7 inch tft lcd module 800x480 ssd1963 factory

ER-TFTM070-4V2.1 is the updated version of ER-TFTM070-4,that is 800x480 dots 7" color tft lcd module display with ssd1963 controller board,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, and ARM .It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.

Of course, we wouldn"t just leave you with a datasheet and a "good luck!".Here is the link for7" TFT capacitive touch shield with libraries,examples,schematic diagram for Arduino Due,Mega 2560 and Uno. For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and development kit at the bottom of this page.

ER-TFTV070-4 is 800x480 dots 7" color tft lcd module display with vga,video,av signal driver board and superior display quality,super wide view angle. optional 4-wire resistive touch panel with USB driver board and cable, optional capacitive touch panel with USB controller board and cable, optional remote control,remote control.It can be used in any embedded systems,car,industrial device,security and hand-held equipment which requires display in high quality and colorful video.

Descriptions:This 7.0" TFT LCD Module can be can be easy controlled by MCU such as 51,AVR,STM32,PIC,MSP430,DSP,ARM, and ARM .It can be used in any embedded systems which require display high quality colorful image. The Module used

SSD1963 LCD controller with 7 inch LCD module with touchscreen. This LCD has a superior display quality and super wide viewing angle, please see the sample pictures, they are taken directly from the LCD display.Features:7.0" TFT LCD Module, Resolution 800x480, SSD1963 Controller

LCD-specificed intialization code is provided, so that you can save time to optimize power control register and gamma curves for best display performance. We have test the provided code, it gives the best display performanace

Warning: All data port voltage can not exceed 3.6V.Package Included:1PCS*New 7" inch TFT LCD module 800x480 SSD1963 Touch PWM, For Arduino AVR STM32 ARM

The 7.0 inch WF70QTIFGDBN0 TFT LCD (resolution 800x480) is built in with SSD1963 controller board plus a 36 pin-out connector on board. This model is available in 8080 family MPU 8bit/16bit options and already defined pin no. 33 ~ 36 as backlight supply; so there is no need to design extra backlight circuit. This display is with the module dimension of 165x100 mm and AA size of 154.08 x 85.92 mm.

This is an IPS type 7 Inch MIPI TFT LCD with 1024x600 resolution, optional resistive or capacitive touch panel, with a  built-in EK79007AD controller chip-set with standard 250cd/m2 brightness.

The 7 Inch MIPI TFT LCD backlight is composed of 21 LEDs is and with a 9.6V backlight voltage and 180mA driving current. This 7 inch TFT LCD has a 7 (16:9) inch diagonally measured active display area with SVGA (1024 horizontal by 600 vertical pixels) resolution, with outline dimension 165x100x3.5 mm and active area 154.2144x85.92 mm, it can be operated at a temperature from -20 to 70 degree, stored at a temperature from -30 to 80 degree with 50,000 hours LED lifetime.

We are going to introduce category of Raystar’s 7-inch TFT LCD modules, which includes resolutions of 800x480~1024x800, and has a variety of TFT module sizes/VA sizes/AA sizes. 7-inch displays have plenty of IC and interface combinations. You can also choose either module with capacitive touch (supports 1-10 point touch) or resistive touch. The brightness ranges from 250 cd/㎡ to high brightness 1100 cd/㎡. There are also options of 7-inch TFT LCD display with control panel. If you couldn’t find a suitable module on our page, we have more models that are not published on the website. You are welcome to click “contact us” button on the top of this page. We’re more than happy to serve you.

Chenghao Optoelectronic CH700WV01B-PD is a 7.0 inch TN tft lcd module with RGB interface. This tft lcd module includes components such as Driver board, iron frame, tft lcd panel, driver IC, back light (BL) and FPC.
