for optional.

This WO240128B2 module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃. The WO240128B2 is available for FSTN positive Transflective with white LED backlight. Please contact us if you need different types of LCDs or LED combinations.

WO256128A2 model is a COG LCD display WO256128A model featured with a PCB board on module which is made of 256x128 dots, diagonal size 2.9 inch. WO256128A2 is built in with ST75256 controller IC, it supports 8080 8-bit parallel (default), 6800 8-bit and 4-wire serial SPI and I2C interface, power supply voltage 3.3V, 1/128 duty, 1/12 Bias. The advantage of WO256128A2 is having circuit layout on PCB board and with screw holes which make modules can be fixed on customers’ applications easily. Also, there are three kinds of connector pitch sizes of 2.54mm (default), 1.0mm and 0.5mm for options. WO256128A2 also have VDD 5V power supply voltage for optional.

WO256128A2 module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃. The WO256128A2 is available for FSTN positive Transflective with white LED backlight. Please contact us if you need different types of LCDs or LED combinations.

Powertip Technology Corporation – a company established in 1991 has grown to become a leading manufacturer of small to mid-size full color TFT and monochrome displays as well as resistive and capacitive touch panels. Powertip is headquartered in Taiwan with production facilities located in Taiwan and China. Powertip’s product offerings address major industries to include medical, industrial, automotive, consumer, white goods, communications, test and measurement and gas pumps / parking meters.

Powertip’s manufacturing capabilities comprise Surface Mount Technology (SMT), Chip-On-Board (COB), Chip-On-Glass (COG), Chip-On-Flex (COF), Tape Automated Bonding (TAB) and screen printing. To meet customer demands, Powertip has developed an STN/VATN LCD module technology with in-cell touch capabilities, a one-glass-solution (OGS) capacitive touch panel and implemented highly discerning touch panel technologies that offer water proofing and use when wearing gloves.

AU Optronics Corporation (AUO)as formed in 2001 and is a smart displayts solutions provider (TFT LCD, LTPS TFT-LCD, AMOLED, Micro-LED) for diverse verticals. AUO offers clients highly-customized and high-quality products and services. The company’s revenue totaled NT$271.0 billion in 2020. The company employs approximately 38,000 people worldwide, including Taiwan, Mainland China, Japan, Singapore, South Korea, the US, and Europe.

Solomon Goldentek Display Corp. (SGD)– was established in 1990, is committed to continuous efforts in order to stay at the top of display industry. SGD not only manufactures displays products like TN, STN, LCD, but also provides professional services in R&D, production and sales. Application products include: instruments, office equipments, messages, telecom, home appliances, autimotive. SGD has passed ISO 9001, TS16949, RoHS and REACH certification. Company offers also customized solutions.

HTDISPLAY Electronics Co.Ltdis a professional LCD manufacturer in China. Company specializes in various types of TN, VA, HTN, STN & FSTN LCD modules and TFT LCD products size from 0.96 to 15″. HTDISPLAY LCD products are widely applied in following fields: office automation, financial terminals, POS systems, telecommunications, household electrical appliances, medical equipment, auto electronics, electric power, automatic attendance checking systems, meters, fitness equipment, electronic classrooms, control equipment and others.

Ampire Co. Ltd.was established in 1998 and is a manufacturer of small and medium size LCD modules for industrial applications. Company’s offer include TN models, STN mono displays, TFT color displays and AMOLED displays. With such experience, Ampire has sharpened its mastery in the customization of LCD modules. Besides providing a complete lineup of displays, Ampire team also focuses on integral controls and easy display system solutions.

SHENZHEN RIFDA LCD– is a Chinese LCD full process manufacturer. RIFDA products cover TFT, OLED, electronic paper and flexible screen. The company’s annual sales amount USD 77million with an annual growth rate of 10%. The Company owns: 2 LCD production lines, 36 automatic COG lines, 2 manual COG lines, 28 automatic FOG lines. In Masters we focus in RIFDA’s icon displays.

Dalian Eastern Display Co., Ltd.is a high-tech professional manufacturer of production, development and application for LCD panels, modules and electronic parts in types of TN, STN and FSTN. Dalian is capable of manufacturing the modules in OEM and ODM with the technologies of SMT, COB, TAB and COG. The company has got the qualification of ISO9001 issued by the international authoritative organization-DNV. The company devotes particularly to the design and production of the customized LCD panels and modules. They are widely used in many electronic parts, such as digital multimeters, fax machines, telephones, public IC phones, electronic scales, clocks, charge meters for taxi, display panels of hi-fi, POS for bank, air conditioner and its remote controls, temperature display panels of refrigerators and control boards in automobiles or motorcycles.

WiseChip Semiconductor Inc.is a professional manufacturer of OLED displays. WiseChip main products include: character type displays, full color OLEDs, monochrome displays, wide temperature range, bendable OLEDs, transparent OLEDs. Products are manufactured according to ISO 9001 and ISO 14001 standards.

Good Displayhas been engaged in the development and assembly for E-ink Display, E-paper Display module, monochrome LCD Display, TFT LCD Display and OLED Display since 2007, and is one of leading manufacturer of displays in China, specializing in providing a Large variety of engineered E-Paper Display, LCD Display and OLED Display for both Standard and customized electronic products. Good Display is well acclaimed by customers for the high quality products. Company obtained management system certificate that fulfils requirements included in the ISO9001 and ISO14001 standard in 2011.

The LCD module incorporates the LCD panel and the driver/controller for displaying images, including the drive circuit, power supply circuit, the light source for the backlight, etc. LCD stands for "Liquid Crystal Display." LCD module is used in a wide variety of devices because they are relatively inexpensive, can be used in thin packages, and require little power.

LCD modules technology is widely used in devices with LCD displays. They are not only used as monitors in measuring instruments such as oscilloscopes and spectrum analyzers but are also widely used in audio-visual equipment such as TVs and audio equipment, and OA equipment such as printers.

In addition, some products may require a smaller size or touch panel type. Recently, LCD modules are often used for in-vehicle equipment, and LCD modules are widely used for car navigation systems and meter panels. High-performance LCD modules provide high visibility day and night, making them reliable devices from a safety standpoint as well.

This section describes the structure and principle of LCD modules. An LCD panel consists of a liquid crystal layer sandwiched between a glass substrate with transparent electrodes and a polarizing plate. By applying a voltage to the liquid crystal, the direction of the liquid crystal molecules is changed, and the amount of light transmitted is controlled, thereby displaying an image. LCD modules can be broadly classified into three types according to the differences in the components mounted on the LCD panel.

COB TypeThis type of LCD modules consists of a controller, driver, DC-DC converter, LED backlight, and other components mounted on a printed circuit board. Although it is difficult to miniaturize, it is suitable for industrial applications as an integrated module that incorporates all functions.

COG TypeThis is an LCD modules with various components mounted on a glass substrate. Compared to the COB type, it can be downsized because it does not use a printed circuit board. It is also attractive in that it can be made at a low cost and is a module that is widely used.

COF TypeThis is an LCD modules in which the driver is mounted directly on a polyimide film substrate. Although more costly, this module is used in large TVs and other products.

The structure of LCD modules are like a sandwich, with each component layered on top of the other. The components are a polarizing filter, glass substrate, transparent electrode, alignment film, liquid crystal, and color filter. The roles of each component are as follows.

Transparent Electrode: Electrodes are used to drive the LCD modules. A highly transparent material is used to not interfere with the display of images.

By mixing materials with different properties with LCD base materials such as ester-based / biphenyl-based / PCH-based (phenylcyclohexane) / cyclohexane-based / phenylpyridimine-based / dioxane-based, various LCD modules with performance suitable for different applications can be made. As an example, LCD modules for automotive applications, unlike those for office or home use, must have high durability against heat and vibration. Therefore, it is necessary to blend materials that improve thermal and vibration endurance performance. As described above, LCD materials are blended to have the appropriate performance for the situation in which they will be used.
