NOTE: Prior pushing through with this tutorial, I encourage you  (if you haven’t yet) to visit Miniaturizing Your Arduino Project using ATtiny85, which demonstrates how to set up your ATtiny85 with Arduino UNO and Arduio IDE.

I am a bit into programming the ATtiny85 currently, and was looking for some libraries to use for my 16×2 LCD via i2c. I tried testing the current library I had (refer to my previous tutorial : Displaying Text to LCD via I2C Module on DIY Arduino Board), but this does not work with the ATtiny85.

In my previous article, we’ve somehow shown the pinout for the ATtiny85 (in my case the ATtiny85 Development Board, but no much of a difference actually:

IMPORTANT: If tou have a separate power supply for the ATtiny85 IC or Development board, you must connect GND from the Arduino UNO to the GND of the power supply.

Now, connect your Arduino UNO as demonstrated in my previous post. We will use the Arduino UNO as ISP to upload sketches to the ATtiny85 IC or Development Board.

To do that I have modified the I2CIO.cpp file of the library to add some #ifdef AVR_ATtiny85 to use TinyWireM in spite of Wire, and to change "read" to "receive" and "write" to "send".

Using an LCD on a small chip like an attiny85 is not really that hard and till recent I didnt even think it warranted an instructable, but I have received questions about it, so I may as well expand on the process.

With the attiny only having a max of 6 pins available, it goes without saying that it cannot directly control all the pins of the standard Hitachi based LCD"s

A little bit over a year ago, I described how to add an LCD to an Attiny or other chip, using only 2 pins. That circuit made use of an HC164 shift register, but as I2C modules for LCD"s are extremely cheap and even LCD"s with a module already in place also are dirt cheap, one might as well use I2C on the Attiny85.

I2CThe attiny85 can simulate I2C on PB2 (pin 7) (SCL) and PB0 (pin 5) (SDA). The "Wire" library that is used to read and write bytes from and to the I2C port on the arduino doesnt work on the attiny. It needs the TinyWireM library to act as an I2C master

The "NewLCD" library from Francisco Malpartida is my favorite library, but also that one fails in using I2C for the Attiny because it makes a call to the Wire library. A modification to make it work with Attiny85 can be found here.

The "Bro Hogan" library however does work. It is basically the same library as the standard arduino LCD library, but it is modified to recognize the Attiny85 and the Attiny2313 and then makes a call to "TinyWireM" rather than "Wire".

Adafruit also provides a libray that works with the Attiny85 and that is described in another instructable. I will be using the Bro Hogan library here.

Most problems you may encounter are related to the IDE getting confused regarding the libraries. If you are using the standard Arduino LCD library, best replace it by the Bro Hogan library. If you are using Malpartida"s library and want to keep that (as it is a great library), move it out of the way. Grab the entire folder and move it out of your sketchbook/libraries folder. Make sure you have the TinyWireM library installed and make sure your libraries are up to date.

Now obviously there is no bootloader for the attiny85, but the process of burning the bootloader sets the fuses of the attiny from factory mode, to the mode you want to use it in. So, presuming you use the Arduino as ISP,:

Operating this display should not be out of the range of the ATTiny85 abilities. I have one using a two-way serial connection for a setup routine, that modifies EEPROM values.

Next you need to see what is coming out. If the received data is correct then there is an issue in the LCD display, try re-flashing the LCD board with new firmware.

This Arduino shield transforms your Arduino UNO into an ISP-Programmer for the ATtiny85 microcontroller. The board simplifies the Boot-loader burning on the ATtiny85 chip. It consists of an 8-pin DIP socket to insert the new ATtiny85 chip, C1 decoupling capacitor, and C2 capacitor is provided to avoid the Arduino UNO from being auto-reset when we upload the program to the ATtiny85 chip. The project is a good choice when the user wants to shrink the Arduino project into an 8-pin microcontroller and when the project requires only a few I/O pins.

The idea to join two boards seamlessly (16 digits, 32 keys) is very charming, but "seamless" might not be possible because the connection pins and some circuit lines (mainly in the keyboard area) on the PCB are "out of the width" of the display.

