To avoid having to solder a lot of wires, we developed the Easy Soldering Guide, a piece of printed circuit board that solders directly to the connector on the original Game Gear display. This connector connects to the main printed circuit board via a ribbon cable.

The installation of the Magic Screen requires (in addition to the original screen and its backlight system of course) the removal of only 3 components.

If you choose to do the complete installation (5 wires to solder so), you can choose between the 7 display modes proposed in order to have the choice according to the game you are playing.

Thus the Magic Screen consumes between 1.6W and 2W depending on the backlight setting chosen and we have chosen to equip the kit with a switch-mode power supply for maximum reliability. We did not want to risk the linear power supply which sometimes causes a short circuit in the kit or in the console.

Note: beyond 3.5W the power supply card has difficulty providing the necessary power to operate the Game Gear. It starts to heat up and wear out prematurely, even more true if you use a flash card like EverDrive which consumes more power than a standard game.

This is especially true when it comes to a video game console that is more than 30 years old and has components that operate at voltages close to 50V. The Sega Game Gear is a fragile console that can be unpredictable.

All CategoriesAntiquesArtBabyBooks & MagazinesBusiness & IndustrialCameras & PhotoCell Phones & AccessoriesClothing, Shoes & AccessoriesCoins & Paper MoneyCollectiblesComputers/Tablets & NetworkingConsumer ElectronicsCraftsDolls & BearsMovies & TVEntertainment MemorabiliaGift Cards & CouponsHealth & BeautyHome & GardenJewelry & WatchesMusicMusical Instruments & GearPet SuppliesPottery & GlassReal EstateSpecialty ServicesSporting GoodsSports Mem, Cards & Fan ShopStampsTickets & ExperiencesToys & HobbiesTravelVideo Games & ConsolesEverything Else

TL;DR:It seems that the majority of Game Gears that have troubles operating is suffering from leaking electrolytic capacitors, so it makes sense starting with recaping. It is very important to clean the PCB thoroughlyof the electrolyte fluid from old capacitors. As GameGear motherboard will operate even with no caps at all, although not recommended.

I bought a Sega Game Gear(VA1 — Twin ASIC (837–7398–01, 837–7719–01, and 837–7996)) at a local flee market. Since it is a European version (different regions have different power plug polarity, so be careful what power supply you use), I used my Spectrum ZX power supply to test it.

So if your Game Gear is experiencing similar symptoms, try measuring the output of the powerboard (first 5V and than 34V lines after power up cycle). It is important that you attach the multimeter before powering on, otherwise you might miss the initial surge. If 34V is stable and the 5V is not, try resoldering the components that are shared between them.

A picture off Facebook from a professional repair man, please note he uses a lot of SMD ceramic/tantalum capacitors (tantalum has the lowest ESR) the size of the caps is 1210/1206. If you find them in the right values, this is a much better option than using electrolytes, because the physical space in the console is very limited and the ceramic/tantalum caps are much more reliable. This board also has the LCD screen mod.

If you’re still not getting the correct voltages a user on Facebook group suggested the Game Gear Power Board IC Repair Kit, which contains the electrolytic capacitors, MB3775 (size SOP 16) IC and 3 power transistors (A, B and C).

Turning off is a protection mode for Game Gear and something is grounding out (you have a short to the ground (measure resistance between 5v and ground with power switched off)). Can be as simple as a misplaced polarity on a cap, a fleck of solder, bad power board, electrolytic fluid from an old cap, or battery acid under a chip that you can"t even see. The base point for troubleshooting would be a nicely and thoroughly cleaned mainboard.

If the fault on your game gear is the CFL tube lights, no power light, black screen then power off. A few times switching on and off and it starts working, than it was suggested to swap tiny transistor next to the 0.47 50v caps, swapping(Q3, Q4 transistors fixed the issue in one case).

One easy thing to check is leave the Game Gear on, for some time. If your screen is still flickering pay attention to transistors (Q9 and Q10). Sometimes electrolytic fluid from leaked capacitors catches underneath one of the transistors or resistors and that can be causing a slight short.

The last resolve would be an LCD screen mod McWill or a Chinese clone. (all of the images are from FB group and are here for educational purposes only)

If the lines roll and are not static, than there is usually still hope that recapping will fix the screen issue. With static lines it usually means that there is physical damage to the screen or the driver chip died or is on its way out.

Matt Marshall from the Facebook group suggested that sometimes these lines can be removed by (very!) gently warming up the LCD chip & ribbon cable and basically attempt to re-flow the ribbon cable, this should be used as a last result as you may damage the screen. If the lines roll and are not static, than there is usually still hope that recapping will fix the screen issue.

Alex Schot from FB group: “The middle IC LCD driver chip is losing connection or failing. Sometimes applying heat to the IC (hover your soldering iron above it for example) and then pressing down will fix the issue.” You could also try with a hairdryer.

This screen was saved by changing electrolytic capacitors. If the lines roll and are not static, than there is usually still hope that recapping will fix the screen issue.

Some have tried to fix this issue by heating the right edge of the GG LCD but have also had it come back not to long after. This issue seem like a typical case off ribbon cable detaching from the screen matrix. As a last resort I would try to heat the connections and try to re-flow them.

Vertical lines aren’t unfixable so much as its only a temporary fix, they are caused the same way they are on Game boy screens, just heating the ribbon cable with hot air and pressing it down usually removes them however every time the system gets hot you fix melting the connection and it probably dying again.

A newly designed drop in replacement power board for the GG, that is currently in beta testing. Instead of the barrel plug it has USB-C, so you can power it from a traditional USB power supply, power bank or computer for example.

I did McWill LCD mod on my Sega Game Gear and while upgrade from original LCD is amazing I was annoyed by gap between new LCD and Game Gear shell. Originally there was thin rubber frame between shell and LCD, but with new LCD gap is much bigger, as shown in the images.

So I modeled thicker replacement to try and close this gap. On comparison image above my version is one the right, original rubber is on the left. I skipped on making square cuts on the right side because these were holes for clips that were holding old LCD in it"s frame so they were not needed any more. New frame closes this gap. It doesn"t actually comes in contact with new LCD, I tried sliding piece of paper between them and it slid effortlessly. Which is fine as I wanted to avoid making pressure on LCD.
