320240 lcd module factory

NHD-320240WG-BxTFH-VZ# | Monochrome Graphic Module | 320x240 Pixels | Transflective LCD | White Backlight | FSTN (+) Positive Display | Built-in Negative Voltage

Newhaven 320x240 graphic Liquid Crystal Display module shows dark pixels on a white background. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-320240WG-BxTFH-VZ# display includes built-in negative voltage. It has an optimal view of 6:00, operates at 5 or 3.3V supply voltage and is RoHS compliant.

WG320240D1 is monochrome 320x240 LCD graphic displays which is having the module dimension of 142x96 mm and AA size of 95.97x71.97 mm, diagonal size 4.7 inch. This LCD graphic display is without controller on module. This LCD module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃.

The RG320240A series graphic LCD display module is resolution composed of 320x240 dots, and the module size is 160x109 mm. This model series has no controller, the logic power supply voltage range is 2.7~5.5V (driver voltage is 5V) , driving method is 1/240 duty. The RG320240A GLCD 320x240 module has a PCB with screw holes and peripheral circuit for easy mounting and usage. The module works within temperature from -20℃ to +70℃, storage temperature covers from -30℃ to +80℃. This model of 320x240 LCD display module can be equipped with an additional analog touch panel. There are a variety of LCD glass types / polarizer types /backlight colors. Please contact us for your request.

Orient Display LCD displays are the general category that includes LCD display glass panels, character LCD modules, graphic lcd modules, Arduino LCD displays, and our featured JAZZ series graphic LCD displays.

Graphic LCD Displays: Our standard LCD Graphic display products range from 122 x 32 pixels to 320 x 240-pixel resolution. These displays are available in positive or negative STN, blue STN, FSTN, or FFSTN with multiple backlight color options. They can be either traditional Chip-On-Board (COB) LCDs or Chip-On-Glass (COG) LCDs for displays with a smaller footprint and lower power consumption. COGs come in the same display types and colors as our other LCD modules but are designed without a PCB to allow for a slimmer profile.

JAZZ Graphic LCD Displays: The series are exclusive for Orient Display 128 x 64 pixels with the selection of yellow green STN, blue STN, positive or negative FSTN display, with the options of yellow green, green amber, blue, red or RGB tricolor backlights, with or without resistive touch panels. JAZZ series have two sizes: 1.0” and 2.7”.

VTN Character LCD Displays: Orient Display VTN is vertical alignment LCDs which provide superior black background and then great contrast with the options of yellow green, green amber, blue, red or RGB tricolor backlights.

LCD Glass Screens (Panels): Orient Display LCD display panels include different options of polarizer in reflective (saving power), transmissive (better contrast) or transflective (sunlight readable and battery powered) types. Orient LCD glass panels include 1; 2; 2.1/2; 3; 3.1/2; 3.3/4; 4; 4.1/2; 5; 6; 8; and 24 digits. Orient LCD glass panels also include 7 , 14 or 16 segments to display digits and alphanumeric letters. The temperature ranges are from room temperature to wide temperature applications. Orient LCD glass panels can have metal pin or zebra connections.

ARDUINO LCD Displays: Orient Display creates special character LCD displays with SPI interface which is easily hooked up with Arduino, which has been widely acceptable in the electronic design. The series includes 8 x 2 characters, 16 x 2 characters, 20 x 2 characters and 20 x 4 characters with either yellow green STN with yellow green LED backlight or blue STN with white LED backlight.

If you have any questions about Orient Display TFT LCD displays or if you can’t find a suitable product on our website. Please feel free to contact our engineers for details.