What really would be great (but I did not find yet) is a "good" 8-digit LCD display to save power. Together with some "sleep code" (if there is spare memory) I could replace the switch with a "software switch" - and replace the AAA battery with a smaller pile (ie LR2032).

This project demonstrates the ability of the Wokwi Arduino simulator. You can write code on ATtiny85 to drive an LCD2004 (4 rows, 20 column hardware) by yourself. You can learn to program as well as see the code in action. No hardare needed.

Timers are popular peripherals in microcontrollers. These timers are responsible for generating accurate time delays using Microcontroller. Also Timers can be used to work as a counters, PWM generation, Capture external signals and so on. Hence these timers are quite important to understand. This tutorial explains the timer in ATtiny85 microcontroller and how to configure and use them.

This is the first question that comes to mind when speaking of timers. What clock source does ATtiny85 timers use ? The The timer peripheral can be clocked with internal or external clock source. As per the ATtiny85 datasheet will use its internal RC Oscillator of 8MHz frequency when being shipped. For tutorial purposes we are using ATtiny85 development board from Digistump. In this ATtiny85 is configured to operate at internally generated 16.5MHz clock and we are using this clock source to drive the timer.

There are two timer peripherals in ATtiny85 Timer0 and Timer1. In this tutorial we are going to use Timer0 to explain its working. Timer0 is a 8 bit timer which means it can count from 0 to 255. This can be configured to operate as a counter as well. The timer functionality can be further extend using the compare match peripherals which enables the timer to count events, PWM generation and so on.

Actual time delay = 63 x 15.81 ms = 996.03 ms . This is close to 1000ms which is our 1 second delay. We can generate even more accurate time delay using Compare match in ATtiny85 which is explained here.

There are two methods we can achieve time delay in ATtiny85. First method is to manually check the Overflow flag after triggering the timer and act when overflow occurs.

This is considered to be the elegant method since it uses the timer interrupt feature of ATtiny85 and doesn’t require code to wait until overflow flag is raised. Here when value in TCNT0 register reaches 255 TOV0 flag will be raised and simultaneously interrupt will be triggered. The program control will be then transferred to Interrupt service routine and there we can use our desired code in the sub routine. In our case we will repeat the timer operation for 63 times to get 1 second time delay.

This is the tiny 4 digit LCD that I used on the latest sculpture. I bought it fromhttps://hexpertsystems.comThe LCD is custom made, and uses a chip on glass PCF8576C controller that talks over I2C

This article describes a simple 1-Wire interface for the ATtiny85, or other AVR processors. To test it I built a circuit driving a serial 4-digit seven-segment display, displaying temperature using the DS18B20 1-Wire temperature sensor:

1-Wire is an ingenious interface that allows a master device to communicate with one or more slave devices over a single wire (plus ground). It"s especially useful on processors with a limited number of I/O pins, such as the ATtiny85, as it only uses up one pin.

To check how tolerant these routines are of variations in clock speed I varied the ATtiny85 internal clock using OSCCAL and checked whether the routines still worked. I was able to vary the clock by about 40% either side of 8MHz before the 1-Wire communication failed. The factory calibration of the internal oscillator is quoted as ±10%, so this should be well within this range.

As an example of using the 1-Wire routines with a single 1-Wire device on the bus I built a simple thermometer based on a DS18B20, using a Sparkfun serial seven-segment display. Here"s the circuit:

The DisplayTemp() routine shows temperatures below zero with a minus sign, to the nearest degree; for example -10°C. Positive temperatures up to 99°C are displayed with one decimal place; for example, 23.4°C. Temperatures of 100 degrees or more are displayed to the nearest degree; for example, 123°C:

Here"s the routine to read the 9-byte scratchpad memory from a single DS18B20 or MAX31820 temperature sensor, check the CRC, and display the temperature in the first two bytes:

Here"s a loop that reads the ROM data of a single device into the array DataBytes[] and displays it on the 7-segment display, two bytes at a time, highest byte first:

It displays the ROM data as a series of four displays, each consisting of four hexadecimal digits. For example, this is the last display for my DS18B20:
